Bryant TSTATBBN2W01 Guía

Heat only, or Cool only

HEAT

2 - Wire Operation

No Batteries Required

Large, Easy To Read Display

Thermoglow Backlight

Keypad Lock

Meets California Title 24 Residential

USERS INFORMATION MANUAL

Heating & Cooling Systems

MODEL TSTATBBN2W01

PROGRAMMABLE DIGITAL

THERMOSTAT

Table Of Contents

FRONT PANEL

DISPLAY

BASIC OPERATION

ADVANCED SETUP

ABOUT ADVANCED OPERATION

WARRANTY

Page 1

CAUTION

Follow Installation Instructions before proceeding.

SET THERMOSTAT TO MODE “OFF” PRIOR TO

CHANGING SETTINGS IN SETUP OR RESTORING

FACTORY DEFAULTS.

TSTATBBN2W01

Residential Light Commercial Systems Carrier Corporation 4/01

Front Panel

Page 2

Liquid Crystal Display

with Thermoglow

Up/Down Buttons

OnO/ff Button

Outside Button

Heat or Cool Indicator

Heat = Red, Cool = Green

HEAT

Display

Page 3

OFF

COOL

HEAT

Mode Indicators

Selects the operation mode of the equipment.

HEAT - indicates the heat mode.

COOL - indicates the air conditioning mode.

OFF - indicates the entire system is turned off.

Page 6.

Room Temperature Display

Indicates the current room temperature.

Desired Set Temperature

Indicates desired room temperature(s). Page 7.

NOTE: The operating mode of this thermostat may be changed from the

factory default HEAT operation, to COOL operation in the Advanced Setup

Section.

In the following pages Cool operation may be substituted for Heat operation

if the factory default is changed in Advance Setup Step #3.

Basic Operation

Page 4

The HEAT setting indicates the

temperature the room has to

reach before the furnace will

turn on to heat the room.

The COOL setting indicates the

temperature the room has to

reach before the air conditioner

will turn on to cool the room.

OFF indicates both heating

and air conditioning

systems are turned off.

Select Mode

HEAT

COOL

OFF

Press

ON/OFF

buttons.

Adjust the

desired Set Temperature

with

Pressing the Up or Down buttons in Heat or Cool will adjust only the H

Cool set temperature.

eat or

Page 5

Basic Operation

Outside

Temperature

Pressing the Outside button will display the

outside temperature. A subsequent press

of the Outside button will return the display

to the previous screen. Normal operation

will continue while the Outside temperature

is being displayed.

Press

OUTSIDE

This feature is only available if an

optional wired, or wireless Outside

Sensor is connected to the

thermostat.

Select Desired Temperature

HEAT

Advanced Setup

Page 6

Press the On/Off button.

While holding the On/Off

press the Outside button

for 2 seconds to enter Setup

screens.

NOTE: Each step # is located at

the top right corner of the

display for easy reference.

OUTSIDE

HEAT

Select HEAT or COOL

operation.

COOL

HEAT

Adjust the deadband

from 1 - 6 degrees.

Select the cycles per

hour limit.

d=cycles per hour

limit defeated.

d1=d + defeat 5 min.

Compressor lockout,

lockout is for Cool

operation.

(d, d1, 2 - 6)

Press

Continued

ON/OFF

Advanced Setup

Page 7

Select the display back-

light always On, or Off

after 8 seconds.

Off

Select thermostat

operation in degrees

Fahrenheit or Centigrade.

L I

Press

ON/OFF

OUTSIDE

ON/OFF

Press the On/Off button.

While holding the On/Off press the

outside button to leave the Setup screens.

If no buttons are pressed, the display will

leave the setup screens after 60 seconds.

Advanced Setup

Page 8

Step # Description Range Factory Default

1 Operating Mode - Heat or Cool Heat / Cool Heat

2 Deadband or Temperature swing 1 - 6 2

Cycles per hour d, d1, 2 - 6 6

Fahrenheit or Centigrade F / C F

Thermoglow backlight Off / On On

Advanced Setup Table

OUTDOOR SENSOR

An outdoor temperature sensor may be connected to this thermostat. Totaline

offers wired or wireless models. Compatible models include: P474-0401RF/REC

& P474-0400.

Consult the remote sensor instruction sheet for wiring connections.

HEAT

About Advanced Features & Operation

Page 9

KEYPAD LOCK - To prevent unauthorized use of the thermostat,

the front panel buttons may be disabled. To disable, or

‘lock’ the keypad, press and hold in the On/Off button.

While holding the On/Off button in, press the Down button,

while holding the Down button in press the Up button. The

keypad is now locked.

Press all 3 for

Keypad Lockout

To unlock the buttons, again press and hold in the On/Off

button. While holding the On/Off button in, press the Down

button, while holding the Down button in press the Up button.

The keypad is now unlocked.

ON/OFF

FACTORY DEFAULTS - If, for any reason it is desirable to

return all stored settings back to the factory default

settings, press the On/Off button. While holding the On/Off

button in, press the Down button for 5 sec. All icons will

appear. Press and hold in the Outside button until Fd

appears. This resets all factory settings. To calibrate

room temperature, press the On/Off button once more.

At this point use the Up and Down buttons to calibrate

room temperature, if needed. Press the On/Off button to

return to normal operation. NOTE CAUTION ON PAGE 1.
