Cabletron Systems TPXMIM-20 Manual de usuario

TPXMIM

INSTALLATION

GUIDE

CABLETRON SYSTEMS, P.O. Box 5005, Rochester, NH 03867-0505

TPXMIM-22

10BASE-T

ETHERNET

ETHERNET A B C

RCV LNK

RCV LNK RCV LNK1

CLN

TPXMIM-20

10BASE-T

ETHERNET

ETHERNET A B C

RCV LNK RCV LNK1

CLN

TPXMIM-34

10BASE-T

ETHERNET

ETHERNET A B C

CLN

RCV LNK

TPXMIM-33

10BASE-T

ETHERNET

ETHERNET A B C

CLN

RCV LNK

EPIM SEL

EPIM

TPXMIM Installation Guide

NOTICE

Cabletron Systems reserves the right to make changes in speciﬁcations and other

information contained in this document without prior notice. The reader should in all cases

consult Cabletron Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is subject to change without

notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FORANY

INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES

WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING

OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION CONTAINED

IN IT, EVEN IF CABLETRON SYSTEMS HAS BEENADVISED OF, KNOWN, OR

SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.

Cabletron Systems, Inc.

P.O. Box 5005

Rochester, NH 03867-0505

Printed in the United States of America

Part Number: 9031145 May 1994

SPECTRUM

and

LANVIEW

are registered trademarks and

TPXMIM

EMME

EMM-E6

MMAC-8FNB

MMAC-5FNB

MMAC-3FNB

, and

EPIM

are trademarks of

Cabletron Systems, Inc.

Ethernet

is a registered trademark of Xerox Corp.

VT-220

and

VT-320

are trademarks of Digital Equipment Corp.

CompuServe

is a registered trademark of CompuServe, Inc.

Printed on

recycled paper.

NOTICE

TPXMIM Installation Guide

FCC NOTICE

This device complies with Part 15 of the FCC rules. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

NOTE:

This equipment has been tested and found to comply with the limits for a ClassA

digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment uses, generates, and can radiate radio frequency

energy and if not installed in accordance with the operator’s manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause interference in which case the user will be required to correct the

interference at his own expense.

WARNING:

Changes or modiﬁcations made to this device which are not expressly

approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

DOC NOTICE

This digital apparatus does not exceed the ClassA limits for radio noise emissions from

digital apparatus set out in the Radio Interference Regulations of the Canadian

Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites

applicables aux appareils numériques de la class A prescrites dans le Règlement sur le

brouillage radioélectrique édicté par le ministère des Communications du Canada.

TPXMIM Installation Guide

iii

CABLETRON SYSTEMS, INC.

PROGRAM LICENSE AGREEMENT

IMPORTANT:

Before utilizing this product, carefully read this License Agreement.

This document is an agreement between you, the end user, and Cabletron Systems, Inc.

(“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron

software program (the “Program”) contained in this package. The Program may be

contained in ﬁrmware, chips or other media. BY UTILIZING THE ENCLOSED

PRODUCT,YOU ARE AGREEING TO BECOME BOUND BY THE TERMS OF THIS

AGREEMENT, WHICH INCLUDES THE LICENSE AND THE LIMITATION OF

WARRANTY AND DISCLAIMER OF LIABILITY. IFYOU DO NOT AGREE TO THE

TERMS OF THISAGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT

TO THE PLACE OF PURCHASE FOR A FULL REFUND.

CABLETRON SOFTWARE PROGRAM LICENSE

1. LICENSE. You have the right to use only the one (1) copy of the Program provided

in this package subject to the terms and conditions of this License Agreement.

You may not copy, reproduce or transmit any part of the Program except as permitted

by the Copyright Act of the United States or as authorized in writing by Cabletron.

2. OTHER RESTRICTIONS. You may not reverse engineer, decompile, or

disassemble the Program.

3. APPLICABLE LAW. This License Agreement shall be interpreted and governed

under the laws and in the state and federal courts of New Hampshire.You accept the

personal jurisdiction and venue of the New Hampshire courts.

TPXMIM Installation Guide

EXCLUSION OF WARRANTY

AND DISCLAIMER OF LIABILITY

1. EXCLUSION OF WARRANTY. Except as may be speciﬁcally provided by

Cabletron in writing, Cabletron makes no warranty, expressed or implied, concerning

the Program (including Its documentation and media).

CABLETRON DISCLAIMSALL WARRANTIES, OTHER THAN THOSE

SUPPLIED TOYOU BY CABLETRON IN WRITING, EITHER EXPRESS OR

IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF

MERCHANTABLITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH

RESPECT TO THE PROGRAM, THEACCOMPANYING WRITTEN

MATERIALS, AND ANY ACCOMPANYING HARDWARE.

