BUNN

ILLUSTRATED PARTS CATALOG

Designs, materials, weights, specifications, and dimensions for equipment or replacement parts

are subject to change without notice.

BUNN-O-MATIC CORPORATION

POST OFFICE BOX 3227

SPRINGFIELD, ILLINOIS 62708-3227

PHONE: (217) 529-6601 FAX: (217) 529-6644

FMD-2

FMD-3

(prior to S/N FMD0013000)

HOT

LIQUID

RELEASE BUTTON WHEN CUP IS 2/3 FULL

PLACE

CUPHEREPLACE

CUPHERE

PLACE

CUPHERE

!WARNING

PUSHandHOLDBUTTONUNTIL CUPIS 2/3 FULL, THENRELEASE

WARRANTY

Bunn-O-MaticCorp.(“Bunn”)warrantstheequipmentmanufacturedbyittobecommerciallyfreefromdefects

in material and workmanship existing at the time of manufacture and appearing within one year from the date of

installation. In addition:

1.)Bunnwarrantselectroniccircuitand/orcontrolboardstobecommerciallyfreefromdefectsinmaterialand

workmanship for two years from the date of installation.

2.)Bunnwarrantsthecompressoronrefrigerationequipmenttobecommerciallyfreefromdefectsinmaterial

and workmanship for two years from the date of installation.

3.)Bunnwarrantsthatthegrindingburrsoncoffeegrindingequipmentwillgrindcoffeetomeetoriginalfactory

screensieveanalysisforthreeyearsfromdateofinstallationorfor30,000poundsofcoffee,whichevercomesfirst.

Thiswarrantydoesnotapplytoanyequipment,componentorpartthatwasnotmanufacturedbyBunnorthat,

inBunn’sjudgement,hasbeenaffectedbymisuse,neglect,alteration,improperinstallationoroperation,improper

maintenance or repair, damage or casualty.

THE FOREGOING WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY OTHER WARRANTY, WRITTEN OR

ORAL, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF EITHER

MERCHANTABILITYORFITNESS FORAPARTICULARPURPOSE. Theagents,dealersoremployeesofBunnare

not authorized to make modifications to this warranty or to make additional warranties that are binding on Bunn.

Accordingly,statementsbysuchindividuals,whetheroralorwritten,donotconstitutewarrantiesandshouldnot

be relied upon.

The Buyer shall give Bunn prompt notice of any claim to be made under this warranty by telephone at (217)

529-6601orbywritingtoPostOfficeBox3227,Springfield,Illinois,62708-3227.IfrequestedbyBunn,theBuyer

shall ship the defective equipment prepaid to an authorized Bunn service location. If Bunn determines, in its sole

discretion,that the equipmentdoesnot conformtothe warranty, Bunnshallrepair theequipmentwithno charge

forpartsduringthewarrantyperiodandno charge for labor by a Bunn Authorized Service Representative during

the warranty period. If Bunn determines that repair is not feasible, Bunn shall, at its sole option, replace the

equipment or refund the purchase price for the equipment.

THEBUYER’SREMEDYAGAINSTBUNNFORTHEBREACHOFANYOBLIGATIONARISINGOUTOFTHESALE

OF THIS EQUIPMENT, WHETHER DERIVED FROM WARRANTY OR OTHERWISE, SHALL BE LIMITED, AS

SPECIFIED HEREIN, TO REPAIR OR, AT BUNN’S SOLE OPTION, REPLACEMENT OR REFUND.

InnoeventshallBunnbeliableforanyotherdamageorloss,including,butnotlimitedto,lostprofits,lostsales,

loss of use of equipment, claims of Buyer’s customers, cost of capital, cost of down time, cost of substitute

equipment, facilities or services, or any other special, incidental or consequential damages.

28365 051200

TABLE OF CONTENTS

TITLE PAGENO.

