Bushnell IMAGE VIEW 118322 Manual de usuario

Model#: 118322

Lit. #: 98-0916/07-10 Version 2.0

Instruction Manual

WARNING

Do NOT look directly at the sun through your binoculars.

Doing so may cause permanent eye damage.

NOTE: To reset the camera if you experience problems or if the display becomes

unresponsive, remove the batteries for at least one minute, then re-install them.

Congratulations on your purchase of the Bushnell ImageView®

binocular! The Bushnell ImageView binocular takes the

technology of digital photography and combines it with a high-

quality compact binocular. This allows you to observe sporting

events, wildlife, scenic vistas or anything you would normally use

a binocular for, and then save the image in a built-in attached

digital camera. You can then download these images to your

computer and e-mail them to your friends and family, print out

the picture, or save them in a photo album for future use. Before

using the product, please read the instructions contained in this

manual and take time to familiarize yourself with the different

parts and features of the product.

Camera and Binocular

Parts Guide Power/

MODE

Button

Camera

Lens

Binocular

Focus

SNAP

Button

Display

Tripod

Socket

Battery

Compartment

USB

Port

SD Card Slot

Power

LED

Remote

Jack

CAMERA PARTS

The camera is powered by two AAA alkaline, lithium, or NiMh batteries (not1.

included). Insert batteries into the compartment, with the springs in contact with

the negative (at) end of each battery. A power meter on the lower right of the

display indicates battery condition.

Insert an SD card ("upside down" with metal contacts facing up) in the slot if greater2.

storage is desired. You may use SD cards (not MMC cards) up to a maximum 32 GB

capacity. The camera has 16 MB of internal memory which can hold 30-40 photos

(depending on the selected resolution and other variables).

Press and hold the MODE button until the power LED comes on. The camera will3.

turn o automatically after about one minute if no buttons are pressed. Note:

when the camera is connected to a computer via the supplied USB cable, the camera

will draw power from the computer, with no battery drain.

Hold the ImageView steady and press SNAP to take a picture (or start/stop4.

shooting a video, when the camera is in video mode). The camera focus is preset

to take sharp photos at distances of about 35 feet or farther from the subject.

When using a tripod, you can help avoid the eects of camera shake by plugging5.

the supplied remote shutter release into the jack next to the SD card slot, and

using the button on the remote rather than SNAP to take photos.

Setup and Basic Operation

The ImageView will imprint the date and time in the bottom right corner of your photos.

To set the correct date and time, after turning on the camera, press and hold both the

MODE and SNAP buttons at the same time, until the display begins to ash. The display

now shows the last two digits of the year. Press the MODE button to move the cursor to

the second digit if necessary. Press the SNAP button to advance the digit to the current

year ("10" for 2010, etc). Then press MODE to go to the next number, which is the month.

Again, use SNAP to change this to the current month. Following the month display is:

date, hour (24hr format), and minute-continue to set these following the same process

using the MODE and then SNAP buttons. When you have completed all of the date/time

settings, the display will stop ashing and return to normal. Note that you will need to

reset the date/time after replacing batteries.

Your ImageView is already set to high resolution and quality right out of the box, and it

is not necessary to use the MODE settings and make any changes to get good results.

However, as you might want to shoot a video clip, delete one or more previous photos,

or explore other options, we recommend you review the available mode options listed

on the following pages. Briey pressing the MODE button will step through these

operational modes in the listed order, and you will see the icon for each mode along

with its current setting on the display. Use the SNAP button to select the desired setting

for any mode. If you make no changes, and the SNAP or MODE button is not pressed

within 5 seconds, the camera will return to normal operation and display.

Using the Operational Modes/Setting Date & Time

Mode Icon/Text Settings Description

Video Video

Camera

OFF, ON Select "ON" instead of "OFF" to put the camera in

video mode. Wait several seconds for the camera

to automatically return to the normal display, then

begin shooting by pressing SNAP. The counter

will show elapsed time. Press SNAP again to

stop shooting. The counter will advance by one,

indicating the video le has been saved. Return to

the video mode setting and select OFF to reset the

camera to still photo mode.

Quality Hq or Lq High, Low Select "Hi" (recommended) or "Lo" quality to choose

the amount of le compression, which aects the

size of the photo le. "Lo" allows more photos to be

stored in memory, but at reduced quality.

Resolution Hi or Lo High

(2.1megapixels),

Low

(VGA:640x480

pixels)

Select "Hi" (recommended) or "Lo" resolution, based

on your preference for better looking photos (Hi) or

being able to take a greater number of photos (Lo).

Using the Operational Modes (Bold indicates default settings)

Mode Icon/Text Settings Description

Line

Frequency

60 or 50 60 Hz, 50 Hz Set to match the AC power frequency (cycles) of

your country. This ensures that stills and videos shot

under uorescent lighting appear normal.

Continuous CT OFF, 3, 5 Select 3 or 5 frames to shoot a rapid series of photos

instead of a single frame when SNAP is pressed (in

normal still photo mode). To cancel, enter this mode

again and select OFF.

Memory

Access

MEM Sto (USB Mass

Storage), PC (USB

Camera)

Select "Sto" to access the internal or card memory

when the camera is connected to a computer with

the USB cable. "PC" allows the camera to be used as

a live USB/PC camera (note that the 8x magnication

and lack of close focus capability limits usefulness in

most size rooms)

Delete Last LSt+Trash

Can

None-press SNAP

to delete the last

photo or video

Select this mode and press SNAP to delete only the

last photo or video you took. The counter will go

down one number.

Using the Operational Modes (Bold indicates default settings)
