The Brocade 8Gb SAN Switch for HP BladeSystem c-Class delivers an easy to manage embedded Fibre Channel switch with 8 Gbps

performance. The Brocade 8Gb SAN Switch hot-plugs into the back of the HP BladeSystem c-Class Enclosure. The integrated design

frees up rack space, enables shared power and cooling, and reduces cabling and small form-factor pluggables. Enhanced trunking

support with external switches provides higher bandwidth to enable demanding applications such as server virtualization. New

features in the Power Pack+ option enable you to manage data flow to maintain optimized application performance. The 12 or 24

auto-sensing ports support lower bandwidth components for investment protection and an upgrade license enables you to 'pay as

you grow'. The Brocade 8Gb SAN Switch saves space and cost, significantly simplifies the SAN environment, enables easier

deployment and management, and delivers the performance required for emerging higher throughput applications.

Brocade 8Gb SAN Switch

Brocade 8Gb SAN SwitchBrocade 8Gb SAN Switch

Brocade 8Gb SAN Switch

Integrated SAN

Integrated SANIntegrated SAN

Integrated SAN

connectivity

connectivityconnectivity

connectivity

Enables data center consolidation with HP BladeSystem c-Class through a state-of-the-art zero-

footprint design while lowering cost through shared power and cooling, fewer cables and SFPs,

and a reduction in space.

Next generation 8 Gbps

Next generation 8 GbpsNext generation 8 Gbps

Next generation 8 Gbps

storage networking

storage networkingstorage networking

storage networking

Enables support of virtualized environments and other emerging technologies through high-speed

technology that doubles the performance of the storage network. Both internal and external facing

ports auto-sense lower bandwidth components for flexibility and investment protection (2, 4, or 8

Gb).

Non-blocking architecture

Non-blocking architectureNon-blocking architecture

Non-blocking architecture

Includes connection speed support for all ports to provide a high-performance system with

aggregate bandwidth of up to 384 Gbps (24 ports x 8 Gbps x 2 for full duplex).

ISL Trunking performance

ISL Trunking performanceISL Trunking performance

ISL Trunking performance

enhancements

enhancementsenhancements

enhancements

Now providing support for up to a single trunk made up of all eight SAN ports for a total of up to

64 Gbps balanced throughput. Trunking of the SAN-facing ports with external Brocade or HP

StorageWorks B-series switches provides a high-bandwidth solution while lowering costs through

fewer SFPs and cables.

Adaptive Networking

Adaptive NetworkingAdaptive Networking

Adaptive Networking

Services

ServicesServices

Services

Enables organizations to better manage data flows and meet service level agreements while

maintaining optimized application performance in virtual environments with new Adaptive

Networking services, including Adaptive Fabric Quality of Service, Traffic Isolation, and Ingress

Rate Limiting.

Access Gateway mode

Access Gateway modeAccess Gateway mode

Access Gateway mode

Employs N_Port ID Virtualization (NPIV), an ANSI T11 standard, to enable interoperability with

other SAN fabrics and eliminate domain considerations while improving SAN scalability.

Broad range of

Broad range ofBroad range of

Broad range of

management tools and

management tools andmanagement tools and

management tools and

SMI-s conformance

SMI-s conformanceSMI-s conformance

SMI-s conformance

Integrates with HP Onboard Administrator for BladeSystem, HP Systems Insight Manager, and HP

Storage Essentials and leverages HP B-series management and monitoring tools. An SMI-s API

enables the use of industry standard interfaces to integrate management with other applications.

QuickSpecs

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-ClassBrocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Overview

DA - 13084 Worldwide — Version 2 — November 17, 2008

Page 1

Available in three models

Available in three modelsAvailable in three models

Available in three models

with a scalable licensing

with a scalable licensingwith a scalable licensing

with a scalable licensing

option

optionoption

option

Available in 12-port, 24-port and 24-port Power Pack+ Full Fabric models. Choose the features

and management options that make sense for your needs. In addition, enables 'pay as you grow'

scalability for easy, scalable growth in dynamic business environments with a non-disruptive 12-

port upgrade for the 12-port model.

