Brookstone BK-150 Manual de usuario
BK-150
User Manual
Hello.
Brookstone BK-150.
At Brookstone we understand that every body is different and have carefully designed your massage chair with that in mind.
1
2
TABLE OF CONTENTS
INTRO
Dimensions
Contents
3
4
Safety
Grounding Instruction
Troubleshooting
Care and Storage
Warranty
CARE
11-12
13
13
13
14
CHAIR
Move & Clearance
Components
Specification
5
6
7
How To Use 8-10
DIMENSIONS
First, let’s get your chair inside.
50.0”
55.6”
33.5”
Base & Backrest
1
Box
3
29.95”
70.53”
34.67”
4
CONTENTS
Everything you need for a relaxing experience.
User Manual Installation Manual Warranty Postcard
BK-150
User Manual
Power Cord BK-150 Massage Chair
Warranty Card
The BROOKSTONE® trademarks, names and logos are owned by BKST Brand Holdings LLC. ©2019. All rights reserved.
Manufactured, marketed and distributed by (Cozzia USA LLC) under license.
Installat
BK-150
ion Manual
5
Move & Clearance
Reserve space on left and right Reserve space on the front and back
8” 8”
CLEARANCE
HOW TO MOVE
Caution: If you roll the chair on wood floor, marks may be left
Two people are needed to lift the chair
A few simple steps to find the best place for your new chair.
Move with a slight pull or push
31.5”
3.2”
6
CHAIR COMPONENTS
Some of your chair’s most important features.
Pillow Speaker+LED
Backrest
Side Panel
Shoulder
Panel
Seat Pad
Calf Rest
Footrest
Note: The speaker will only operate when the massage chair is in operation
To play music using your massage chair’s speakers please connect your
smartphone, tablet, or other electronic device to your chair using bluetooth.
CHAIR SPECIFICATIONS
Model No.
BK-150
Power Consumption
120W
Max Massage Time
30 minutes
Shipping Weight
Gross weight: 231 lbs
Net Weight: 198 lbs
Safety Feature
Equipped with overheatingand power
surge detectors safety feature
Dimensions (L x W x H)
Chair Dimension: 55.6" x 33.5" x 50"
Reclined Dimension: 78" x 33.5" x 44"
A few important facts about your massage chair.
Rated Voltage
110 - 120V
Rated Frequency
60Hz
Power of Speakers
12W (2 sides)
Length of Wiring
Controller wiring27.6"
Power supply wiring70.9”
Usage Condition
Environment temperature: 10。
C-40。
C
Contrastinghumidity: 30-85RH
Storage Condition
Storage temperature: -20。
C-60。
C
Storage humidity level: 30-85RH
7
8
HOW TO USE
Connect the chair to a power supply, then turn switch to the “I” position. The chair is now in idle mode.
During idle, the on/off button will blink.
During idle, only the on/off, pause, legrest recline/restore, and chair recline/restore buttons can be operated.
Relax
Manual Air
Strength Speed Width Intensity
Direction Spot/Partial
Gentle
Lower BackUpper Back Stretch
Vigorous
HEAT
Relax
Manual Air
Strength Speed Width Intensity
Direction Spot/Partial
Gentle
Lower BackUpper Back Stretch
Vigorous
HEAT
115 11
14
18
19
22
26
27
25
13
12
17
16
21
20
23
24
2
3
7
10
9
4
5
8
6
9
The Start/Stop Control Button
Press the power button and any massage function to start a massage. Press the power button again to end your massage and turn off the
chair.
1. ON/OF
Press this button once to halt current massage function and count down timer. During pause mode, the pause button will be blinking.
Press this button again to cease the “Pause” function and resume previous massage function as well as countdown timer.
2. PAUSE
Time Interval Control Button
When a massage function is activated, the timer is preset at 15 minutes. Every single press on this button will change the timer interval in
the sequence of "20>25>30>5>10>15>20" minutes.
3. TIMER
This massage will quickly demonstrate all of the massage features in 5 minutes.
4. DEMO
A program designed to provide a mild massage that is great for deep relaxation, best used before going to sleep.
5. RELAX
A program designed to provide a quiet, gentle massage that is good for beginners or those that prefer a soft touch.
6. GRNTLE
This massage will combine vigorous tapping on your back and an air massage focused on your arms and legs.
7. VIGOROUS
This massage will focus on your neck, shoulders, and legs with a slow massage that incorporates soothing heat.
8. UPPER BACK
This massage will focus on your lower back with a deep massage that includes air compression.
9. LOWER BACK
This massage will stretch your legs and back with a combination of gentle tapping, kneading,rolling, and air compression.
10. STRETCH
Press this button in order to activate the zero gravity position.
15. ZGR
Angle Adjustment Button for Backrest
Keep pressing to comfortably lay flat or to restore the chair to its original position.
11/12. CHAIR RECLINE AND RESTORE
Angle Adjustment Button for Legrest
Keep pressing either button until the legrest reaches your desired position.
13/14. LEGREST RECLINE AND RESTORE
Gentle
Lower Back
Upper Back
Stretch
Vigorous
Relax