Auger Drive and Hopper Assembly..............................................................................................................................................10

Covers, Panels and Drip Tray.........................................................................................................................................................4

Dispense Valves and Lines ..........................................................................................................................................................18

Door, Lamp, Dispense Switches and Panels..................................................................................................................................8

Electrical Controls........................................................................................................................................................................20

Mixing/Whipper Chambers and Drive Motor ...............................................................................................................................12

Numerical Index ..........................................................................................................................................................................24

Strainer, Solenoid, Fill Valve and Lines ........................................................................................................................................16

Tank, Heater and Overflow Protection..........................................................................................................................................14

328365 051200

BUNN

®FMD-2

FMD-3

COVERS, PANELS AND DRIP TRAY

RED/WHI

FLUORESCENT

LAMP

BALLAST

SOL

DISPENSE

WHIPPER

HOPPER

RUN/RINSESWITCH

WHI

WHI WHI REDWHI/RED

WHI

WHI/RED

SOL

LEFTDISPENSE

RIGHTWHIPPER

RIGHTHOPPER

SOL

RIGHTDISPENSE

LEFTWHIPPER

LEFTHOPPER

CENTERHOPPER

CENTERWHIPPER

SOL

CENTERDISPENSE

WHI

WHI/VIOWHI/VIOWHI/VIO WHI

WHI

ORAORAORA

RED

WHI/VIO

ORA

WHI

TAN

WHI/VIO

ORA

RED

WHI

TAN

WHI

RED

JUMPERPLUGMUSTBE

USEDWHENCOLD

DRINKFEATURENOT

INSTALLED

RED

SOL

HOT/COLDSWITCH

WHI/YEL

RED

TAN

WHI

COLDDRINKOPTION(LEFT ONLY)

BLK-16

120VOLTSA C - 2 WIRE OR

120/208-240VOLTSAC - 3WIRE

SINGLEPHASE, 60HZ

SCHEMATICWIRING DIAGRAM PDS-1,PDS-2,& PDS-3

GRN

L1 NL2

LIMIT

THERMOSTAT

BLK-16

TANKHEATER

RED-16(3-WIRE MODELS)

WHI-16(2-WIRE MODELS)

BLK-16

SOL

TANKINLET

BLK

WHI

BLU

PROBE

LIQUID

LEVEL

BOARD

VIO

WHI

PNK-20

RED RED

OVERFLOWSWITCH

FAN

HEATERSW.

THERMOSTAT

BLK-16

BLK

RED

WHI/VIO

ORA

WHI

HOPPER

DELAY

BLK WHI WHI

WHI

BLK

WHI

RED

BLU

STARTER

BLK

BLU RED

RED/BLK

BLK

RED

BLK

RED

RED/BLK

RED/WHI

BLU

WHI

BLK

WHI

DISPENSESWITCH

(RIGHT,MODELSPDS-2& PDS-3)

DISPENSESWITCH

(CENTER,MODELPDS-3ONLY)

DISPENSESWITCH

(LEFT,MODELSPDS-2& PDS-3)

(ALSOPDS-1 SWITCH)

BLK

141

PDS1Components

PDS2&PDS3Components

(CENTERCOMPONENTSELIMINATEDONPDS-2)

GRY

GRY WHI

GRY

CHASSIS

DOOR

GRN

200°F190°F180°F

HOT

LIQUID

RELEASEBUTTONWHENCUPIS2/3FULL

PLACE

CUPHEREPLACE

CUPHERE

PLACE

CUPHERE

!WARNING

2 1 3

4 26 5

11 12 13 14 15

19 17 18 16

23 22 21 20

24 25

P1437.28

28365 051200

ITEM PART NO. QTY. DESCRIPTION

1 26504.0000 4 Hinge

02308.0000 12 Screw, Pan Head #8-32 x .375"

2 28299.0000 1 Cover, Top Rear - BLK

28671.0000 1 Cover, Top Rear - SST

02308.0000 2 Screw, Pan Head #8-32 x .375"

3 28204.0000 1 Cover, Top Front - BLK

28670.0000 1 Cover, Top Front - SST

4 28209.1000 1 Housing W/Decals - BLK (Includes items 24 & 25)

28661.1000 1 Housing W/Decals - SST (Includes items 24 & 25)

5 28269.0001 1 Panel, Right

01311.0001 4 Screw, Truss Head - Locking #8-32 x .25"

6 28270.0000 1 Panel, Whipper Motor Mounting (Also order items 7, 8, 9 - dispensers w/out cold

water option & 28 dispensers w/cold water option)

00991.0000 6 Nut, Elastic Lock #8-32

7 26524.0000 1 Decal, Tank Heater Switch

8 26523.0000 1 Decal, Rinse/Run Switch

9 00619.0010 1 Plug, Hole .437" Dia (Not used on dispensers w/cold water option)

10 -------------- 2 Gasket, Foam W/Adhesive 10.1" LG (Order item 29)

11 28283.0000 1 Panel, Lower Front Access

01311.0000 2 Screw, Truss Head #8-32 x .25"

12 28436.0000 1 Panel W/Decal, Splash (Includes item 13)(FMD-3 Models)

