Bticino 344642 Manual de usuario

User manual

www.bticino.com

Classe 300X

344642 - 344643

RA00138AG-10/21-PC

Classe 300X

User manual

Classe 300X

User manual

Contents Your Classe 300X Video Internal Unit, use it now! 5

Answer a call 5

Listen to the video door entry answering machine 7

Auto-switching on and camera scrolling 10

Write or record a memo 12

Call another room or apartment (Intercom) 16

Disconnect a smartphone from the system 18

Dissociate a user from the system 20

General information 22

Function keys and status LEDs 22

Home page 23

Enabling functions 24

Quick actions 24

Function status 25

Call forward enabling to the smartphones 26

Enabling to all the smartphones 26

Block calls to all the smartphones 28

Functions 30

Functions 31

Answering machine 32

Cameras 36

NETATMO cameras 38

CCTV 39

Memo 41

Text memo 43

Audio memo 44

Intercom 45

Activations 47

Quick actions 48

Settings 49

General settings 50

Wi-Fi 50

Associated accounts 55

Time and date 57

Language 59

Information 60

Ringtones 61

Display 62

Clean monitor 62

Background 63

Calibration 63

Answering machine 64

Quick actions 66

Configuration 68

Compatible devices 69

Report a problem 72

Device reset 74

Wi-Fi reset 75

Menù installatore 76

Classe 300X

User manual

Services 77

Inductive loop 77

Door status 78

Office 79

Paging 80

Door Entry App 82

Introduction 82

Account registration 83

Authentication 86

Forgotten password 87

Account cancellation 89

Association of the device 90

Home page 92

Display the cameras or Entrance Panels 92

Open door locks 94

To receive a video door entry call 94

Call home: Call your Classe 300X 98

Menu 99

Answering machine 100

Activations 102

Users 103

Settings 106

Account 108

Help 111

Warnings and consumer rights 113

Quick guide

Classe 300X

User manual

544

Answer a call

1. Touch to answer the call, the LED comes on steady. To end the call touch the connection key

again.

2. If necessary, during the call touch the screen to display the audio/video adjustment icons.

3. Touch the icons and to adjust the parameters.

Your Classe 300X Video Internal Unit, use it now!

Note: audio and video adjustment are not available for NETATMO cameras.

Quick guide

Classe 300X

User manual

A. Adjust the volume.

B. Disable the microphone.

C. Adjust the image brightness.

D. Adjust the image contrast.

E. Adjust the image colour.

4. Touch to open the Entrance Panel door lock.

The door lock key lights up briefly, to indicate that the door lock has been released.

Quick guide

Classe 300X

User manual

1. Touch to enter the answering machine and display the message.

2. Touch to open the message.

When there are one or more unread messages in the answering machine, the home page that

opens when clicking the answering machine icon shows a numeric indication, and the memo LED

flashes.

Listen to the video door entry answering machine

Quick Actions

10:36

Tuesday, 22 April

Activations

Answering machine Cameras Memo

Settings

Intercom

Private camera

Lock

External intercom

Pager

Download the Door Entry App

Answering machine

22/10/2013

19:34

22/10/2013

16:30

22/10/2013

17:02

21/10/2013

11: 25

21/10/2013

15:00

20/10/2013

17:59

19/10/2013

14:20

15/10/2013

20:03

Back

Quick guide

Classe 300X

User manual

3. Touch to pause or restart playback.

The message is played back automatically

The message can be managed using the appropriate icons:

A. Adjust the volume.

B. Delete the message.

C. Beginning and end of message.

D. Return to the answering machine screen.

Back

Volume

22/10/2013

18:34

Back

Volume

22/10/2013

18:34

Quick guide

Classe 300X

User manual

the message status indication automatically switches to “read” , and the numeric indication

disappears from the home page

5. Touch to return to the home page.

Answering machine

22/10/2013

16:30

22/10/2013

17:02

21/10/2013

11: 25

21/10/2013

15:00

20/10/2013

17:59

19/10/2013

14:20

15/10/2013

20:03

Back

22/10/2013

18:34

Quick guide

Classe 300X

User manual

Auto-switching on and camera scrolling

1. Touch to display the cameras in your system.

2. The connection key flashes; touch this key to enable audio communication.

Any cameras installed in the system can be accessed using the dedicated section, or using the

automatic switching on key.

The corresponding key comes on and the display shows the images recorded by the camera of the

associated Entrance Panel.

For the camera adjustments see Answer a call.

Quick Actions

10:36

Tuesday, 22 April

Activations

Answering machine Cameras Memo

Settings

Intercom

Private camera

Lock

External intercom

Pager

Download the Door Entry App
