Bunn Tiger XL M-2 EXT Manual de usuario

For current speciﬁcation sheets and other information, go to www.bunn.com.

Features

Related Products

Item#

Project

Dat e

Patents Apply 7/08 A8.1a

BUNN Espress®Tiger XL M Series

• Upto180shotsperhourfromlessthan16”ofcounterspace.

• Intelligentmodularbrewingchamberadjustsespresso.

• SimulatesBaristatampingandpolishingmotiontoprovideuniform

extraction.

• Twohoppersforregular,decaforotherspecialtybeans.

• Eachhopperholds1.75lbsoffreshbeans.

• Adjustsfor4.5to7.4inchcupclearance.

• Podbrewingoptionstandardonallmodels.

• Intuitiveoperationaldesign.Easytousecontrolpadguidesuserthrough

stepsformakingdrinks.

• Easydailycleaning.

• Innovativemilkdeliverysystemdoesnotinjectsteamorwatertodilutethe

foamsocustomersenjoyafull,richavorexperience.

•Availablewithaself-contained1gallonmilkdrawerorexternalmilk.

Model Agency Listing

TigerXLM-2

TigerXLM-2EXT

Tiger Super Automatic

Espresso Machine

Espresso Water Quality System

EQHP-ESP

ProductNo.:39000.0008

Replacement Cartridge

EQHP-ESPCRTG

ProductNo.:39000.1008

Caﬁza™Cleaning Tablets

ProductNo.:36000.1189(100count)

ProductNo.:36000.1188(12/case)

Rinza™

MilkFrotherCleaner

ProductNo.:39265.0000(each)

ProductNo.:39265.0001(6/case)

Cup Heater

ProductNo.:35800.0400

Steamer

ProductNo.:35800.0401

Model Tiger XL M Series EXT

external milk

Dimensions:19.3”Hx15.8”Wx18.1”D

(49 cm H x 40.1 cm W x 45.9 cm D)

Model Tiger XL M Series

with milk drawer

Dimensions:25.5”Hx15.8”Wx18.1”D

(64.8 cm H x 40.1 cm W x 45.9 cm D)

BUNN®practicescontinuousproductresearchandimprovement.Wereservetherighttochangespecicationsandproductdesignwithoutnotice.Such

revisionsdonotentitlethebuyertocorrespondingchanges,improvements,additionsorreplacementsforpreviouslypurchasedequipment.

Alldimensionsshownininches. Bunn Corporation owns all copyrights relating to materials in this publication. Please contact Bunn Corporation to request permission to reproduce any portion of this publication.

Dimensions & Speciﬁcations

Bunn-O-MaticCorporationofCanada-280IndustrialPkwy.S.Aurora,OntarioL4G3T9•905-841-2866•Fax905-841-2775•www.bunn.com

CANADA

Tank Heater Total Cubic Weight Cord

Model Product # Volts Amps Watts Watts Capacity Measure lbs/kg Attached

TigerXLM-2 35800.6913 208 12 2000 2400 180shots/hr 12.5/.35 103/46.2 Yes/

         NoPlug

Capacity per Hour: Espresso:180

  Cappucino:120

  Latte:100

  PODProducts:60

  HotWater:7.9gallons(30 litres)

 

Model includes: Machine, water ﬁltration system, installation and 2-year preventative maintenance.

Electrical:Modelrequires2-wiregroundedservicerated120/208V,singlephase,50/60Hz.

Plumbing:20-100psi(138-690kPa).Machinesuppliedwith1/4"malearetting.Allmachinesaresuppliedwitha

 wastewaterhoseandmustbeconnectedtoadrain.

Tiger XL M, EXT

(front view)

3/08 © Bunn-O-Matic Corporation