QuickSpecs

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-ClassBrocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Overview

DA - 13084 Worldwide — Version 2 — November 17, 2008

Page 2

Advanced Fabric Services

Advanced Fabric ServicesAdvanced Fabric Services

Advanced Fabric Services

Hardware Enforced Zoning (included)

Dynamic Path Selection (included)

WebTools (included)

Enhanced Group Management (EGM)

Power Pack+ fabric services software bundle (optional)

Adaptive Networking

ISL Trunking

Fabric Watch

Extended Fabrics

Advanced Performance Monitoring

Secure Fabric OS (included in base FOS)

Data Center Fabric Manager (optional)

* Not supported in Brocade Access Gateway mode.

Manageability

ManageabilityManageability

Manageability

WebTools (included)

Enhanced Group Management (EGM)

Advanced Performance Monitoring (optional Power Pack+ upgrade)

HP OnBoard Administrator (included with HP BladeSystem)

HP Systems Insight Manager (included with HP BladeSystem)

HP Storage Essentials (optional)

API

SNMP

SMI

Interoperability

InteroperabilityInteroperability

Interoperability

Brocade Access Gateway, a feature enabled in Fabric OS v5.2.1b and later, enables Brocade

embedded SAN switches to interoperate with other SAN fabrics running supported firmware. While in

Brocade Access Gateway mode, the device must also be connected to an NPIV-enabled edge switch or

director. Supported edge environments are listed in the Brocade Fabric OS® release notes.

Software Components, Standard

Software Components, StandardSoftware Components, Standard

Software Components, Standard

Access Gateway

Access GatewayAccess Gateway

Access Gateway

Included with Fabric OS v5.2.1b and later, Brocade Access Gateway Mode enables seamless

connectivity for Brocade embedded SAN switches to other supported SAN fabrics, enhances scalability,

and simplifies manageability. Utilizing N_Port ID Virtualization (NPIV) standards, Brocade Access

Gateway eliminates switch/domain considerations.

* Brocade Access Gateway mode does not support many switch-related features, including most features

in the Power Pack+ bundle. Please refer to the Fabric OS v5.2.1b Release Notes and Access Gateway

Administrator's Guide for details.

Frame Filtering

Frame FilteringFrame Filtering

Frame Filtering

A special B-Series ASIC-based capability that enables new applications and features. The switch has the

ability to "view" the first 64-bytes of the Fibre Channel frame. At this time, Frame Filtering enables

advanced capabilities such as Advanced Zoning and Advanced Performance Monitoring (optional).

QuickSpecs

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-ClassBrocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Product Highlights

DA - 13084 Worldwide — Version 2 — November 17, 2008

Page 3

Advanced Zoning

Advanced ZoningAdvanced Zoning

Advanced Zoning

Zoning (Port and Worldwide Name), as well as Access Control, are enforced by hardware within the

ASIC that provides the same simple administration previously enforced only with software. Hardware

enforcement enables the highest level of zoning enforcement without any impact to performance.

Administrators can organize a physical fabric into logical groups and prevent unauthorized access by

devices outside the Zone.

WebTools

WebToolsWebTools

WebTools

- included in

Brocade Fabric OS

Enables organizations to monitor and manage single Fibre Channel switches and monitor small SAN

fabrics. Tasks can be performed through a Java-capable Web browser from a standard laptop, desktop

PC or workstation from any location within the enterprise.

EGM

EGMEGM

EGM

Enhanced Group Management (EGM) is a FOS license that is included with all B-Series switches and

enables multi-switch operations. It helps automate operations across multiple switches to save time and

streamline repetitive operations, which are typically prone to error. EGM drives consistency across

fabrics, while minimizing the risk associated with potential downtime due to configuration mismatches.

EGM provides streamlined troubleshooting for more effective fabric monitoring and diagnosis.

Both Data Center Fabric Manager Professional and Enterprise enable EGM functionality. Customers

have EGM functionality enabled within the hardware product and need only to make the decision around

which management application is right for them - Data Center Fabric Manager Professional or

Enterprise.

Dynamic Path Selection

Dynamic Path SelectionDynamic Path Selection

Dynamic Path Selection

Improves performance by dynamically routing data traffic across multiple links and trunk groups.

