BTC BCE 4816IM Manual de usuario
CD-WRITER
4816IM
CD-ReWritable Drive
User’s Manual
CLASS 1 LASER PRODUCT
APPAREIL A LASER DE CLASSE 1
LASER KLASSE 1
LUOKAN 1 LASERLAITE
PRODUIT LASER
CATEGORIE 1
DANGER INVISIBLE LASER RADIATION WHEN OPEN AVOID DIRECT EXPOSURE TO
BEAM
VORSICHT INSICHTBARE LASERSTRAHLUNG WENN ABDECKUNG GEÖFFNET NICHT
DEM STRAHL AUSSETSEN
ATTENTION RADIATION DU FAISCEAU LASER INVISIBLE EN CAS D’OUVERTURE.
EVITER TOUTE EXPOSITION AUX RAYONS.
Copyright Statement
It is a criminal offence, under applicable copyright laws, to make unauthorised
copies of copyright-protected material, including computer programs, films,
broadcasts and sound recordings. This equipment should not be used for such
purposes.
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that
may cause undesired operation.
FCC Warning Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can emit radio frequency energy
and, if not installed or used in accordance with the instructions, may cause
interference to radio communications. However, television reception interference
can be determined by turning the equipment off and on. The user is encouraged to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet different from that to which the receiver
is connected
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FOR EUROPE
“The drive is in conformity with the EMC directive and low-voltage
directive.”
Table of Contents
INTRODUCTION 1
SYSTEM REQUIREMENTS 1
PACKAGE CONTENTS 2
INSTALLATION 3
HOST INTERFACE CONNECTIONS 3
HARDWARE INSTALLATION 4
DRIVER INSTALLATION 6
Windows Environment 6
SOFTWARE INSTALLATION 6
Windows Environment 6
CONNECTION & OPERATION 7
FRONT PANEL 7
REAR VIEW 8
TECHNICAL DATA 10
TROUBLESHOOTING 13
CD-WRITER 4816IM
1
INTRODUCTION
CD-WRITER 4816IM is a half-height CD-ReWritable drive of standard
IDE interface. It supports maximum 48x speed writing ability on CD-R
discs, 16x speed on CD-RW discs and 48x speed reading performance.
The drive backs up all writing modes and different CD formats and it
automatically recognizes the media placed in the drive, whether a CD, a
CD-R or a CD-RW. With the bundled CD-RW mastering software, CD-
WRITER 4816IM is an ideal model for creating customized audio and
data CDs, and for archiving or distributing big files to achieve data
interchange and backup. Here are some important features of CD-
WRITER 4816IM:
♦ 8X, 16X, 20X, 24X, 32X, 40X and 48X writing speed on CD-R
media
♦ 4X, 8X, 10X, 12X and 16X writing speed on CD-RW media
♦ Adopts Buffer Underrun Prevention technology
♦ Supports MultiRead function
♦ Supports writing modes of TAO, DAO, SAO and packet writing
♦ Large internal buffer: 2MB
♦ Advanced dust-sealed design
♦ Low power consumption
♦ Firmware upgrade possibility via Flash Memory
System Requirements
For IBM compatible PCs, the system requirements recommended
are as follows:
♦ PC sufficient to run Windows 95/98/ME or WindowsNT/2000/XP
CD-WRITER 4816IM
♦ Pentium II 300MHz above with at least 64MB of memory
♦ Fast and sufficient hard disk space (minimum 200MB for
installation, 1GB or more is recommended.)
♦ IDE host interface supporting ATAPI MMC command
♦ Operating system: Microsoft Windows 95/98/ME or Windows
NT/2000/XP
Package Contents
♦ CD-WRITER 4816IM
♦ Audio cable
♦ Application software disc
2
CD-WRITER 4816IM
INSTALLATION
Host Interface Connections
Most current mainboard models have two IDE ports (primary and
secondary) which can connect two IDE cables. Two IDE cables
allow you to connect up to four devices, but it is recommended that
you separate IDE ports for your hard drive and your CD-ReWritable
drive. This will ensure that your hard drive’s performance and speed
won’t be affected by having the CD-RW drive on the same cable.
If you connect only one device on the cable, you can set the jumper
as “master” or “slave”.
If you connect two devices (e.g. CD-ROM & CD-RW) on the same
cable, set different jumper for each device (CD-ROM as “master”,
CD-RW as “slave” and vice versa.) The same rule goes for the
connection of having your hard disk and one other device on the
same cable.
MASTER
CSEL
SLAVE
JUMPER
3
CD-WRITER 4816IM
4
You may consider one of the two ways recommended below to
connect your drive.
♦ To get the most stable performance for the CD-RW drive to write:
Primary IDE Master: Hard Disk
Primary IDE Slave: CD-ROM Drive
Secondary IDE Master: CD-RW drive
♦ For best hard disk performance:
Primary IDE Master: Hard Disk
Secondary IDE Master: CD-ROM drive
Secondary IDE Salve: CD-RW drive
Hardware Installation
1. Turn off the power to the computer system and all peripheral
devices.
2. Disconnect all cables and connectors from the back of your
computer, then remove the cover from the computer.
3. Insert the CD-ReWritable drive into one of the vacant 5.25" drive
bays and secure it with screws to your PC.
In order to prevent interference between the CD-ReWritable drive and the
computer, please make sure to mount the drive using all four mounting
screws.
4. Connect the 40-pin IDE cable from one of the IDE ports on the
mainboard to the 40-pin connector of your CD-ReWritable drive.
Also, connect the power supply cable to the back of the CD-
ReWritable drive.
CD-WRITER 4816IM
The red-edge of the IDE Cable must be connected to Pin 1 on the CD-
ReWritable drive.
5. If you have a sound card that can be connected to this CD-
ReWritable drive, you can connect the drive (as Audio-out) and the
sound card (as Audio-in) with a 4-pin audio cable. (See figure above.)
If your mainboad is integrated with built-in sound system, plug the 4-
pin audio cable into the CD-IN connector on the mainboard as
Audio-in.
6. Re-attach the cover of your computer, and reconnect the power
supply.
5
CD-WRITER 4816IM
6
Driver Installation
Windows Environment
CD-WRITER 4816IM is a PnP device, and Windows 95/98/ME and
Windows NT/2000/XP can automatically detect the drive and load
the appropriate driver. If Windows cannot detect the drive, you can
operate manually:
1. Click the Control Panel Icon in My Computer and then click
Add New Hardware. The Add New Hardware window appears.
2. The program will automatically search for your new drive and
load the appropriate driver.
Software Installation
The bundled mastering software gives you the complete solution for
making audio/data CDs right from your desktop. It allows you to copy
files from your computer to a recordable compact disc. In addition,
the audio CDs you create can be played in your home or car CD
player. For the CD-RW media, you can write and erase data on the
CD as you do with a floppy disk.
Windows Environment
(1) Run install.exe or setup.exe
or
(2) Refer to the manual in the software disc.