28436.0001 1 Panel W/Decal, Splash (Includes item 13)(FMD-2 Models)

01311.0000 2 Screw, Truss Head #8-32 x .25"

13 28328.0000 1 Decal, Caution-Hot Liquid & Cup Placement (FMD-3 Models)(Shown)

28328.0003 1 Decal, Caution-Hot Liquid & Cup Placement (FMD-2 Models)

14 28267.0000 1 Cover, Drip Tray

15 28268.0000 1 Drip Tray Assembly

16 28269.0000 1 Panel, Left

01311.0001 4 Screw, Truss Head - Locking #8-32 x .25"

17 26528.0000 4 Leg, 4.0" Adjustable (Also see item 30)

18 03996.0000 4 Pad, Rubber 1.25" Dia. (Also see item 30)

19 23164.0002 1 Plug, Hole 1.50" Dia. - BLK

00619.0011 1 Plug, Hole 1.50" Dia - SST

20 28206.0000 1 Cover, Left Side Access - BLK (Also order item 21)

28668.0000 1 Cover, Left Side Access - SST (Also order item 21)

01311.0003 2 Screw, Truss Head - BLK #8-32 x .25"

01311.0000 2 Screw, Truss Head - SST #8-32 x .25"

21 28368.0000 1 Decal, Thermostat Adjustment

COVERS, PANELS AND DRIP TRAY

(Continued)

28365 051200

BUNN

®FMD-2

FMD-3

COVERS, PANELS AND DRIP TRAY

(Continued)

RED/WHI

FLUORESCENT

LAMP

BALLAST

SOL

DISPENSE

WHIPPER

HOPPER

RUN/RINSESWITCH

WHI

WHI WHI REDWHI/RED

WHI

WHI/RED

SOL

LEFTDISPENSE

RIGHTWHIPPER

RIGHTHOPPER

SOL

RIGHTDISPENSE

LEFTWHIPPER

LEFTHOPPER

CENTERHOPPER

CENTERWHIPPER

SOL

CENTERDISPENSE

WHI

WHI/VIOWHI/VIOWHI/VIO WHI

WHI

ORAORAORA

RED

WHI/VIO

ORA

WHI

TAN

WHI/VIO

ORA

RED

WHI

TAN

WHI

RED

JUMPERPLUGMUSTBE

USEDWHENCOLD

DRINKFEATURENOT

INSTALLED

RED

SOL

HOT/COLDSWITCH

WHI/YEL

RED

TAN

WHI

COLDDRINKOPTION(LEFT ONLY)

BLK-16

120VOLTSA C - 2 WIRE OR

120/208-240VOLTSAC - 3WIRE

SINGLEPHASE, 60HZ

SCHEMATICWIRING DIAGRAM PDS-1,PDS-2,& PDS-3

GRN

L1 NL2

LIMIT

THERMOSTAT

BLK-16

TANKHEATER

RED-16(3-WIRE MODELS)

WHI-16(2-WIRE MODELS)

BLK-16

SOL

TANKINLET

BLK

WHI

BLU

PROBE

LIQUID

LEVEL

BOARD

VIO

WHI

PNK-20

RED RED

OVERFLOWSWITCH

FAN

HEATERSW.

THERMOSTAT

BLK-16

BLK

RED

WHI/VIO

ORA

WHI

HOPPER

DELAY

BLK WHI WHI

WHI

BLK

WHI

RED

BLU

STARTER

BLK

BLU RED

RED/BLK

BLK

RED

BLK

RED

RED/BLK

RED/WHI

BLU

WHI

BLK

WHI

DISPENSESWITCH

(RIGHT,MODELSPDS-2& PDS-3)

DISPENSESWITCH

(CENTER,MODELPDS-3ONLY)

DISPENSESWITCH

(LEFT,MODELSPDS-2& PDS-3)

(ALSOPDS-1 SWITCH)

BLK

141

PDS1Components

PDS2&PDS3Components

(CENTERCOMPONENTSELIMINATEDONPDS-2)

GRY

GRY WHI

GRY

CHASSIS

DOOR

GRN

200°F190°F180°F

HOT

LIQUID

RELEASEBUTTONWHENCUPIS2/3FULL

PLACE

CUPHEREPLACE

CUPHERE

PLACE

CUPHERE

!WARNING

2 1 3

4 26 5

11 12 13 14 15

19 17 18 16

23 22 21 20

24 25

P1437.28

28365 051200

ITEM PART NO. QTY. DESCRIPTION

COVERS, PANELS AND DRIP TRAY

22 28435.0000 1 Cover, Rear Access - BLK (Includes item 23)