Secure Fabric OS

Secure Fabric OSSecure Fabric OS

Secure Fabric OS

included in Brocade Fabric

Secure Fabric OS features have been fully integrated into the base Fabric OS since v5.3.0. These

comprehensive security features for SAN fabrics provide policy-based security protection for more

predictable change management, assured configuration integrity and reduced risk of downtime. Security

methods supported include digital certificates and digital signatures, multiple levels of password

protection, strong password encryption and Public Key Infrastructure (PKI)-based authentication, and

128-bit encryption of the switch's private key used for digital signatures. These features enable

organizations to customize SAN security to meet specific policy requirements and work in conjunction

with Advanced Zoning to further secure access to the SAN, simplify storage management, and reduce

provisioning time.

Software Components, Optional

Software Components, OptionalSoftware Components, Optional

Software Components, Optional

Power Pack+ Software

Power Pack+ SoftwarePower Pack+ Software

Power Pack+ Software

Bundle

BundleBundle

Bundle

The Power Pack+ Software Bundle includes:

Adaptive Networking

ISL Trunking

Advanced Performance Monitoring

Extended Fabrics

Fabric Watch

* Not supported in Access Gateway mode

QuickSpecs

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-ClassBrocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Product Highlights

DA - 13084 Worldwide — Version 2 — November 17, 2008

Page 4

Adaptive Networking

Adaptive NetworkingAdaptive Networking

Adaptive Networking

Services

ServicesServices

Services

This suite of tools optimizes fabric behavior and ensures ample bandwidth for mission-critical

applications. The tools currently include Quality of Service (QoS), Ingress Rate Limiting, Traffic Isolation,

and Top Talkers. By assigning zones a high, medium, or low priority, QoS allocates bandwidth in the

event of congestion to expedite high-priority traffic and keep all traffic flowing. Ingress Rate Limiting

restricts data flow from less-critical hosts at preset bandwidths. Traffic Isolation assigns high-bandwidth

data flows to specific ISLs. And Top Talkers measures the top bandwidth-consuming traffic in real time for

a specific physical or virtual device, or end to end across the fabric.

ISL Trunking

ISL TrunkingISL Trunking

ISL Trunking

For high performance and seamless failover, this optional license logically groups up to eight E-ports

(switch mode) or F-ports (Access Gateway mode) to provide a high bandwidth trunk between two

Brocade or HP StorageWorks B-Series switches. Each switch needs its own license. The fabric operating

system views the trunk as a single, high bandwidth ISL resource (up to 64 Gbps when routing connections

between 8 Gbps capable switches). Connections are load-balanced across the individual links, which

comprise the logical trunk group.

Fabric Watch

Fabric WatchFabric Watch

Fabric Watch

Fabric Watch enables each switch to monitor the health of the SAN for potential faults-and automatically

alert network managers to problems before they become failures. Fabric Watch tracks a variety of SAN

fabric elements, events, and counters. Monitoring fabric-wide events, ports, SFPs, and environmental

parameters permits early fault detection and isolation as well as performance measurement. Each switch

in the SAN needs its own Fabric Watch license.

Advanced Performance

Advanced PerformanceAdvanced Performance

Advanced Performance

Monitoring

MonitoringMonitoring

Monitoring

This enabling technology helps administrators monitor application data traffic from a SID (Source ID) to a

DID (Destination ID), so they can fine-tune and scale the fabric more efficiently. Plus, Advanced

Performance Monitoring includes the ability for early warning detection of hot spots within the fabric, a

powerful tool for maximizing SAN performance.

Extended Fabrics

Extended FabricsExtended Fabrics

Extended Fabrics

Extends the native Fibre-Channel traffic up to 166 km. Extended Fabrics increases the scalability,

reliability, and performance benefits of Fibre Channel Storage Area Networks (SANs) beyond the native

10 km distance specified by the Fibre Channel standard.

Data Center Fabric

Data Center FabricData Center Fabric

Data Center Fabric

Manager Professional

Manager ProfessionalManager Professional

Manager Professional

HP StorageWorks Data Center Fabric Manager Professional is a server based management application

available at no-charge and comes with B-series SAN Switches and includes the following features:

Allows management of a single Fabric OS (FOS) fabric (up to a 1,000 B-Series switch ports) at a

time

Performs group switch management beyond the scope of Web Tools

Does not offer management of the DC SAN Backbone Director

It is targeted for SMB customers that use FOS based SAN fabrics and require a management solution for

smaller SANs based on a single fabric.

