Bunn SLCA-7 Manual de usuario

Features

Related Products

ECID# 27986

PROJECT

DAT E

01/14

Model Agency Listing

SLCA-7

Specialty Liquid

Coffee Dispenser

SLCA-7

Dimensions: 32.8” H x 19.7” W x 23.4” D

(83.3cm H x 50cm W x 59.4cm D)

EQHP-10L

Product No. : 39000.0001

Graduated Cylinder Kit

Product No.: 34843.1001

Specialty Liquid Coffee Dispenser

• Dispenses two coffees from liquid concentrate plus milk and chocolate powders

(20:1 to 50:1 products)

• Accommodates two .5 gallon (.1.9 litre) liquid coffee bibs and

two 8-pound (3.63kg) hoppers

• Bib size: 5” w x 9.25” H x 4.875” D (12.7cm W x 23.5cm H x 12.4cm D)

• Global multi-volt design is easily converted to ratings from 100 to 240 volts

(50-60 hertz) eliminating the need to inventory multiple electrical conﬁgurations

• Set up for portion-control to ﬁll cups with a 7.25” (18.4cm) cup clearance

• Serves seven set drinks, all in a 19.7” (50cm) footprint

• Four gallon (15.14 litre) hot water tank

• Front of machine access for easy machine set up, calibration and service

• Spring loaded auger drive system for easy hopper installation

• Key lock on door prevents tampering

3/16” Replacement Tube Kit

Product No.: 39329.1000

Adapter Tube Package

Product No.: 37500.0201

8” Adjustable Legs

Product No.: 00506.0000

A6.7

BUNN®practices continuous product research and improvement. We reserve the right to change speciﬁcations and product design without notice. Such

revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.

All dimensions shown in inches.

Dimensions & Speciﬁcations

Bunn-O-Matic®Corporation - 1400 Stevenson Drive Springﬁeld, Illinois 62703 • 800-637-8606 • 217-529-6601 • Fax 217-529-6644 • www.bunn.com

Model Product Dispense Rate Volts Amps Total Capacity* Cubic Shipping Cord

Number 1.7 oz. (.05L) Watts Measure Weight Attached

Product Ratios†

SLCA-7 38900.0305 20:1 - 50:1 120 15 1800 43 cups/hr. 10.9 ft3140 lbs. Yes

208 23.7 5000 385 cups/hr. .31 M363.5 kg No

240 23.7 5800 512 cups/hr. No

†Other ratios may be available based on tube options. Please contact your BUNN Sales Representative.

*Capacity measured with a 12 oz. (.35L) cup.

Power cord (NEMA 5-15P) 15 Amp-120V machine only. (30 Amp cord and plug needed for 208V and 240V models)

Electrical: 120V requires 2-wires plus ground service rated 120V, single phase, 60 Hz.

Plumbing: 20-100 psi (138-689 kPa) from a 1/4" or larger supply line. Unit requires a 1 gpm (3.79 lpm) line ﬂow capacity. A shut-off

valve should be installed in the line before the unit. Install a regulator in line when pressure is greater than 100 psi

(689 kPa) to reduce pressure to 50 psi (344 kPa). Supplied with 1/4" male ﬂare ﬁtting.

01/14 © Bunn-O-Matic Corporation