28684.0000 1 Cover, Rear Access - SST (Includes item 23)

01311.0003 2 Screw, Truss Head - BLK #8-32 x .25"

01311.0000 2 Screw, Truss Head - SST #8-32 x .25"

23 28341.0000 1 Schematic, 120V, 120/208V & 120/240V

24 00831.0000 1 Decal, Warning-Electrical

25 00656.0000 1 Decal, Comply to Plumbing Code

26 21436.0000 2 Catch, Magnetic

27 01311.0001 4 Screw, Truss Head - Locking #8-32 x .375"

28 26522.0000 1 Decal - HOT/COLD (Models w/cold water option)

29 28366.1000 - Gasket, Foam W/Adhesive - 12" LG

28366.1001 - Gasket, Foam W/Adhesive - 36" LG

28366.1002 - Gasket, Foam W/Adhesive - 120" LG

30 13255.0003 - Kit, Leg 4.0" Adjustable (Includes 4 each of items 17 & 18)

Not

Illustrated

28365 051200

BUNN

®FMD-2

FMD-3

DOOR, LAMP, DISPENSE SWITCHES AND PANELS

PUSH and HOLD BUTTON UNTIL CUP IS 2/3 FULL, THEN RELEASE

14 15 10 13 12

1 2 3 4 5

9 13 6

P1438.40

28365 051200

ITEM PART NO. QTY. DESCRIPTION

1 28147.1000 1 Door W/Decal (Includes items 2 and 18)(FMD-3 Models)

28147.1002 1 Door W/Decal (Includes items 2 and 18)(FMD-2 Models)

01390.0000 4 Screw, Round Head #8-32 x .625"

01522.0000 4 Washer, Flat .203 I.D. x .50 O.D."

00991.0000 4 Nut, Elastic Stop #8-32

2 28301.0000 1 Decal, Door Front (FMD-3 Models)

28301.0002 1 Decal, Door Front (FMD-2 Models)

3 28284.0001 1 Window, Door - Inside

02336.0000 2 Screw, Truss Head #4-40 x .375"

4 28362.0000 1 Display, Graphics (Cafe Scene)

5 28284.0000 1 Window, Door - Outside

6 -------------- 1 Hinge, Door (See Covers, Panels and Drip Tray)

7 26892.0000 1 Plate, Strain Relief

8 26444.0000 2 Bushing, Strain Relief

9 28325.0000 1 Socket W/Terminals, Starter

10 27619.0000 1 Starter, Lamp

11 28261.0000 1 Panel, Door - Lower

01383.0001 5 Screw, Pan Head #6-32 x .375"

12 26239.0000 1 Lamp, Fluorescent - 8 Watts

13 28322.0000 2 Lamp Holder, Fluorescent

02328.0002 2 Screw, Pan Head #6 - 32 x .188"

14 28332.1000 1 Panel W/Decal, Door - Upper (Includes item 15)

01383.0001 5 Screw, Truss Head #6 - 32 x .25"

15 28370.0000 1 Decal, Cleaning

16 28335.0000 2 Clip, Ground

17 28296.0000 3 Switch Assembly, Dispense (One less used on FMD-2 Models)

18 27298.0000 1 Striker Assy.

19 21004.0192 1 Lead, Electrical 18AWG Green - 11.5" Lg

20 28338.0000 1 Wiring Harness, Door Interconnect 120V (Includes item 7 & 1 of item 8)

21 28336.0000 1 Wiring Harness, Door 120V

22 26537.0000 1 Decal, Flavors (Almond Amaretto, Cappuccino, French Vanilla,

Hazelnut, Hot Chocolate and Raspberry Mocha)

26537.0001 1 Decal, Flavors (Swiss Mocha, Mocha, Raspberry Vanilla,

Irish Creme, Coffee and Original)

26537.0003 1 Decal, Flavors (White Chocolate, Cinnamon Vanilla Nut, Decaf,

Regular, French Vanilla and Hot Chocolate)

26537.0007 1 Decal, Flavors (Fat Free French Vanilla, Cinnamon Vanilla, Cinnamon

Vanilla Nut, English Toffee, Hot Chocolate and Apple Cider)

DOOR, LAMP, DISPENSE SWITCHES AND PANELS

Not

illustrated

28365 051200

BUNN

®FMD-2

FMD-3

AUGER DRIVE AND HOPPER ASSEMBLY

P1439.40
