BTSX BIT-VWC-409R Manual de usuario
深圳市比特视讯有限公司
第1页 共 19 页
CATALOG
1. Product Overview.......................................................................................................... 2
1.1. Product features..................................................................................................... 2
1.2. Application scenarios............................................................................................3
2. Specifications.................................................................................................................. 3
3.Operation instructions.................................................................................................. 5
3.1. Product panel description................................................................................5
3.2. Remote control function description............................................................. 8
3.3. Product connection diagram...........................................................................14
3.4. Definition of rows and columns.....................................................................15
3.5. Supported resolution......................................................................................... 16
4. Common problems..................................................................................................... 17
5. Appendix........................................................................................................................ 18
5.1 Appendix 1: Arrangement of output interface..........................................18
深圳市比特视讯有限公司
BIT-VWC-409R
深圳市比特视讯有限公司
第2页 共 19 页
1. Product Overview
1.1. Product features
BIT-V409R is an ultra HD Rotary Splicer by Shenzhen Bitvisus Technology Limited.
Support 4 channels HDMI input (1 channel 4K@60Hz, 3 channels 4K@60Hz), 1
channel DP input (4K@60Hz), 9 channels output HDMI (1080p@60Hz), 1 channel
DP loop out.
A single device, 5 inputs and 9 outputs(Compatible with 1 in 9 out), can be
combined in any number of splicing modes: horizontal screen / vertical screen /
2X2, and support large scale parallel operation in the form of loop out.
It can open 4 windows on the whole screen at most, and supports multiple window
opening modes（Single screen、PIP double screen、double screen、Four picture
segmentation）
The input supports a maximum of 3840x2160@ 60Hz and is backward compatible.
The maximum single output supports 1920x1080 @ 60Hz.
The input supports full screen rotation of 90 °(only supported in single-picture
mode), and the output supports 180 ° rotation of the first line (only supported
when the stitching mode is two lines).
no stretching, no deformation, no need to compress the input source, the picture is
clear.
深圳市比特视讯有限公司
第3页 共 19 页
Support single display mode (1x1).
Support infrared remote control, serial RS232 control.
Low power consumption, energy saving and environmental protection. Conductive
heat dissipation is used internally without any external heat dissipation measures,
and the reliability is extremely high.
Support Computers, Android boxs, game consoles and other devices as input
source.
Using 40nm high-end programmable FPGA chip, full hardware real-time
processing architecture, ultra-fast processing speed without delay.
1.2. Application scenarios
It is mainly used in industrial applications such as ultra-high-definition video
surveillance, large screen walls, large advertising screens in stores, and large
screens for exhibitions.
2. Specifications
Product name
BIT-VWC-409R
Input Max. Pixel FPS
600MHz
Input supports the highest resolution
3840*2160@60Hz
DP signal
Display port 1.2*1
深圳市比特视讯有限公司
第4页 共 19 页
HDMI signal
HDMI 2.0*1,，HDMI 1.4 *3
Output Max. Pixel FPS
165MHz
Output single screen support resolution
1920*1080@60Hz
HDMI output interface
HDMI 1.3 * 9
Loop out signal
Display port 1.2*1
Audio output
3.5mm Headphone
Control method
Remote control, RS232 serial port (can be
looped out)
Factory default resolution
HDMI：3840*2160@60Hz
DP：3840*2160@60Hz
Support custom resolution
Yes
Operating temperature
0℃-50℃
Power consumption
12W
Power supply
12V@2A AC-DC
Weight
840g
Size
270mm * 122.5mm * 20mm
Annex
One DP Cable
One 12V@2A AC-DC
One remote control
Power Supply
12V@2A AC-DC
Warranty
One year
深圳市比特视讯有限公司
第5页 共 19 页
3.Operation instructions
3.1. Product panel description
BIT_V409R front panel
A: Industrial seat, RS232 control loop out, used in cascade mode to loop out RS232
commands to the next device.
B：Network interface, TCP network protocol, is used for the control system to issue
instructions to control the device.
C：Industrial seat, used for RS232 control, used to issue RS232 commands.
