BURY Motion Manual de usuario

Index

Introductory information 2

1. General 2

2. Security guidelines 2

Installation of the hands-free car kit 4

3. Scope of supply 4

4. Positioning and mounting 6

5. Installing the BURY Motion in your vehicle 7

6. Inserting and removing the iPhone 9

Operating guidelines 11

7. Turning the cradle 11

8. Using the hands-free car kit for the first time 11

9. Establishing a

Bluetooth

connection 12

10. Accepting, making, ending calls 13

11. Playing back music from your iPhone 14

12. Charging your iPhone 14

Further information 15

13. Service 15

14. Appropriate use of this system 16

15. Approvals and declaration of conformity 16

BURY Motion

1. General

Dear customer,

Congratulations on purchasing a BURY hands-free car kit. You have chosen a high quality product that

is extremely easy to use.

Please read the operating manual carefully so that you can fully enjoy your BURY hands-free car kit. If

you have any further questions concerning installation or operation of your car kit, please contact your

dealer. He will be happy to give you reliable advice.

You can also contact our hotline. Our phone and fax numbers are listed in the chapter Service at the

end of the operating instructions.

Have a good trip!

2. Security guidelines

Installation - who and where

The installation of this system can be carried out by yourself but please

observe the installation requirements of the automotive manufacturer

(VAS 1978). During the installation, park the car at a place where the

road traffic is not impaired.

Power supply

This system has been designed for the use in vehicles with an on-board

supply system of 12 volts (passenger car). If you intend to install the

device in a vehicle with an on-board supply system of 24 volts (lorry),

please use a voltage converter. If you have queries regarding this sub-

ject, please contact our hotline.

Position, volume

Install the components of the device in the vehicle so that your field of

vision is not impaired and the components are not mounted in the im-

pact zone of the passenger compartment or in the airbag inflation

zones.

Introductory information

Intended use

We shall not be liable for damages or malfunctions due to improper use

of the hands-free system. Therefore, do not expose the device to moi-

sture, extreme temperatures or shocks and carefully follow the proce-

dure described in the installation and operating guidelines.

Use while driving

Operate the system only when the situation allows it and when you do

not endanger, harm, constrain, or annoy other road users. The volume

of the device has to be set in a way that exterior noise is still audible.

Faults

Do not commission the device if you detect or assume a defect. In this

case, contact a Bury specialised dealer or our hotline. Improper repair

efforts can be dangerous for you. Therefore, only skilled personnel may

perform inspections.

Using the power supply cable with the cigarette lighter plug

Please only use this cable in connection with the BURY Motion. Do not

charge up a mobile phone or laptop using the cable. The cable is not

suitable for use in HGVs. The voltage output that is emitted on the mini

USB plug totals 12 volts.

Important:

The driver is ultimately responsible for the safe operationX

and control of their vehicle at all times. You should never

use a hand held phone, including sending or reading text or

picture messages, while driving.

Research indicates that there is a risk to safety when theX

driver of a motor vehicle is distracted and using a mobile

phone while driving can be a distraction.

The manufacturer strongly recommends that you use aX

hands-free solution when driving.

Installation of the hands-free car kit

3. Scope of supply

The hands-free car kit (HFCK) is supplied with different combinations of components, depending on

the sales regions (countries). The operating manual refers to all versions.

Description of the components:

1) Window Mount

2) Mobile phone specific cradle with integrated electronics

3) 12V vehicle power adaptor cable with cigarette lighter connection

4) Installation and Operating manual on CD

5) Plug-in external microphone

6) Dash Mount Adapter for installation on the dashboard or console

(Depending on the version available inclusive or separately as an accessory)

Accessories - available separately / including, if applicable:

7) GPS module to improve the navigation reception (only for iPhone 3GS/ 3G)

8) Car Mount (adhesive pad for mounting on the dashboard)

9) ISO cable tree for fixed installation

10) External microphone for perfect speech input (special passive microphone)

11) AUX IN/OUT cable for music playback using the car radio

Note:

If certain components are added or omitted you will receive the correspondingX

information on a separate enclosure.

