Bticino 391782 Manual de usuario
391782
1,3 Megapixel bullet camera
with IR LED
User Manual
LE05643AA-01CB-12W40
EN
2
Indice
1 General Introduction ......................................................................................................................................................................................................3
1.1 Accessories..............................................................................................................................................................................................................3
1.2 Features.....................................................................................................................................................................................................................3
1.3 Specifications..........................................................................................................................................................................................................4
1.3.1 Performance.......................................................................................................................................................................................................4
1.3.2 Factory Default Setup...................................................................................................................................................................................6
2 Framework....................................................................................................................................................................................................................... 11
2.1 Dimensions........................................................................................................................................................................................................... 11
3 Installation........................................................................................................................................................................................................................ 11
3.1 Device Installation............................................................................................................................................................................................. 11
4 Connecting to a device and opening the web application...................................................................................................................... 12
4.1 IE options configuration for config tool and and IE.......................................................................................................................... 12
4.1.1 Connection with the Search Tool......................................................................................................................................................... 12
4.1.2 Connection with Internet Explorer....................................................................................................................................................... 13
4.2 Connection with Mozilla Firefox or Google Chrome........................................................................................................................ 13
5 Quick Configuration Tool.......................................................................................................................................................................................... 14
5.1 Introduction........................................................................................................................................................................................................... 14
5.2 Searching/Connecting..................................................................................................................................................................................... 14
5.2.1 Connecting to the device’s web interface........................................................................................................................................ 14
5.3 Connecting with the configuration tool (to change the IP address or upgrade the device software..................... 16
5.4 Main interface of the tool............................................................................................................................................................................... 18
5.4.1 Network settings........................................................................................................................................................................................... 18
5.4.2 System Information..................................................................................................................................................................................... 18
5.4.3 System Upgrade........................................................................................................................................................................................... 19
6 Resetting the camera................................................................................................................................................................................................. 19
1,3 Megapixel bullet camera with IR LED
3
User Manual
1 General Introduction
1.1 Accessories
Accessory Name Amount
IP Camera 1
Accessories bag (screws and
installation template)
1
Quick Start guide 1
CD 1
1.2 Features
Functions features
User
Management
Different user rights for each group, one user belongs to one group.
The user right shall not exceed the group rights.
Storage
Function
Central server backup function in accordance with your configuration and setup in schedule
settings.
Record via Web and the recorded file are stored in the client-end PC.
FTP Network storage.
Alarm
Function
Real-time respond to video detect as user pre-defined activation setup and exert corresponding
message in screen and audio prompt.
Real-time video detect(motion detect, camera masking) shows message in screen and audio
prompt.
Generates an alarm when finds an abnormality in the system.
Network
Monitor
One-channel video data transmit to network terminal. Delay is 270ms (network bandwidth
support needed)
Max 20 connections.
Audio and video transmission protocol: HTTP, TCP, UDP, RTP/RTCP, RTSP and etc.
Web access.
Network
Management
Configuration and management via Ethernet.
Device management via web or client-end.
Various network protocols.
Power External power adapter DC12V
PoE 802.3af.
Assistant
Function
Log function
System resource information and running status real-time display.
Day/Night mode auto switch.
Backlight compensation: screen auto split to realize backlight compensation to adjust the bright.
Electronic shutter and gain setup.
Video watermark function.
4
1.3 Specifications
1.3.1 Performance
Parameters IP bullet ext
System
Main Processor TI Davinci high performance DSP
OS Embedded LINUX
System
Resources
Real-time network, local record, and remote operation at the same
time.
User Interface Remote operation interface such as WEB, VMS software
System Status Bit stream statistics, log, and software version.
Video Parameter
Image Sensor 1/3-inch COMS
Pixel 1280(H)*960(V)
Day/Night Mode Day/night mode switch.
Gain Control Fixed/Auto
White Balance Manual/Auto
BLC On/off
Electronic Shutter Manual/Auto (ranges from 1/3 to 1/10000).
Video Compression H264/ MJPEG
Video Frame Rate
Main stream（1280*960@15fps）/ extra stream（704*576@15fps）
or
Main stream（1280*720@25fps）/ extra
stream（704*576@25fps）
Video Bit Rate
H.264: 64-6144Kbps.
MJPEG: 64-10240Kbps.
The bitrate is adjustable.
Video Flip Mirror function.
Flip function.
Snapshot Max 1f/s snapshot (JPEG).
Privacy Mask Max 4 privacy mask zones
Video Setup Parameter setup such as bright, contrast.
Video Information Channel title, time title, motion detect, privacy mask.
Lens 3,6mm Megapixel
Lens Interface M12. Lens
1,3 Megapixel bullet camera with IR LED
5
User Manual
Parameters Tc IP comp ext
Video
Motion Detect
396 (18*22) detection zones: sensitivity level ranges from 1 to 6 (The
6th level has the highest sensitivity)
Activation event: Video storage, image snapshot, log, email, etc.
Video Loss Activation event: Video storage, image snapshot, log, email etc.
Record /
Backup
Record Priority Manual> Video detect>Schedule
Local Storage N/A
Network
Network 1-channel wire Ethernet port, 10/100 Base-T Ethernet
Network Protocol Standard HTTP, TCP/IP, IPv4/IPv6, ARP, IGMP, ICMP, RTSP, RTP, UDP,
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour, SNMP.
