Buffalo CloudStation CS-X Manual de usuario

User Manual

CloudStation

CS-X, CS-WX, and CS-WV

www.buffalotech.com v2.8

™

Introduction

Thank you for purchasing the Buffalo CloudStation. This simple device gives you the

exibility of cloud-based storage without the worries that come with storing your important

data on someone else’s servers. Using Pogoplug software, CloudStation lets you serve up

les, photos, and multimedia over the Web to any of your devices, wherever you may be.

Turn to page 4 to set up your CloudStation.

Because we’re constantly updating our products, the images and text in this manual may

vary slightly from the images and text displayed by your CloudStation. As time passes,

future user interfaces, updated software, and later versions of this manual may be available

for download from www.buffalotech.com. For more information on CloudStation, see

buffalocloudstation.com.

Table of Contents

Introduction

Setup 4

Diagrams and Layout (CS-WX & CS-WV) 7

Power Mode Switch 10

Diagrams and Layout (CS-X) 11

Using your CloudStation

Uploading 14

Downloading 15

Pogoplug Applications 16

Sharing 17

Search 19

Slideshows 20

Creating New Folders 21

Renaming Files and Folders 22

Renaming Devices 23

Active Copy 24

Settings and Conguration

General Settings 25

Social Settings 26

Media Settings 28

Security Settings 29

Upload Settings 30

Adding a Printer 31

Device Settings 34

Local Settings 35

Adding a Second Drive 38

Time Machine 40

BitTorrent Client 41

Direct Copy 43

Troubleshooting

Status LED Flash Codes 45

Appendix

Specications (CS-WX & CS-WV) 47

Specications (CS-X) 48

Contact Information (USA) 49

Contact Information (Europe) 50

GPL Information 51

Open a browser window on your computer and go to https://cloudstation.pogoplug.com/. Click

Set Up Your CloudStation.

Plug one end of the included Ethernet cable into the Ethernet port on your CloudStation and the

other end into any available LAN port on your router.

In the browser window, click Next.

Setup

USB

FUNCTION

AUTO

OFF

DC-IN

LAN

WAN

LAN LAN

Now, plug your CloudStation into a surge protector, wall socket, or power strip.

Move the power mode switch on the back of the unit to the on (middle) position. The blue power

LED will begin to blink.

Wait for the CloudStation to boot. This will take about 5 minutes. When the power LED on the

front panel stops blinking and glows steadily, the unit has nished booting. The info/error LED

should not be blinking. If it is, turn to the next page to troubleshoot.

In the browser window, click Next. Follow the instructions on the screen to nish installing your

CloudStation.

USB

FUNCTION

AUTO

OFF

DC-IN

LAN

If you’ve connected your CloudStation to a power source and to a router, but the info/error LED

is ashing amber or your CloudStation suddenly turned off by itself, here are some things you

can check:

Is the power mode switch on the back of the CloudStation (CS-WX and CS-WV models only) in

the On position? If it’s in the Auto (top) position, the CloudStation may suddenly shut down

after a few minutes. Move it to the On (bottom) position until you’ve installed NAS Navigator

software on your computers.

Is the amber info/error LED on the front of your CloudStation (CS-WX and CS-WV models only)

ashing? Check the following:

Is the Ethernet cable connected to your CloudStation and to your router?

Is your router turned on?

Is your router congured to automatically assign IP addresses (DHCP)?

Do you have a rewall installed that blocks UDP, or is UDP disabled on your router?

If you have veried all of the above and the info/error LED on the front of your CloudStation is

still ashing, please move the power mode switch to the Off position, wait until the power LED

turns off, and then move it back to the On position. It will take about ve minutes to boot.

If you continue to have problems, please contact tech support. Tech support contact

information is available on pages 49 and 50.

Troubleshooting

Back Panel Layout

Front (CS-WX and CS-WV)

Power LED

Function LED

Info/Error LED

Front Cover

(pull the left

side straight

toward you to

remove)

Back Panel Layout

Front Panel Removed (CS-WX and CS-WV)

Second hard

drive

Main hard drive

Press tab to

release drive

Front Panel Layout

Rear (CS-WX and CS-WV)

Function Button

USB

Fan

Auto Power

Power On

Power Off

Ethernet

(to router)

Power

Socket for

Kensington-style lock

Power cord

stress relief

The “Power Mode” switch on the back of the

unit has three positions: Auto, On, and Off.

The Auto position automatically powers the

unit on or off with your PC. If your PC is turned

on the CloudStation will power up; if the PC is

turned off the CloudStation will power down.

You must have installed the NAS Navigator

software (available from www.buffalotech.com)

on your PC for this feature to work. Otherwise,

if you move the switch to Auto, your unit will

power down by itself and you will have to

manually turn it back on.

Move the switch to the On (middle) position to

have the CloudStation turn on and stay on.

To turn off the CloudStation, move the switch

to the Off position. It will take several minutes

to fully shut down. Do not unplug the unit

until shutdown is complete and the power LED

is no longer lit.

Power Mode Switch (CS-WX and CS-WV)

Power

Mode
