Briggs & Stratton 326400 Series Guía de configuración

in any form or by any means, electronic or mechanical, including photocopying,

recording or by any information storage and retrieval system, without permission

in writing from Briggs & Stratton Corporation.

PRINTED IN U.S.A.

FORM MS6179−03/18/2009

REPLACES FORM MS6179−08/23/2007

FILE IN SECT. 2 OF SERVICE MANUAL

326400

Illustrated Parts List

Model Series

326400

TYPE NUMBERS:

0010 through 0080,

0110 through 0399,

0611, 0620,

0630 through 0799,

0801, 0802, 0803, 0804, 0805,

1160, 2520, 2521, 2522, 2526, 2527,

2528, 2529, 2530, 2550, 2560, 2561,

2562, 2563, 2580, 2581, 2582, 2583, 2596.

Not for

Reproduction

326400

6179−2Assemblies include all parts shown in frames. 03/18/2009

13A

383

635

308

337

645

406

342

989

307

724A

724

722

989A

362

322

552

626

871

870

415

306

1 395663 Cylinder Assembly

5 691712 Head−Cylinder

6 691261 Washer

(Cylinder Head)

7 692231 Gasket−Cylinder Head

8 495738 Breather Assembly

9 27803s Gasket−Breather

10 690294 Screw

(Breather Assembly)

11 691512 Tube−Breather

13 691614 Screw

(Cylinder Head)

(1 3/4” Long)

−−−−−−− Note −−−−−

691640 Screw

(Cylinder Head)

(2 1/16” Long)

13A 691441 Screw

(Cylinder Head)

(2 7/16” Long)

14 691690 Stud

(Cylinder Head)

15 692833 Plug−Oil Drain

306 299536 Shield−Cylinder

307 690294 Screw

(Cylinder Shield)

308 691731 Cover−Cylinder Head

(Used After Code Date

75060800).

−−−−−−− Note −−−−−

221953 Cover−

Cylinder Head

(Used Before Code

Date 75060900).

Used on Type No(s).

0291, 0648.

322 692198 Screw

(Cylinder Head Cover)

337 802592s Plug−Spark

342 298125s Plunger−Breaker

362 793351 Shield−Spark Plug

383 89838 Wrench−Spark Plug

406 690533 Spring−Breather Tube

415 692882 Plug

(Cylinder)

552 393666 Bushing−

Governor Crank

626 690512 Spacer−

Governor Crank

635 66538s Boot−Spark Plug

645 692880 Bushing−Plunger

722 68768 Seal−Plunger

724 93516 Retainer−Seal

724A 221873 Retainer−Seal

870 691583 Seat−Valve

(Exhaust)

871 231218 Bushing−Valve Guide

989 690578 Stop Switch−

Spark Plug

−−−−−−− Note −−−−−

293739 Stop Switch−

Spark Plug

Used on Type No(s).

0200.

298926 Stop Switch−

Spark Plug

Used on Type No(s).

0028, 0062, 0138,

0187, 0195, 0220,

0232, 0237, 0238,

0243, 0266, 0295,

0320, 0327, 0658,

0663, 0675, 0680,

0681, 0687, 0691,

0729, 0730, 0735,

2528, 2562.

390785 Stop Switch−

Spark Plug

Used on Type No(s).

0640, 0734.

989A 690633 Stop Switch−

Spark Plug

Engine Gasket Set−Reference 358

Carburetor Overhaul Kit−Reference 121

Valve Gasket Set−Reference 1095

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Not for

Reproduction

326400

6179−3Assemblies include all parts shown in frames. 03/18/2009

45 45

33 34

225

553

742

591

900A

598

743

746

900

407

511

1144

755

1143

552

626

219

219A

221

25 792365 Piston Assembly

(Standard)

−−−−−−− Note −−−−−

792367 Piston

Assembly

(.020 Oversize)

26 792366 Ring Set

(Standard)

−−−−−−− Note −−−−−

792368 Ring Set

(.020 Oversize)

27 691792 Lock−Piston Pin

28 299691 Pin−Piston

29 299632 Rod−Connecting

30 691726 Dipper−

Connecting Rod

31 690396 Lock−Rod Screw

32 692345 Screw

(Connecting Rod)

33 394436 Valve−Exhaust

34 394435 Valve−Intake

35 691597 Spring−Valve

(Intake)

36 691597 Spring−Valve

(Exhaust)

40 691939 Retainer−Valve

−−−−−−− Note −−−−−

690274 Retainer−

Valve

Used on Type No(s).

0722.

42 494553 Keeper−Valve

(Used After Code Date

80111200).

−−−−−−− Note −−−−−

68283 Keeper−Valve

(Used Before Code

Date 80111300).

45 691594 Tappet−Valve

46 692855 Camshaft

219 291192 Gear−Governor

(Used Before Code

Date 78062000).

219A 393720 Gear−Governor

221 841026 Cup−Governor

225 691357 Shaft−Governor Gear

407 690810 Screw

(Camshaft Bearing)

511 690402 Washer

(Camshaft Bearing)

552 393666 Bushing−

Governor Crank

553 690269 Retainer−Valve Spring

591 691746 Plug−Camshaft

598 270516 Shim−End Play

(Camshaft Bearing)

(.009 Thick)

−−−−−−− Note −−−−−

270517 Shim−

End Play

(Camshaft Bearing)

(.007 Thick)

270518 Shim−

End Play

(Camshaft Bearing)

(.005 Thick)

626 690512 Spacer−Governor

Crank

742 691080 Retainer−E Ring

743 691153 Gear−Drive

746 691803 Gear−Idler

755 299706 Bearing−Camshaft

900 691767 Shaft−Gear

900A 691768 Shaft−Gear

1143 691081 Screw

(Drive Gear Cover)

1144 690301 Washer

(Drive Gear Cover)

Engine Gasket Set−Reference 358

Carburetor Overhaul Kit−Reference 121

Valve Gasket Set−Reference 1095

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Not for

Reproduction

326400

6179−4Assemblies include all parts shown in frames. 03/18/2009

357

16 691797 Crankshaft

−−−−−−−Note −−−−−

690534 Crankshaft

Used on Type No(s).