2. NO LIABILITY FOR CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL

CABLETRON OR ITS SUPPLIERS BE LIABLE FORANY DAMAGES

WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR

LOSS OF BUSINESS, PROFITS, BUSINESS INTERRUPTION, LOSS OF

BUSINESS INFORMATION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR

RELIANCE DAMAGES, OR OTHER LOSS) ARISING OUT OF THE USE OR

INABILITY TO USE THIS CABLETRON PRODUCT, EVEN IF CABLETRON

HAS BEENADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE

SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF

LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, OR ON

THE DURATION OR LIMITATION OF IMPLIED WARRANTEES IN SOME

INSTANCES THEABOVE LIMITATIONS AND EXCLUSIONS MAY NOT

APPLY TOYOU.

UNITED STATES GOVERNMENT RESTRICTED RIGHTS

The enclosed product (a) was developed solely at private expense; (b) contains “restricted

computer software” submitted with restricted rights in accordance with Section 52227-19

(a) through (d) of the Commercial Computer Software - Restricted Rights Clause and its

successors, and (c) in all respects is proprietary data belonging to Cabletron and/or its

suppliers.

For Department of Defense units, the product is licensed with “Restricted Rights” as

deﬁned in the DoD Supplement to the Federal Acquisition Regulations, Section 52.227-

7013 (c) (1) (ii) and its successors, and use, duplication, disclosure by the Government is

subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical

Data and Computer Software clause at 252.227-7013. Cabletron Systems, Inc., 35

Industrial Way, Rochester, New Hampshire 03867.

CONTENTS

TPXMIM Installation Guide

CONTENTS

CHAPTER 1 INTRODUCTION

1.1 Using This Manual.......................................................................... 1

1.2 TPXMIM Features .......................................................................... 2

1.3 Overview......................................................................................... 3

1.4 The TPXMIM and Management Modules....................................... 4

1.5 The TPXMIM and MMAC Backplane.............................................. 5

1.6 LANVIEW LEDs.............................................................................. 6

1.7 Network Management Capabilities................................................. 7

1.8 Related Material ............................................................................. 7

1.9 Getting Help.................................................................................... 8

CHAPTER 2 SPECIFICATIONS/REQUIREMENTS

2.1 Operating Specifications................................................................. 9

2.2 TPXMIM Network Requirements.................................................. 11

2.2.1 TPXMIM-20/22 RJ45 Connector Specifications..............11

2.2.2 TPXMIM-33/34 Champ Connector Specifications........... 11

2.3 Network Requirements................................................................. 13

2.3.1 10BASE-T Twisted Pair Network..................................... 13

2.3.2 Multimode Fiber Optic Network....................................... 15

2.3.3 Single Mode Fiber Optic Network.................................... 16

2.3.4 Thin-Net Network............................................................. 17

2.4 Transceiver Requirements ........................................................... 17

CHAPTER 3 INSTALLATION/CONFIGURATION

3.1 Unpacking the TPXMIM................................................................ 19

3.2 Installing the TPXMIM .................................................................. 19

3.3 Configuring Boards and Ports ...................................................... 21

3.3.1 Assigning an Entire TPXMIM Board................................ 22

3.3.2 Assigning Individual TPXMIM Ports ................................24

3.4 Adding/Replacing EPIMs.............................................................. 25

3.5 Connecting to the Network........................................................... 26

3.5.1 Attaching a Twisted Pair Segment to

the TPXMIM-20/22 .......................................................... 27

3.5.2 Attaching a Twisted Pair Segment to

the TPXMIM-33/34 .......................................................... 28

3.5.3 Connecting a Twisted Pair Segment to an EPIM-T......... 30

3.5.4 Connecting an AUI Cable to an EPIM-X.......................... 32

CONTENTS

TPXMIM Installation Guide

3.5.5 Connecting a Fiber Optic Cable to an EPIM-F1/F2,

or EPIM-F3.......................................................................33

3.5.6 Connecting a Thin-Net Segment to an EPIM-C...............35

3.5.7 Connecting an AUI Cable to an EPIM-A..........................37

CHAPTER 4 TESTING/TROUBLESHOOTING

4.1 Pre-Installation Test......................................................................39

4.2 Installation Check-Out...................................................................40

4.3 Using LANVIEW............................................................................42

4.4 Troubleshooting Checklist.............................................................45

APPENDIX A TWISTED PAIR WIRING TABLES

APPENDIX B EPIM SPECIFICATIONS

TPXMIM Installation Guide

Page 1

CHAPTER 1

INTRODUCTION

The

Twisted Pair Switching Media Interface Module (TPXMIM)

is a

switchable multi-channel Ethernet repeater that resides in a Multi Media

Access Center

(MMAC) hub. This manual explains how to:

• install the TPXMIM

• connect the module to an existing network

• troubleshoot any installation/operational problems.