Platform interface Standard ONVIF
Remote Operation Monitor, system setup, log information, maintenance , upgrade etc
AUX
Reset Built-in RESET button
IR light 30 LED IR light 20m
General Parameter
Power Support DC12V and PoE 802.5af.
Power Consumption 6W MAX
Working Temperature -10
℃
~+50
℃
Working Humidify 10%~90%
Dimensions(mm) 62.9x64.3x146.8
Weight 370G
Installation Wall mount
6
1.3.2 Factory Default Setup
Function Setup
Type Item Default Settings
Camera Setup
Properties
Brightness 50
Contrast 50
Hue 50
Saturation 50
Gain Mode Auto
Gain Max 80
Exposure Mode Auto
Scene Mode Auto
Day/night mode Auto
BLC Off
Mirror Disable
Flip Disable
Video
Video Main stream
Code
-
Stream T
ype
General
Encode M
ode
H.264B
Resolution 720P（1280*720）
Frame Rate（FPS）PAL: 25
NTSC:30
Bit Rate T
ype
CBR
Reference B
it
R
ate
1536-6144Kb/s
Bit R
ate
4096
I frame I
nterval
50
Watermark S
et
tings
Enable
Watermark
character DigitalCCTV
1,3 Megapixel bullet camera with IR LED
7
User Manual
Function Setup
Type Item Default Settings
Camera Setup
Video
Video Extra stream
Enable
Enable
Code
-
Stream T
ype
General
Encode M
ode
H.264B
Resolution
CIF(352×288/352×240)
Frame Rate（FPS）PAL: 25
NTSC:30
Bit R
ate
T
ype
CBR
Reference Bit R
ate
192-1024Kb/S
Bit
R
ate
1024
I
frame
I
nterval
50
Snapshot
Snapshot Type General Snap
Image Size 720P（1280*720）
Q
uality
5
Interval
1picture/s
Overlay
Privacy M
ask
Disable
Channel T
itle
Enable
Time T
itle
Enable
Path
Snap
shot
path
C:\PictureDownload
Record path
C:\RecordDownload
Network setup
TCP/IP
Host Name IPC
Ethernet Card Wire (Default)
Mode Static
MAC address
Depends on the device
IP version IPV4 and IPv6
IP address 192.168.1.108
Subnet mask 255.255.255.0
Default gateway 192.168.1.1
Preferred DNS 8.8.8.8
Alternate DNS 8.8.8.8
Enable ARP/Pingto
to set IP address
service
Enable
8
Function Setup
Type Item Default Settings
Network setup
Connection
Max connection 10
TCP port 37777
UDP port 37778
HTTP port 80
RTSP port 554
PPPoE
Enable Disable
User Name N/A
Password N/A
DDNS
Server Type Disable, CN99 DDNS
Server IP none
Port 80
Domain Name none
User Name none
Password N/A
Update Period 5m
IP filter Trusted Sites Disable
SMTP（email）
SMTP Server none
Port 25
Anonymity Disable
User name anonymity
Password N/A
Sender none
Authentication
(Encrypt mode) N/A
Title (Subject) IPC Message
Main Receiver N/A
Interval 0s
Health Mail Disable，interval=60m
UPnP Enable UPnP Disable
SNMP
SNMP v1 Disable
SNMP v2 Disable
SNMP port 161
Read community public
Write community private
Trap address N/A
Trap port 162
1,3 Megapixel bullet camera with IR LED
9
User Manual
Function Setup
Type Item Default Settings
Bonjour Enable Enable
Server name
Depends on the device.
Multicast Multicast address 239.255.42.42
Port 36666
QoS Real-time monitor 0
Command 0
Event management
Video detect
Motion
Detect
Enable Disable
Anti-dither 5 seconds
Sensitivity 3
Record Channel Enable
Record Delay 10 seconds
Send Email Disable
Snapshot Disable
Video
Masking
Enable Disable
Record Channel Enable
Record Delay 10 seconds
Send Email Disable
Snapshot Disable
Abnormity
Disconnecti
on
Enable Disable
Record Enable
Record Delay 10s
IP Conflict
Enable Disable
Record Enable
Record Delay 10s
10
Function Setup
Type Item Default Settings
Storage management
Schedule
Record
Schedule To Set
Snapshot
Schedule To Set
Destination
(Storage )
Path :
Record
Snapshot
Timer Disable
Motion Detect Disable
Alarm Disable
FTP
FTP enable Disable
Server IP N/A
Port 21
User name anonymity
Password N/A
Record control
Pack duration 8m
Pre-record 5s
Disk Full Overwrite
Record Mode Auto
Main Stream Main Stream
System management
General setup
Local setup Device Name
Device factory SN
Language English
Date and
time
Date Format Y-M-D
Time Format 24H
Time Zone GMT+08:00
Current Time Sync PC
DST Disable
DTS type Week
Start time 00:00:00 of the first Sunday of the
month
End time 00:00:00 of the second Monday of
the month
Synchronize with
NTP Disable
NTP server clock.isc.org
Port 37
Update period 10m
Auto maintenance Auto reboot Enable
Auto delete old files Disable