SMB customers that initially start off with Data Center Fabric Manager Professional and have a small

SAN environment may over time feel the need for an enterprise-class product (Data Center Fabric

Manager Enterprise) as their environments start to grow in size and complexity, and as they start to

uptake more enterprise-class functionality (such as Fibre Channel Routing, FCIP, etc.). A non-disruptive

upgrade path is available from Data Center Fabric Manager Professional to Data Center Fabric

Manager Enterprise.

QuickSpecs

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-ClassBrocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Product Highlights

DA - 13084 Worldwide — Version 2 — November 17, 2008

Page 5

Data Center Fabric

Data Center FabricData Center Fabric

Data Center Fabric

Manager Enterprise

Manager EnterpriseManager Enterprise

Manager Enterprise

HP StorageWorks Data Center Fabric Manager Enterprise is a server based enterprise-class product that

supports FOS products as well as FOS and M-EOS products together. It provides complete DC SAN

Backbone Director management including enterprise-class features/environments such as FICON, Fibre

Channel Routing, FCIP, Adaptive Networking, etc. It also delivers unprecedented scalability with support

for up to 24 SAN fabrics and 9,000 B-series switch ports.

HP will provide a free license upgrade to Data Center Fabric Manager Enterprise for existing HAFM/FM

customers that have an active maintenance and support contract at the time Data Center Fabric

Manager Enterprise is available. Data Center Fabric Manager does require at least one FOS based B-

series SAN switch.

BladeSystem compatibility

BladeSystem compatibilityBladeSystem compatibility

BladeSystem compatibility

The Brocade 8Gb SAN Switch for HP BladeSystem c-Class must be deployed within the BladeSystem c-Class infrastructure and is

compatible only with HP BladeSystem c-Class Enclosures.

Switch interoperability

Switch interoperabilitySwitch interoperability

Switch interoperability

HP StorageWorks B-Series

HP StorageWorks B-SeriesHP StorageWorks B-Series

HP StorageWorks B-Series

Switches, Directors, and

Switches, Directors, andSwitches, Directors, and

Switches, Directors, and

Routers

RoutersRouters

Routers

8 Gb Switches and

8 Gb Switches and8 Gb Switches and

8 Gb Switches and

Directors

DirectorsDirectors

Directors

Embedded switch for HP StorageWorks 4400 Enterprise Virtual Array

8/8 SAN Switch

8/24 SAN Switch

8/40 SAN Switch

8/80 SAN Switch

DC SAN Backbone Director

4 Gb Switches and

4 Gb Switches and4 Gb Switches and

4 Gb Switches and

Directors

DirectorsDirectors

Directors

Brocade 4Gb SAN Switch for HP c-Class BladeSystem

Brocade 4Gb SAN Switch for HP p-Class BladeSystem

4/8 SAN Switch

4/16 SAN Switch

4/32 SAN Switch

4/32B SAN Switch

4/64 SAN Switch

4/256 SAN Director

2 Gb Switches and

2 Gb Switches and2 Gb Switches and

2 Gb Switches and

Directors

DirectorsDirectors

Directors

MSA SAN Switch 2/8

SAN Switch 2/8

SAN Switch 2/8-EL

SAN Switch 2/8V

SAN Switch 2/16

SAN Switch 2/16-EL

SAN Switch 2/16N

SAN Switch 2/16V

SAN Switch 2/32

Core Switch 2/64

SAN Director 2/128

Virtual Connect

Virtual ConnectVirtual Connect

Virtual Connect

HP 4Gb Virtual Connect Fibre Channel Module for HP c-Class

BladeSystem

Multi-Protocol Routers

Multi-Protocol RoutersMulti-Protocol Routers

Multi-Protocol Routers

and Gateways

and Gatewaysand Gateways

and Gateways

Multi-Protocol (MP) Router

400 Multi-Protocol Router

Multi-Protocol Router Blade

* Supported in the same fabric with Brocade 8Gb SAN Switch for HP BladeSystem c-Class, but not

directly connected.

QuickSpecs

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-ClassBrocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Product Highlights

DA - 13084 Worldwide — Version 2 — November 17, 2008

Page 6

Warranty

WarrantyWarranty

Warranty

(1-1-1) Hardware Warranty - One-year on-site warranty, normal business hours, next business day

response, installation not included.

NOTE:

NOTE:NOTE:

NOTE:

The hardware warranty covers firmware and embedded non-saleable software. Saleable software

carries its own warranty, please see below.

Software Warranty: HP warrants only that the software media will be free of physical defects for a period

of ninety (90) days from delivery.

