LASER PRINTER

PARTS REFERENCE LIST

HL-2060

NOTE FOR USING THIS PARTS REFERENCE LIST

1. In the case of ordering parts, it needs mentioning the following items:

(1) Code

(2) Q'ty

(3) Description

(4) Symbol ( PCB No., Revision , and Parts location mounted on the PCB.)

Note : No orders without Parts Code or Tool No. can be accepted.

< Example >

REF.NO. CODE Q’TY DESCRIPTION SYMBOL REMARK

Revision No.: marked on the printed circuit board.

B48K056 - 201A

2. Design-changed parts :

If the parts are changed, any one of the following symbols is indicated in the REMARKS

column.

#A : compatible between old and new

#B : replaceable from old to new

#D : incompatible

# : newly established

3. The original of this list was made based on the information available in November, 1997.

4. Parts are subject to change in design without prior notice.

(1) (4)

(3)

(2)

Design change indication

Specification No .

Pattern alteration No.

Circuit board No.

CONTENTS

1. POWER CORDS & HARNESSES ........................................................1

2. MAIN PCB.............................................................................................1

3. HIGH-VOLTAGE POWER SUPPLY .....................................................3

4. LOW-VOLTAGE POWER SUPPLY......................................................3

5. COVERS...............................................................................................5

6. PCB ATTACHMENTS...........................................................................7

7. TRANSFER...........................................................................................7

8. CHASSIS ..............................................................................................9

9. PAPER FEEDER.................................................................................11

10. PAPER TRAY A4, LRT/LGL................................................................13

11. LASER UNIT.......................................................................................13

12. FIXING UNIT, 115V/230V...................................................................15

13. DOCUMENTS.....................................................................................15

14. PACKING MATERIALS.......................................................................17

15. ADJUSTMENT TOOL KIT...................................................................19

1-2

2 .MAIN PCB

MODEL HL-2060 54T-U04-103

1 .POWER CORDS & HARNESSES

MODEL HL-2060 54T-U04-050/070

-1-

1. POWER CORDS & HARNESSES

REF.NO. CODE Q'TY DESCRIPTION REMARK

1A UH1052001 1 AC CORD, VDE

1B UH1053001 1 AC CORD, SEV

1C UH1055001 1 AC CORD, SAA

1D UH1054001 1 AC CORD, BS

1E UH1051001 1 AC CORD, UL/CSA

1F U34320001 1 AC CORD #4, BS

1G UK4094001 1 AC CORD, DEMKO

1H U34322001 1 AC CORD #6, ISRAEL

1I U34342001 1 AC CORD #8, BS/SINGAPORE

2 UK2502001 1 HV HARNESS 16P

3 UK4100000 1 PAPER FEED FFC 21P

4 UK2506001 1 LV HARNESS 8P

5 UK2507001 1 FUSER HARNESS 4P

6 UK4072001 1 DC MOTOR HARNESS 3P

7 UK4166001 1 PAPER EJECT SENSOR HARNESS 3P

MODEL HL2060 54T-U04-050/070

2. MAIN PCB

REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK

1-2 UK4051001 1 MAIN PCB ASSY, HL-2060 B512006-2

1 UK4215000 1 MROM23C32000-01 EVEN

2 UK4216000 1 MROM23C32000-02 ODD

3 UK4056001 1 MIO CONNECTOR PCB ASSY B512013-2

4 087320616 8 TAPTITE, CUP S M3X6

5 087320616 1 TAPTITE, CUP S M3X6

MODEL HL-2060 54T-U04-103

- 2 -

3 .HIGH-VOLTAGE POWER SUPPLY

MODEL HL-2060 54T-U04-200

4 .LOW-VOLTAGE POWER SUPPLY

MODEL HL-2060 54T-U04-200

-3-

3. HIGH-VOLTAGE POWER SUPPLY

REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK

1 UK3750001 1 HV PS PCB ASSY HL-2060 B48K297-2

2 087320616 2 TAPTITE, CUP S M3X6

MODEL HL-2060 54T-U04-200

4. LOW VOLTAGE POWER SUPPLY

REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK

1 UK4150001 1 LV PS PCB ASSY 115V HL-2060

1 UK4151001 1 LV PS PCB ASSY 230V HL-2060

2 UH2036001 6 TAPTITE, PAN S(WASHER) M3X8

MODEL HL-2060 54T-U04-300

- 4 -

5 .COVERS

MODEL HL-2060 54T-U04-400

4-5

10 10

17-19

1-3

-5-

5. COVERS

REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK

1-3 UH1526001 1 UPPER COVER ASSY

1 UH1533001 1 M COVER A

2 UH1534001 1 M COVER B

3 UH1535001 1 M COVER C

4-5 UH1538001 1 TONER CARTRIDGE LID

4 UH1540001 1 PAPER STOPPER

5 UH1541001 1 PAPER STOPPER GUIDE

6 UH1893001 1 SW PANEL ASSY (SP) B512005-1

7 UK4068001 1 SW PANEL HARNESS ASSY

8 UH1589001 1 PANEL SHEET HL-2060

9 UH1510001 1 INTERLOCK ACTUATOR

10 085311015 3 TAPTITE, BIND B M3X10

11 UH1572001 1 FONT CARD COVER

12 UH2076001 1 CLEANER BRUSH

13 UH2077001 1 SIDE COVER L, GRAY1227

14 UH2027001 1 SIDE COVER R2 ASSY

15 UH1531001 1 SWING PAPER TRAY

16 UL7978001 1 PLATE SPRING

17-19 UH1542001 1 REAR COVER ASSY

17 UH2085001 1 CHANGEOVER GUIDE, GRAY1227

18 UH1548001 1 JAM REMOVE COVER

19 UK4083001 1 PAPER EJECT SENSOR PCB ASSY B512002-1

20 UH1511001 1 LEAD WIRE COVER

21 UH1512001 1 FRONT COVER

22 UH1514001 1 NAME PLATE

23 UH1545001 1 PAPER SENSOR ACTUATOR

24 087320616 2 TAPTITE, CUP S M3X6

25 087320616 1 TAPTITE, CUP S M3X6

26 087320616 1 TAPTITE, CUP S M3X6

27 087321016 2 TAPTITE, CUP S M3X10

28 060301006 1 TAPTITE, BIND B M3X10

29 085311015 3 TAPTITE, BIND B M3X8

30 UH1509001 1 LIGHT GUIDE

MODEL HL-2060 54T-U04-400

- 6 -

6 .PCB ATTACHMENTS

MODEL HL-2060 54T-U04-450

7 .TRANSFER

MODEL HL-2060 54T-U04-600

410

1-1

-7-