D ： Dip switch (Board id): indicates the ID of the current device in cascade
mode.V406 does not support this function, only V409 supports it.
E：IR is used for receiving remote control signals,Need external IR receiver.
F, G, H，I: 4 HDMI input ports, of which I port is 4K60, F/G/H port is 4K30, suitable
for graphics card output on PC host or other devices. There is an LED light next to
深圳市比特视讯有限公司
第6页 共 19 页
each HDMI interface. The light indicates that the HDMI interface has a signal input.
J: 1 DP input interface, 4K60 input, suitable for graphics card output on PC host or
other devices.
K: Audio output interface, used for audio output devices: earphones, etc.
L: DP ring output interface, when multiple devices are cascaded,It acts as a DP
input source for other devices or displays. The LED light (loop) next to the interface
indicates that there is a loop-out signal output.
(In single-screen mode, the loop-out follows the selection of the input source
channel to switch. In non-single-screen mode, only the loop-out DP signal is
supported).
M: Power switch
BIT_V409R rear panel
A: Power interface, connect to 12V@2AAC-DC power supply.
O: LED light (power) next to the interface.It is a power indicator. The LED lights
when the device is normally powered.
P: Connect the light, which means the video signal is connected normally.
B, C, D, E, F, G, H, I, J: 9 HDMI output interfaces, used to connect display devices
such as monitors, televisions or monitors. There is an LED next to each HDMI
深圳市比特视讯有限公司
第7页 共 19 页
interface.The light is on, indicating that there is a signal output from the HDMI
interface.
Note 1: DIP switch,when cascading, it indicates the ID number of the current device,
which is set in binary.
ID number
Binary
ID number
Binary
Device 1
1000
Device 9
1001
Device 2
0100
Device 10
0101
Device 3
1100
Device 11
1101
Device 4
0010
Device 12
0011
Device 5
1010
Device 13
1011
Device 6
0110
Device 14
0111
Device 7
1110
Device 15
1111
Device 8
0001
深圳市比特视讯有限公司
第8页 共 19 页
3.2. Remote control function description
Remote control panel
Remote control panel description(In the case of outputting a complete image,
explain the keys)
[Full screen] The output screen, put together as a whole:
Remote
button
Features
Ent
Confirm key
深圳市比特视讯有限公司
第9页 共 19 页
Esc
Escape key
Row
Set splicing mode: row (range: 1-16)
Col
Set splicing mode: column (range: 1-16)
Win
window：The number of each screen (window) in "whole screen"，See Note 1 at the
end of the form for details.
Src
source：Enter the number of the source, 1 for HDMI, 2 for DP.
+
Cooperation【 ↔ ↕ Zoom] to realize the function of "move left / right / zoom in /
zoom out" of small window in picture
-
Cooperation【 ↔ ↕ Zoom] to realize the function of "move left / right / zoom in /
zoom out" of small window in picture
↔ ↕ zoom
Picture in picture
Small window move left and right menu --- small window move up and down
menu --- small window zoom in and out menu
Four picture
（select the input source displayed on the screen through the [Win / Src] button）
Double screen：left and right -- > up and down
（select the input source displayed on the screen through the [Win / Src] button）
Single screen rotation
HDMI①--->HDMI②--->HDMI③--->HDMI④--->DP⑤
R90ᵒ
Rotate the whole input image 90 ° (only in the case of single image)
深圳市比特视讯有限公司
第10 页 共 19 页
R180ᵒ
First line output image rotated 180 ° (only in case of 2 lines)
Clone
Clone mode: copy display (1x1) for each output port
Note 1:
[win] key meaning: window, the number of each screen (window) in the "whole
screen", the corresponding screen position is as follows.
Single screen mode: there is only one screen, and the value is fixed as number 1, as
shown below.
Double picture(picture in picture mode): The face value of the large picture is No. 1,
and the value of the small picture is No. 2, as shown in the following figure.
Double picture(Left right mode): The left screen value is No. 1, and the right screen
value is No. 2, as shown below.
Double picture(Up down mode): The upper screen value is No. 1, and the lower
screen value is No. 2, as shown below.