EXCLUSIVE REMEDY:

EXCLUSIVE REMEDY:EXCLUSIVE REMEDY:

EXCLUSIVE REMEDY:

The entire liability of HP and its suppliers and your exclusive remedy for software

that does not conform to this Limited Warranty shall be the repair or replacement of the defective media.

This warranty and remedy are subject to your returning the defective media during the warranty period to

HP in the country in which you obtained the software.

Services Included with

Services Included withServices Included with

Services Included with

Product Purchase

Product PurchaseProduct Purchase

Product Purchase

The Power Pack+ Software Bundle includes one year of HP standard business hours, standard business

days Software Support (includes software technical support and software product and documentation

updates).

HP Service & Warranty

HP Service & WarrantyHP Service & Warranty

HP Service & Warranty

Support

SupportSupport

Support

HP Service & Warranty Support Additional Warranty protection and/or HP Installation packages can be

purchased.

NOTE:

NOTE:NOTE:

NOTE:

Certain restrictions and exclusions apply. Consult the Customer Support Center for details. HP

provides a one-year, hardware limited warranty, fully supported by a worldwide network of resellers and

service providers.

In addition, available service offerings include a full range of HP Care Pack packaged hardware and

software services:

Installation

Extended coverage hours and enhanced response times

System management and performance services

For more information on warranty and support options, please visit our Web site at:

http://www.hp.com/hps/tech/storage/supp/

Software Product Services

Software Product ServicesSoftware Product Services

Software Product Services

Stand-alone telephone support

Rights to new license version

Media and documentation updates

Hardware Product

Hardware ProductHardware Product

Hardware Product

Services

ServicesServices

Services

Installation services

On-site maintenance (includes warranty support)

Response time upgrades during the warranty period

Post-warranty coverage

The embedded SAN switches for HP BladeSystem c-Class are not covered under the BladeSystem

Enclosure Care Packs; the SAN switches carry separate Care Packs. SAN Switch Care Pack service level

support should always be uplifted to match existing storage or server service levels.

NOTE:

NOTE:NOTE:

NOTE:

The HP Care Pack service part numbers below covers the Brocade 8/12c SAN

Switch & Brocade 8/24c SAN Switch

Hardware Services On-site Service

Hardware Services On-site ServiceHardware Services On-site Service

Hardware Services On-site Service

QuickSpecs

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-ClassBrocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Service and Support, HP Care Pack, and Warranty Information

DA - 13084 Worldwide — Version 2 — November 17, 2008

Page 7

Next Business Day On-site Service, 5-Day x 9-Hour Coverage, 3 Years, Electronic

UE436E

4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic

UE437E

4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic

UE438E

6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years,

Electronic

UE439E

Next Business Day On-site Service, 5-Day x 9-Hour Coverage, 4 Years, Electronic

UE440E

4-Hour On-site Service, 5-Day x 13-Hour Coverage, 4 Years, Electronic

UE441E

4-Hour On-site Service, 7-Day x 24-Hour Coverage, 4 Years, Electronic

UE442E

6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 4 Years,

Electronic

UE443E

Next Business Day On-site Service, 5-Day x 9-Hour Coverage, 5 Years, Electronic

UE444E

4-Hour On-site Service, 5-Day x 13-Hour Coverage, 5 Years, Electronic

UE445E

4-Hour On-site Service, 7-Day x 24-Hour Coverage, 5 Years, Electronic

UE446E

6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 5 Years,

Electronic

UE447E

Hardware Installation, Electronic

U5988E

NOTE:

NOTE:NOTE:

NOTE:

The HP Care Pack service part numbers below covers the Brocade 8/24c SAN

Switch Power Pack+

Hardware Services On-site Service

Hardware Services On-site ServiceHardware Services On-site Service

Hardware Services On-site Service

Support Plus

Support PlusSupport Plus

Support Plus

Onsite HW support, 8am-9pm, M-F, 4hr response and SW Tech support offsite, onsite

at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, 3 Years,

Electronic

UL246E

Onsite HW support, 8am-9pm, M-F, 4hr response and SW Tech support offsite, onsite

at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, 4 Years ,

Electronic

UL248E

Onsite HW support, 8am-9pm, M-F, 4hr response and SW Tech support offsite, onsite

