Cabletron Systems FDCMIM-24 Manual de usuario

FDCMIM-04/08/24/28/34/38/44/48

FDDI CONCENTRATORS

INSTALLATION GUIDE

CABLETRON SYSTEMS, P.O. Box 5005, Rochester, NH 03867-0505

NOTICE

Cabletron Systems reserves the right to make changes in

speciﬁcations and other information contained in this document

without prior notice. The reader should in all cases consult Cabletron

Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is

subject to change without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR

ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL

DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO

LOST PROFITS) ARISING OUT OF OR RELATED TO THIS

MANUAL OR THE INFORMATION CONTAINED IN IT, EVEN IF

CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR

SHOULD HAVE KNOWN,THE POSSIBILITY OF SUCH

DAMAGES.

Cabletron Systems, Inc.

P.O. Box 5005

Rochester, NH 03867-0505

Printed in the United States of America

Order Number: 9030669-02 November 1993

SPECTRUM

LANVIEW

, and

Remote LANVIEW

are registered

trademarks and

FDCMIM-04

FDCMIM-08

FDCMIM-24

FDCMIM-28

FDCMIM-38

FDCMIM-44

FDCMIM-48

EMME

CXRMIM

TRMM

TPRMIM

FORMIM

FDMMIM

FDMMIM-04

FDMMIM-24

FDMMIM-30

MMAC-3FNB

MMAC-5FNB

MMAC-8FNB

MMAC-M8FNB

IRM

IRM2

IRM3

IRBM

are trademarks of Cabletron Systems, Inc.

CompuServe

is a registered trademark of CompuServe, Inc.

Ethernet

is a trademark of Xerox Corporation.

Windows

is a registered trademark of Microsoft Corporation.

FCC NOTICE

This device complies with Part 15 of the FCC rules. Operation is

subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

NOTE

:This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to Part 15 of the FCC

rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment.This equipment uses, generates, and can

radiate radio frequency energy and if not installed in accordance with

the operator’s manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is

likely to cause interference in which case the user will be required to

correct the interference at his own expense.

WARNING

: Changes or modiﬁcations made to this device which are

not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

DOC NOTICE

This digital apparatus does not exceed the Class A limits for radio

noise emissions from digital apparatus set out in the Radio

Interference Regulations of the Canadian Department of

Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques

dépassant les limites applicables aux appareils numériques de la class

A prescrites dans le Règlement sur le brouillage radioélectrique édicté

par le ministère des Communications du Canada.

Printed on recycled paper

SAFETY INFORMATION

iii

SAFETY INFORMATION

CLASS 1 LASER TRANSCEIVERS

Class 1 Laser Products

The FDCMIM-34 and FDCMIM-38 connectors use Class 1 Laser

transceivers. Read the following safety information before installing

or operating the FDCMIM-34 or FDCMIM-38.

The Class 1 laser transceivers use an optical feedback loop to

maintain Class 1 operation limits. This control loop eliminates the

need for maintenance checks or adjustments.The output is factory set,

and does not allow any user adjustment. Class 1 Laser transceivers

comply with the following safety standards:

• 21 CFR 1040.10 and 1040.11 U.S. Department of Health and

Human Services (FDA).

• IEC Publication 825 (International Electrotechnical

Commission).

• CENELEC EN 60825 (European Committee for

Electrotechnical Standardization).

When operating within their performance limitations, laser

transceiver output meets the Class 1 accessible emission limit of all

three standards. Class 1 levels of laser radiation are not considered

hazardous.

CLASS 1

LASER PRODUCT

SAFETY INFORMATION

CLASS 1 LASER TRANSCEIVERS

Laser Radiation and Connectors

When the connector is in place, all laser radiation remains within the

ﬁber.The maximum amount of radiant power exiting the ﬁber (under

normal conditions) is -12.6dBm or 55x10

-6

watts.

Removing the optical connector from the transceiver allows laser

radiation to emit directly from the optical port.The maximum

radiance from the optical port (under worst case conditions) is 0.8 W

-2

or 8x10

W m

-2

-1

WARNING

: Do not use optical instruments to view the laser output.

