BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
User
Guide
BT Studio / Studio Twin
Digital Cordless Telephone
This equipment is not designed for ma ing emergency telephone calls
when the power fails. Alternative arrangements should be made for
access to emergency services.
This product is intended for connection to analogue public switched
telephone networ s and private switchboards in the United Kingdom.
This product is not DECT
GAP compatible. It cannot
be registered to any other
DECT GAP telephone and
it is not possible to register
additional handsets.
Please open this page for an ‘At a glance’
guide to your BT Studio.
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408 BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
1 2
Handset display
Displays the status
of your handset.
Red light
Indicates that the phone
is ringing or in use.
Talk button
Use to make, receive
and end calls.
Int button
Use to make an internal call or
to transfer a call to the BT Studio
additional handset (feature only
available if you have purchased
the BT Studio Twin).
Recall button
For use with a switchboard/PBX
and some BT Select Services.
Also use to exit the Calls list.
Quickdial button
Use to store up to 10 numbers
that can then be dialled at the
touch of two buttons.
Keypad
Delete/Secrecy button
Use to delete digits entered
incorrectly and numbers in the
Calls list. Also used to mute a call
so the caller cannot hear you talk
to someone close by.
Calls list button
Press to enter the Calls list, to
view the last 10 calls/most recent
calls. Also use to scroll up and
down through the Calls list.
Volume button
In idle mode use to adjust
the handset ringer volume.
During a call, use to adjust
the earpiece speech volume.
Redial/ ause button
Press to redial the last number
called. Also, press to dial or
store a pause in a number.
At a glance
S
e
c
r
e
c
y
Quickdial Redial Volu e
Calls
Del
䊱
䊲
123
456
789
0
RInt
P
BT Studio Handset
3
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Power/
In use
Charging
Charging
Additionally if you have purchased the BT Studio Twin
Charging light
Red light comes on when
the batteries are being
recharged.
Charging
light
Red light
comes on
when the
batteries
are being
recharged.
Power/In use light
Green light comes on
to indicate mains power.
Flashes when the line is
in use.
Use to page
a handset(s).
BT Studio Base
BT Studio Charger
S
e
c
r
e
c
y
Quic dial Redial Volume
Calls
Del
123
456
79
0
RInt
P
4
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Quick guide to the
handset display icons
Batteries are charged
Batteries are exhausted and require charging
Batteries are being charged
Switches off when batteries are fully charged
Handset is in use
Flashes to indicate an external incoming call
Steady during an external call
Flashes to indicate an internal call
Indicates you are dialling or storing a
number in the Quickdial memory
Secrecy feature is switched on
Steady when viewing the Calls list
Flashes when a new call has been received
in the Calls list
Steady when handset is in range of the base
Flashes when the handset is out of range of
the base
5
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
In this guide
At a glance 1
Introduction 6
Unpacking 7
For your records 8
Safety information 9
Setting up 11
sing the telephone 18
Making and receiving calls 18
Secrecy 19
Last number redial 20
aging 20
Quickdial memory 21
Caller Display 23
Handset settings 25
sing the BT Studio additional
handset 26
Internal calls 26
Transferring calls 27
Help 28
General information 30
Guarantee 30
Technical information 31
Switchboard compatibility 31
Switchboard external line access code 32
Setting pauses 32
Recall 32
Index 33
6
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Introduction
Your BT Studio is designed for ease of use and made to the
high standards set by BT.
You can expect your BT Studio to provide many years of
quality service. Please read the instructions carefully before
use and keep this user guide for future reference.
DECT
By purchasing the Studio you now own a product which
combines the advantages of cordless operation with the
performance of a high quality corded telephone. It complies
with the Digitally Enhanced Cordless Telecommunications
(DECT) standard and offers unparalleled quality and
features.
This user guide applies to both the Studio and Studio Twin
telephones. Please note the Studio range of telephones are
non GAP compatible. Please refer to page 26 for further
information.
7
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Unpacking your BT Studio
or BT Studio Twin
Check that your BT Studio is complete. If anything is
missing, please contact your place of purchase immediately.
BT Studio handset
BT Studio base station
Power supply for the base station
Telephone line cord
2 x AAA rechargeable batteries
QuicdialRedialVolume
Calls
Clr
123
456
79
0
RInt
P
Studio
Digital Clarity
DECT
Page
Charging In Use
(Item code 872260)
8
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Additionally if you have purchased the BT Studio Twin:
BT Studio Twin additional handset
BT Studio Twin charger
Power supply for the charger
2 x AAA rechargeable batteries
For your records
For guarantee purposes proof of purchase is required, so
please keep your receipt.
Date of purchase:
Place of purchase:
Serial number:
(on the underside of the base station)
Helpline
If you have problems with your phone, please call the BT
Studio Helpline on 0 706 05 047.
QuicdialRedialVolume
Calls
Clr
123
456
79
0
RInt
P
(Item code 003313)
9
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
General
Only use the power supply included with the product.
Using an unauthorised power supply will invalidate your
guarantee and may damage the telephone. The item
number for the base station is 872260. The item number
for the charger is 003313 (only applicable if you have
purchased the BT Studio Twin).
For the handset use only approved Nickel Metal
Hydride (NiMH) rechargeable batteries. Never use
other batteries or conventional alkaline batteries. They
could lead to a short circuit or destroy the battery
casing. Recommended batteries should have a power
rating of 550mAh 1.2V. Batteries are available from the
BT Studio Helpline 0 706 05 047.
Do not open the handset or base station. This could
expose you to high voltages or other risks. Contact the
helpline for all repairs.
Radio signals transmitted between the handset and base
may cause interference to hearing aids.
It is recommended that advice from a qualified expert
be sought before using this product in the vicinity of
emergency/intensive care medical equipment.
It is recommended that if you have a pacemaker fitted
you check with a medical expert before using this
product.
Never dispose of batteries in a fire. There is a serious
risk of explosion and/or the release of highly toxic
chemicals.
Safety information