at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, 5 Years ,

Electronic

UL250E

Support Plus 24 - Recommended

Support Plus 24 - RecommendedSupport Plus 24 - Recommended

Support Plus 24 - Recommended

Onsite HW support 24x7, 4hr response and SW Tech support offsite, onsite at HP's

discretion, 24x7 2hr response time incl. HP holidays, 3 Years, Electronic

UL247E

Onsite HW support 24x7, 4hr response and SW Tech support offsite, onsite at HP's

discretion, 24x7 2hr response time incl. HP holidays, 4 Years, Electronic

UL249E

Onsite HW support 24x7, 4hr response and SW Tech support offsite, onsite at HP's

discretion, 24x7 2hr response time incl. HP holidays, 5 Years, Electronic

UL251E

HP Care Pack Services

HP Care Pack ServicesHP Care Pack Services

HP Care Pack Services

Warranty Upgrade

Warranty UpgradeWarranty Upgrade

Warranty Upgrade

Options

OptionsOptions

Options

Service offerings include a full range of Customer HP Care Pack services for both hardware and software

services.

Support Plus 24 is the recommended service for this product.

Support Plus 24 is the recommended service for this product.Support Plus 24 is the recommended service for this product.

Support Plus 24 is the recommended service for this product.

Response - Upgrade on-site response from next business day to same day 4-hours

Coverage - Extend hours of coverage from 5 days x 9 hours to 7 days x 24 hours

Duration - Select duration of coverage for a period of 1, 3, or 5 years

Additional Warranty protection and/or HP Installation packages can be purchased.

NOTE:

NOTE:NOTE:

NOTE:

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details

QuickSpecs

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-ClassBrocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Service and Support, HP Care Pack, and Warranty Information

DA - 13084 Worldwide — Version 2 — November 17, 2008

Page 8

HP Care Pack Information

HP Care Pack InformationHP Care Pack Information

HP Care Pack Information

HP Care Pack is defined as an upgrade to the product warranty attribute, available for a specific

duration and hours of coverage.

HP Care Pack is not available for less than the product's warranty duration.

HP Care Pack is available for sale anytime during the warranty period for most products, but the

commencement date will be the same as the Warranty Start Date (delivery date to end user

customer). Proof of purchase may be required.

HP Care Pack services are prepaid.

For additional HP Care Pack (hardware & software) information, as well as orderable part numbers,

please refer to the URL listed below:

http://h20219.www2.hp.com/services/cache/10950-0-0-225-121.html

Additional Services

Additional ServicesAdditional Services

Additional Services

Implementation service, SAN Architecture service. For more information on service options, please visit

our Web site at:

http://www.hp.com/go/san

QuickSpecs

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-ClassBrocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Service and Support, HP Care Pack, and Warranty Information

DA - 13084 Worldwide — Version 2 — November 17, 2008

Page 9

Step 1 – Base Configurations

Step 1 – Base ConfigurationsStep 1 – Base Configurations

Step 1 – Base Configurations

Select one:

Model Name

Model NameModel Name

Model Name

Model Description

Model DescriptionModel Description

Model Description

Part Number

Part NumberPart Number

Part Number

HP B-Series 8/12c SAN

HP B-Series 8/12c SANHP B-Series 8/12c SAN

HP B-Series 8/12c SAN

Switch BladeSystem c-

Switch BladeSystem c-Switch BladeSystem c-

Switch BladeSystem c-

Class

ClassClass

Class

(1) 8 Gb SAN Switch; 12 ports enabled for any combination (internal and external);

two (2) short wave 8 Gb SFP+s; full fabric connectivity; documentation

AJ820A

HP B-Series 8/24c SAN

HP B-Series 8/24c SANHP B-Series 8/24c SAN

HP B-Series 8/24c SAN

Switch BladeSystem c-

Switch BladeSystem c-Switch BladeSystem c-

Switch BladeSystem c-

Class

ClassClass

Class

(1) 8 Gb SAN Switch; 24 ports enabled (16 internal, 8 external); four (4) short wave 8

Gb SFP+s; full fabric connectivity; documentation

AJ821A

HP B-Series 8/24c SAN

HP B-Series 8/24c SANHP B-Series 8/24c SAN

HP B-Series 8/24c SAN

Switch Pwr Pk+

Switch Pwr Pk+Switch Pwr Pk+

Switch Pwr Pk+

BladeSystem c-Class

BladeSystem c-ClassBladeSystem c-Class

BladeSystem c-Class

(1) 8 Gb SAN Switch; 24 ports enabled (16 internal, 8 external); four (4) short wave 8

Gb SFP+s; full fabric connectivity; documentation and includes Power Pack+ Bundle

and management tools (see software components, optional)

AJ822A

* #0D1 may appear after this part number on your sales order when factory

integration is indicated.