Connection options:

1 Microphone

2 AUX IN/OUT

3 Power supply

6Installation of the hands-free car kit

4. Positioning and mounting

First of all, please choose the most convenient position for the BURY Motion in your vehicle by checking

different positions in the vehicle. In the following chapters, the Window Mount serves as an installation

example. The mounting of the Dash mount Adapter may be different, depending on the vehicle. In this

context, it may be necessary to purchase additional tools such as a console or a mounting bracket

separately through your specialist retailer.

When using the Car Mount, please clean the subsequent adhesive point of the dashboard with a damp

cloth before you remove the protective film and fit the Car Mount. Please remember that during the

subsequent use, depending on the intensity of the sunlight and the structure and condition of the da-

shboard, a bleaching of the uncovered surfaces may occur.

If you would like to use the device during your journey, positioning it in the front area on the driver’s

side is advisable. Sit in the vehicle and check whether you can reach the device without difficulty.

After having found a suitable position for the BURY Motion in the vehicle you can now mount the de-

vice. Please use a cleaning cloth for degreasing the surfaces to which you want to attach the Window

Mount.

Important:

When positioning the BURY Motion please take care that the device does not impairX

the view onto the road, that it will not be installed in the impact zone of the passenger

compartment (amongst others in the airbag inflation zones) and that the cable may be

laid without any problems.

Please avoid direct sunlight on the device or high internal temperatures, which can beX

rapidly reached in parked vehicles. In such cases, remove the BURY Motion and put it in

the car glove pocket or glove box for instance.

5. Installing the BURY Motion in your vehicle

Step 1:

Connecting the BURY Motion with the Window Mount

Push the BURY Motion in the Window Mount until you can feel it click

into place. After this, attach the Window Mount with the BURY Motion

in the vehicle.

Note:

You will find the same snap-in mechanism on the WindowX

Mount as you do on the Dash Mount Adapter and the Car

Mount.

Step 2:

Attaching the BURY Motion to the windscreen

Put the Window Mount on a smooth, dry, dust-free and oil free surface.

The Window Mount remains attached to almost all smooth surfaces.

The suction pad attachment is especially suitable for rapid and straight-

forward attachment to the front windscreen. Please use a cleaning

cloth to remove grease from the windscreen.

8Installation of the hands-free car kit

With the help of a suction pad you can attach the BURY Motion to the

windscreen. To do this, use the press-stud on the Window Mount in

order to either increase or decrease the pressure on the suction pad.

To do this, use the press-stud on the Window Mount in order to either

increase or decrease the pressure on the suction pad. If you press

down on the press stud from top to bottom then the suction pad at-

tachment loosens again.

Step 3:

Attaching the plug-in external Microphone

Please connect the microphone jack with the BURY Motion.

Step 4:

The power supply connection

Connect the BURY Motion with the cigarette lighter plug. Plug the ciga-

rette lighter plug into the appropriate connector in your vehicle.

When using the ISO power supply cable, please comply with the in-

structions in the documentation about your vehicle and radio concer-

ning the Pin allocations on the ISO-plugs. The Cinch plugs are for trans-

ferring the audio signals. It is possible that the radio in your vehicle has

other inputs. The corresponding adapters are available through your

specialist retailer.

click

6. Inserting and removing the iPhone

Inserting the iPhone

To insert your iPhone you have to open the front flap of the BURY Motion device. To do this, press the

ejection button on the right hand side of the BURY Motion. This is how you open the front flap.

Please remove any protective from your iPhone. Otherwise your iPhone does not fit in the holder or

the cover could be damaged. Place your iPhone in the opened front flap of the BURY Motion.

Using one hand, put the iPhone into the cradle until it snaps into place. With the other hand, hold the

Window Mount in position. Make sure that your iPhone is firmly in place before you drive away.

10 Installation of the hands-free car kit

Removing the iPhone

Press down on the ejection button on the right hand side of the BURY Motion so that the front flap

opens again.

Remove the iPhone upwards from the open flap.
