EIB3028 / 3018

Alarms

Instruction Manual

Read and retain carefully for as long as the product is being used. It contains vital

information on the operation and installation of your Alarm. The leaﬂet should be

regarded as part of the product.

If you are just installing the unit, the leaﬂet MUST be given to the householder. The

leaﬂet is to be given to any subsequent user.

Mains Powered

Contents

Installer Guide

1. Introduction 5

1.1 Overview 7

1.2 Technical Specifications 9

2. Installation 11

2.1 Important Safety Instructions 12

2.2 Where to locate the Alarm? 13

2.3 Which Alarm in what room? 14

2.4 Where in the room? 15

2.5 Unsuitable locations 16

2.6 Mounting and wiring 18

2.7 Interconnecting Alarms 22

2.8 Removing the Alarm 24

User Guide

3. What is Carbon Monoxide? 25

3.1 Symptoms of CO poisoning 27

3.2 How to protect your family against CO 28

3.3 How does your Alarm work 29

4. Testing 33

4.1 Testing and maintaining your Alarm 34

4.2 Cleaning your Alarm 36

5. What to do in case of fire alarm 38

6. What to do in case of CO alarm 40

7. Troubleshooting and Indicator summary tables 42

8. Important safeguards 52

9. Service and Guarantee 55

9.1 Getting your Alarm serviced 56

9.2 Guarantee 56

Introduction

Installer Guide

The EIB3028 is a dual sensor Heat and Carbon Monoxide (CO) Alarm. It contains a proven electrochemical

CO sensor to detect the presence of toxic levels of Carbon Monoxide as well as an independent fast

acting Class A1 Thermistor sensor to detect dangerous levels of heat. The combination of CO and

Heat detection makes it an ideal Alarm for kitchens, utility rooms and garages where fuel burning

appliances maybe installed.

The EIB3018 is a Carbon Monoxide Alarm which contains a proven electrochemical CO sensor to

detect the presence of toxic levels of Carbon Monoxide (CO). It is ideal for kitchens, garages, utility

rooms and other areas where fuel burning appliances maybe installed.

Up to 12 Alarms can be interconnected so that if one senses fire or dangerous levels of CO, all

Alarms sound. It can be a hardwired interconnection or a wireless interconnection (for the latter an

EIB3000MRF SmartLINK module needs to be added to each Alarm – sold separately)

The EIB3000 series is supplied with a base that allows very quick and simple installation of the Alarm

as it automatically connects both mains power and battery as the detector head slides onto the base.

Each Alarm comes with built-in rechargeable backup batteries to power the Alarm in the event of a

mains failure.

AudioLINK

The EIB3000 series Alarms are AudioLINK enabled. This feature allows the user to download

information from the Alarm through the use of a mobile App. For more information on using this

feature, please refer to the relevant section on www.eielectronics.com or www.brooks.com.au

1.1 Overview

EIB3018 Carbon Monoxide Alarm

EIB3028 Heat / Carbon Monoxide Alarm

Red LED

Alarm Indicator

Yellow LED

Fault Indicator

Green LED

Power Indicator

Test / Hush Button Alarm Sounder

RF Module

LED Indicator

RF Module

Learn Switch

Alarm

Removal

Latch

Carbon Monoxide

Sensor Entry Holes

Red LED Alarm Indicator

Yellow LED Fault Indicator

Green LED Power Indicator Test / Hush Button

Alarm Sounder

Heat Sensor

(Thermistor)

RF Module

LED Indicator

RF Module

Learn Switch

Alarm

Removal

Latch

‘FIRE’ & ‘CO’

LED Display

(normally hidden)

Carbon Monoxide Sensor Entry Holes

EIB3018 Carbon Monoxide Alarm

EIB3028 Heat / Carbon Monoxide Alarm

Red LED

Alarm Indicator

Yellow LED

Fault Indicator

Green LED

Power Indicator

Test / Hush Button Alarm Sounder

RF Module

LED Indicator

RF Module

Learn Switch

Alarm

Removal

Latch

Carbon Monoxide

Sensor Entry Holes

Red LED Alarm Indicator

Yellow LED Fault Indicator

Green LED Power Indicator Test / Hush Button

Alarm Sounder

Heat Sensor

(Thermistor)

RF Module

LED Indicator

RF Module

Learn Switch

Alarm

Removal

Latch

‘FIRE’ & ‘CO’

LED Display

(normally hidden)

Carbon Monoxide Sensor Entry Holes

Heat Sensor Thermistor (EIB3028) Class A1 detection – Alarm is triggered at 58°C

Carbon Monoxide Sensor Electrochemical (EIB3028 and EIB3018)

Power Supply 100-250V AC, 50Hz, 0.25W

Battery Backup

Built-in 10-year rechargeable Vanadium Pentoxide Lithium cells. Fully

charged, the battery will provide up to 6 months (without module

fitted) or 3 months (with module fitted) back-up without mains power

Alarm Sounder Piezoelectric Horn

Alarm Sound Level 85dB(A) at 3 meters (min)

Memory Feature Indicates that the Alarm has previously detected fire and or dangerous

levels of CO

Display EIB3028 - indicates FIRE or CO

Self Test Sensors, battery and electronics are automatically tested periodically

Test/Hush Button

Checks sensors, electronics, display, interconnection and sounder.

If the unit is in alarm when pressed, it silences the alarm for 10min

(if alarming due to heat), 4 minutes (if alarming due to <150ppm CO)

Visual indicators Green LED – Power supply Yellow LED – Fault, EOL Red LED –

memory, pre-alarm or alarm (if coincides with horn sounding)

1.2 Technical Specifications

AudioLINK Enabled

Operational Life 10 years

Interconnection Up to 12 units can be interconnected via a hardwired or wireless

system (using optional EIB3000MRF SmartLINK module)

EIB3000MRF Frequency 926 MHz

Fixings Supplied with Easi-fit anti-tamper mounting plate with integral

terminal block and wiring cover, includes screws and wall plugs

Operating Temperature Normal: -10°C to +40°C (Storage: -10°C to +40°C) *

Humidity Range 15% to 95% RH (non-condensing)

Plastic Material UL94V-0 flame retardant rated

Dimensions EIB3028: Product: - Ø150mm x 66mm Package - 155 x 155 x 70mm

EIB3018: Product: - Ø150mm x 63mm Package - 155 x 155 x 65mm

Weight 350g (including packaging)

Warranty 5 year (limited)

Approvals EN50291-1:2010+A1:2012, AS1603.3:2018

* Temperature and Humidity conditions are for normal operation and storage. Units will function outside these

ranges as required by the specific product Standards. Extended exposure to conditions outside these ranges

can reduce product life. For advice on prolonged operation outside these ranges consult the manufacturer.