Step 2 – Additional Options

Step 2 – Additional OptionsStep 2 – Additional Options

Step 2 – Additional Options

Select each type of required options with quantities specified:

Hardware:

Hardware:Hardware:

Hardware:

Model Name

Model NameModel Name

Model Name

Model Description

Model DescriptionModel Description

Model Description

Part Number

Part NumberPart Number

Part Number

8 Gb Optical Transceivers

8 Gb Optical Transceivers8 Gb Optical Transceivers

8 Gb Optical Transceivers

(SFP+s)

(SFP+s)(SFP+s)

(SFP+s)

Short Wave:

HP 8Gb SW B-series FC SFP+

AJ716A

Long Wave:

HP 8Gb Long Wave B-series 10km FC SFP+ 1 Pack

AJ717A

4 Gb Optical Transceivers

4 Gb Optical Transceivers4 Gb Optical Transceivers

4 Gb Optical Transceivers

(SFPs)

(SFPs)(SFPs)

(SFPs)

Short Wave:

HP 4Gb SW B-series FC SFP

AJ715A

Long Wave :

HP 4Gb LW B-series 10km FC SFP

AK870A

Long Wave :

HP 4Gb LW B-series 35km FC SFP 1 Pack

AN211A

Optical cables

Optical cablesOptical cables

Optical cables

LC-LC for between 4/8 Gb and 4/8 Gb Fibre Channel devices

LC-LC for between 4/8 Gb and 4/8 Gb Fibre Channel devicesLC-LC for between 4/8 Gb and 4/8 Gb Fibre Channel devices

LC-LC for between 4/8 Gb and 4/8 Gb Fibre Channel devices

.5 m LC-LC Multi-Mode OM3 Fibre Channel Cable

AJ833A

1 m LC-LC Multi-Mode OM3 Fibre Channel Cable

AJ834A

2 m LC-LC Multi-Mode OM3 Fibre Channel Cable

AJ835A

5 m LC-LC Multi-Mode OM3 Fibre Channel Cable

AJ836A

15 m LC-LC Multi-Mode OM3 Fibre Channel Cable

AJ837A

30 m LC-LC Multi-Mode OM3 Fibre Channel Cable

AJ838A

50 m LC-LC Multi-Mode OM3 Fibre Channel Cable

AJ839A

LC-LC for between 2/4/8 Gb and 2/4/8 Gb Fibre Channel devices

LC-LC for between 2/4/8 Gb and 2/4/8 Gb Fibre Channel devicesLC-LC for between 2/4/8 Gb and 2/4/8 Gb Fibre Channel devices

LC-LC for between 2/4/8 Gb and 2/4/8 Gb Fibre Channel devices

2 m LC-LC Multi-Mode Fibre Channel Cable

221692-B21

5 m LC-LC Multi-Mode Fibre Channel Cable

221692-B22

15 m LC-LC Multi-Mode Fibre Channel Cable

221692-B23

30 m LC-LC Multi-Mode Fibre Channel Cable

221692-B26

50 m LC-LC Multi-Mode Fibre Channel Cable

221692-B27

LC-SC for between a 1 Gb and 2/4 Gb Fibre Channel devices

LC-SC for between a 1 Gb and 2/4 Gb Fibre Channel devicesLC-SC for between a 1 Gb and 2/4 Gb Fibre Channel devices

LC-SC for between a 1 Gb and 2/4 Gb Fibre Channel devices

2 m LC-SC Multi-Mode Fibre Channel Cable

221691-B21

5 m LC-SC Multi-Mode Fibre Channel Cable

221691-B22

QuickSpecs

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-ClassBrocade 8Gb SAN Switch for HP BladeSystem c-Class

Brocade 8Gb SAN Switch for HP BladeSystem c-Class

Configuration Information

DA - 13084 Worldwide — Version 2 — November 17, 2008

Page 10

Tabla de contenidos

Otros manuales de Cambiar de Brocade Communications Systems