The use of optical instruments to view laser output increases eye

hazard.When viewing the output optical port, you must remove power

from the network adapter.

CONTENTS

CHAPTER 1 INTRODUCTION

1.1 Using This Manual ....................................................................1-1

1.2 Overview.....................................................................................1-2

1.3 Getting Help...............................................................................1-4

CHAPTER 2 CONFIGURATION AND INSTALLATION

2.1 Installation Requirements.........................................................2-1

2.2 Adding MIMs to an MMAC .......................................................2-1

2.3 MMAC Configurations...............................................................2-3

2.3.1 FDCMIMs Exclusively .................................................2-4

2.3.2 IRM3 and Ethernet MIMs with FDCMIMs ................2-5

2.3.3 EMME and RMIMs with FDCMIMs ...........................2-5

2.3.4 TRMM and Token Ring MIMs with FDCMIMs .........2-7

2.4 Twisted Pair Pinout Configuration...........................................2-8

2.5 Installing the FDCMIM.............................................................2-9

CHAPTER 3 USING LANVIEW

3.1 FDCMIM Status LEDs..............................................................3-1

3.2 Port Status LEDs.......................................................................3-2

CHAPTER 4 SPECIFICATIONS

INTRODUCTION

Page 1-1

CHAPTER 1

INTRODUCTION

The FDCMIM-04/08/24/28/34/38/44/48 are components of a modular

dual attached concentrator.These components attach to an FDDI dual

ring through the Cabletron Systems FDMMIM, FDMMIM-04,

FDMMIM-24, or FDMMIM-30.

Note:

Throughout this manual, unless otherwise noted, the term

FDCMIM refers to the FDCMIM-04/08/24/28/34/38/44/48.

FDCMIMs reside in a Multi Media Access Center (MMAC), and you

can use them either with or without an FDMMIM, since you can form

a stand-alone FDDI network using one or more FDCMIMs.

The FDCMIM-X4s have four and the FDCMIM-X8s have eight master

ports (where X varies, depending on the cable/transmitter type) that

accept different connectors. Chapter 4,

Speciﬁcations

, lists the

operating speciﬁcations for the different available FDCMIM cable and

transmitter types.

1.1 USING THIS MANUAL

This manual explains how to install FDCMIM concentrator modules.

The following summarizes the chapter organization.

Chapter 1,

Introduction

, describes the FDCMIM and its features.

Chapter 2,

Conﬁguration and Installation

, includes installation

requirements, and detailed instructions for installing your FDCMIM

into an MMAC hub as a stand-alone concentrator.

Chapter 3,

Using LANVIEW

, describes the purpose of each

FDCMIM LANVIEW LED.

Chapter 4,

Speciﬁcations

, provides operating speciﬁcations for each

FDCMIM cable/transmitter type.

INTRODUCTION

Page 1-2

Figure 1-1. FDCMIM-04 / 24 / 34 / 44 FDDI Concentrator

Media Interface Modules

1.2 OVERVIEW

The FDCMIM is a concentrator module that resides in an MMAC

network hub containing a Flexible Network Bus (FNB).The FDCMIM

acts as a modular component in a Dual Attached Concentrator.

FDCMIMs (and their attached stations) gain access to an FDDI dual

ring network through an FDMMIM, FDMMIM-04, FDMMIM-24, or

FDMMIM-30 the Cabletron Systems X3T9.5 compliant Dual Attached

Concentrator and Ethernet to FDDI Bridge Media Interface Modules.

The FDCMIM connects to the FDMMIM through the FDDI portion of

the MMAC Flexible Network Bus.