In addition, Appendices contain TPXMIM and Ethernet Port Interface

Module (EPIM) environmental and operational speciﬁcations.

This manual serves as a simple installation and troubleshooting reference

guide for the TPXMIM. To gain a full understanding of this device and its

capabilities, and to help eliminate any potential problems during or after

installation, please be sure to read and understand all of the instructions

and information in this document and in the release notes.

1.1 USING THIS MANUAL

You should have a general working knowledge of Ethernet or IEEE 802.3

type data networks prior to installing the TPXMIM. The following

summarizes the organization of this manual.

Chapter 1,

Introduction

, discusses TPXMIM features, and provides an

overview of the device’s capabilities. This chapter concludes with a list of

related documentation and how to obtain additional support related to

TPXMIM installation and operation.

Chapter 2,

Speciﬁcations/Requirements

, provides speciﬁcations and

network requirements to consider before installing the TPXMIM.

CHAPTER 1:

INTRODUCTION

Page 2

TPXMIM Installation Guide

Chapter 3,

Installation/Conﬁguration

provides instructions/guidelines

on how to install the TPXMIM into an MMAC-FNB, set the board or

individual ports to a speciﬁc MMAC Channel, install/replace an optional

EPIM, and connect segments to your device using an optional EPIM.

Chapter 4,

Testing/Troubleshooting

, provides some testing procedures to

ensure the TPXMIM is working properly before installing it into your

network. This chapter also details the TPXMIM LANVIEW

LEDs that

enable you to quickly diagnose network/operational problems and

includes a troubleshooting checklist.

Appendix A,

Twisted Pair Wiring Tables

, provides the wiring tables to

assist in using a punchdown block to wire twisted pair segments.

Appendix B,

EPIM Speciﬁcations

, lists the speciﬁcations for each

optional EPIM available for the TPXMIM.

1.2 TPXMIM FEATURES

LANVIEW

Cabletron provides a visual diagnostic and status monitoring system,

called LANVIEW, with the TPXMIM. LANVIEW LEDs help you

quickly identify device, port, and physical layer problems.

“Switching”

The TPXMIM brings “bank switching” and individual “port assignment”

to the MMAC chassis. Using any multi-channel management module

(i.e., the EMME or EMM-E6), you can assign either the entire board

(bank switching) or each individual port (port assignment) to any of the

three Ethernet channels on the MMAC-FNB (i.e., Channel A, B, or C).

Connectivity

The TPXMIM series offers four connector versions:

• TPXMIM-20 — nine RJ45 ports; one EPIM port

• TPXMIM-22 — twenty-one RJ45 ports; one EPIM port

• TPXMIM-33 — one 50-pin Champ connector; one EPIM port

• TPXMIM-34 — two 50-pin Champ connectors; one EPIM port

OVERVIEW

TPXMIM Installation Guide

Page 3

MIB Navigation

Assigning the TPXMIM board or individual ports to speciﬁc Ethernet

channels, or obtaining TPXMIM board or port statistics, requires a multi-

channel management device (e.g., EMME or EMM-E6) and access to a

MIB walking tool. The EMME or EMM-E6 allows MIB access both

locally (i.e., Local Management) and remotely (i.e., additional Cabletron

Remote Management packages).

For information on how to use the Local Management MIB walking tool,

refer to either the EMME or EMM-E6 Local Management manual. For

information on how to use a Remote Management MIB walking tool,

refer to documentation speciﬁc to that Remote Management package.

Compliance

Each TPXMIM utilizes Repeater Interface Controller (RIC) technology.

RIC technology integrates all repeater functionality into one integrated

circuit. This makes the TPXMIM fully 10Base-T IEEE 802.3i compliant.

Fault Tolerance

By performing its own repeater functions, the TPXMIM greatly enhances

the fault tolerance of the MMAC. By not relying on one central module to

perform repeater functions, TPXMIMs eliminate a single point of failure.

In addition, the TPXMIM provides port segment partitioning and

reconnection. This feature assures that problem segments do not affect

any other segments. If the TPXMIM detects 31 consecutive collisions on

any segment, or if a collision detector remains on for more than 110

the TPXMIM automatically partitions that segment. When the TPXMIM

receives a good packet from the segment, it automatically reconnects.

1.3 OVERVIEW

The

Twisted Pair Switching Media Interface Module

(TPXMIM)

provides board or individual port connectivity to any MMAC-FNB

Ethernet Channel (i.e., Channels A, B, or C). All ports initially default to

Channel B upon power up and require a Management Information Base

(MIB) change to access any other channel. Refer to Chapter 3,

Installation/Conﬁguration

, for additional information on how to assign

the TPXMIM board or individual ports to speciﬁc channels.