STP-PMD

FDDI

FDCMIM-44

PWRFNB

LNKPST

SMF-PMD

FDDI

FDCMIM-34

LNKPST

LNK

PST

LNK

PST

LNK

PST

PWRFNB

UTP-PMD

FDDI

FDCMIM-24

PWRFNB

LNKPST

FDDI

FDCMIM-04

LNKPST

LNK

PST

LNK

PST

LNK

PST

PWRFNB

INTRODUCTION

Page 1-3

Figure 1-2. FDCMIM-08 / 28 / 38 / 48 FDDI Concentrator

Media Interface Modules

By using an FDMMIM, FDMMIM-04, FDMMIM-24, or FDMMIM-30

you can manage adjacent FDCMIMs through FDMMIM Local

Management, the out-of-band management facility resident on the

FDMMIM and FDMMIM-04 modules.You can also manage FDCMIMs

with Cabletron Systems SNMP management tools such as

SPECTRUM

or Remote LANVIEW/Windows

FDCMIMs also provide the ﬂexibility of forming a single ring stand-

alone FDDI concentrator. Since FDCMIMs connect through the

MMAC backplane through an isolated FDDI bus, you can link several

modules, and their subsequent stations, together without the need for

a bridge or repeater.

STP-PMD

FDDI

FDCMIM-48

PWRFNB

LNKPST

SMF-PMD

FDDI

FDCMIM-38

PWRFNB

LNK

PST

LNK

PST

LNK

PST

LNK

PST

LNKPST

LNK

PST

LNK

PST

LNK

PST

UTP-PMD

FDDI

FDCMIM-28

PWRFNB

LNKPST

FDDI

FDCMIM-08

PWRFNB

LNK

PST

LNK

PST

LNK

PST

LNK

PST

LNKPST

LNK

PST

LNK

PST

LNK

PST

INTRODUCTION

Page 1-4

1.3 GETTING HELP

If you need additional support relating to the FDCMIM, or if you have

any questions, comments, or suggestions relating to this manual,

contact Cabletron Systems Technical Support. Before calling, please

have the following information ready:

• The product type (e.g., FDCMIM-24 or FDCMIM-38)

• The product serial number.

Note:

Locate the serial number on the FDCMIM front panel.

You can contact Cabletron Systems Technical Support by any of the

following methods:

By phone: Monday through Friday

between 8 A.M. and 8 P.M. EST

at (603) 332-9400.

By CompuServe

: GO CTRON from any ! prompt

By Internet mail: [email protected]

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de red de Cabletron Systems

Cabletron Systems

Cabletron Systems MMAC-M8FNB Manual de usuario

Cabletron Systems

Cabletron Systems SSIM-T5-04 Manual de usuario

Cabletron Systems

Cabletron Systems 9F241-12 Documento técnico

Cabletron Systems

Cabletron Systems 1082 Manual de usuario

Cabletron Systems

Cabletron Systems WPIM-DI Instrucciones de instalación y mantenimiento

Cabletron Systems

Cabletron Systems 6C105 Manual de operación y mantenimiento

Cabletron Systems

Cabletron Systems Netlink FRX4000 Instrucciones de montaje

Cabletron Systems

Cabletron Systems MMAC-M5FNB Manual de usuario

Cabletron Systems

Cabletron Systems CRBRIM-W/E Manual de usuario

Cabletron Systems

Cabletron Systems MMAC-Plus 9A128-01 Manual de usuario

Cabletron Systems

Cabletron Systems TPMIM-22 Manual de usuario

Cabletron Systems

Cabletron Systems TRMIM-32A Manual de usuario

Cabletron Systems

Cabletron Systems CyberSWITCH HSIM-W6 Manual de usuario

Cabletron Systems

Cabletron Systems TRXMIM-24A Manual de usuario

Cabletron Systems

Cabletron Systems TRBMIM-T Manual de usuario

Cabletron Systems

Cabletron Systems CyberSWITCH HSIM-W6 Manual de usuario

Cabletron Systems

Cabletron Systems W85 Manual de usuario

Cabletron Systems

Cabletron Systems TRMIM-22 Manual de usuario

Cabletron Systems

Cabletron Systems 9C300-1 Guía de inicio rápido

Cabletron Systems

Cabletron Systems HSIM-FE6 Manual de usuario

Cabletron Systems

Cabletron Systems TRBMIM Manual de usuario

Cabletron Systems

Cabletron Systems MMAC-5FNB Manual de usuario

Cabletron Systems

Cabletron Systems Expansion module 9T122-08 Guía de inicio rápido

Cabletron Systems

Cabletron Systems SSIM-T8-04 Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