0237, 0133, 0190,

0252, 0315, 0788,

2582.

261222 Crankshaft

Used on Type No(s).

0139, 0204, 0228,

0328, 0678.

690535 Crankshaft

Used on Type No(s).

0050, 0116, 0130,

0143, 0147, 0149,

0150, 0151, 0156,

0167, 0170, 0172,

0173, 0174, 0185,

0186, 0188, 0192,

0193, 0208, 0219,

0231, 0248, 0257,

0286, 0290, 0310,

0317, 0318, 0329,

0337, 0343, 0371,

0636, 0638, 0666,

0669, 0684, 0690,

0706, 0721, 0751,

2550.

690536 Crankshaft

Used on Type No(s).

0022, 0063, 0114,

0129, 0153, 0175,

0176, 0183, 0198,

0205, 0217, 0224,

0233, 0235, 0236,

0238, 0247, 0255,

0261, 0265, 0266,

0273, 0277, 0278,

0279, 0285, 0287,

0291, 0296, 0303,

0320, 0334, 0338,

0340, 0344, 0345,

0346, 0347, 0348,

0353, 0359, 0361,

0363, 0366, 0367,

0374, 0375, 0383,

0385, 0394, 0396,

0633, 0634, 0648,

0650, 0654, 0661,

0671, 0674, 0676,

0680, 0687, 0692,

0693, 0694, 0696,

0698, 0699, 0702,

0703, 0708, 0714,

0718, 0722, 0724,

0729, 0733, 0736,

0746, 0753, 0754,

0757, 0764, 0771,

0772, 0774, 0776,

0782, 0787, 2522,

2563, 2596.

Crankshaft

(NO LONGER

AVAILABLE)

Used on Type No(s).

0158, 0160, 0197,

0216, 0237.

690537 Crankshaft

Used on Type No(s).

0210, 0262, 0630.

690540 Crankshaft

Used on Type No(s).

0062, 0241, 0242,

0243, 0244, 0260,

0269, 0272, 0292,

0295, 0297, 0300,

0302, 0312, 0327,

0352, 0365, 0369,

0373, 0391, 0635,

0670, 0681, 0686,

0691, 0719, 0723,

0726, 0730, 0732,

0735, 0737, 0740,

0744, 0745, 0750,

0755, 0759, 0780,

0786, 2562.

690541 Crankshaft

Used on Type No(s).

0061, 0124, 0246,

0253, 0305, 0308,

0335, 0341, 0342,

0646, 0710, 0711,

0713, 0728, 0781,

0785, 2529, 2561.

690543 Crankshaft

Used on Type No(s).

0259, 0293, 0647,

0756.

691806 Crankshaft

(Used After Code Date

77072410).

Used on Type No(s).

0021, 0112, 0128,

0181, 0189, 0203,

0209, 0254, 0256,

0258, 0314, 0321,

0357, 0362, 0368,

0395, 0656, 0668,

0675, 0709, 0717,

0739, 0743, 0752,

0765, 0778, 0779,

0784, 0789, 0790,

0792, 0793, 0794,

0801, 0802, 0804,

2521, 2526, 2530.

Crankshaft

(Used Before Code

Date 77072510).

(NO LONGER

AVAILABLE)

Used on Type No(s).

0021, 0112, 0128,

0181, 0189, 0203,

0209, 0254, 0256,

0258, 0314, 0321,

0357, 0362, 0368,

0395, 0656, 0668,

0675, 0709, 0717,

0739, 0743, 0752,

0765, 0778, 0779,

0784, 0789, 0790,

0792, 0793, 0794,

0801, 0802, 0804,

2521, 2526, 2530.

690546 Crankshaft

Used on Type No(s).

0682, 2560.

261944 Crankshaft

Used on Type No(s).

0720, 0758, 0788.

17 691938 Bearing−Ball

24 222698s Key−Flywheel

357 691483 Key−Drive Pulley

Engine Gasket Set−Reference 358

Carburetor Overhaul Kit−Reference 121

Valve Gasket Set−Reference 1095

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Not for

Reproduction

326400

6179−5Assemblies include all parts shown in frames. 03/18/2009

569

15A

568

15B

567

998

998A

15A 690946 Plug−Oil Drain

15B 691680 Plug−Oil Drain

21 281658s Cap−Oil Fill

567 691104 Screw

(Engine Base)

568 294751 Base−Engine

Used on Type No(s).

0020, 0023, 0050,

0139, 0145, 0150,

0151, 0152, 0155,

0159, 0175, 0191,

0199, 0203, 0206,

0208, 0212, 0218,

0219, 0226, 0356,

0804, 2527, 2583.

−−−−−−− Note −−−−−

291404 Base−

Engine

Used on Type No(s).

0134, 0135.

568 294751 Base−Engine

Used on Type No(s).

0062, 0120, 0121,

0123, 0126, 0127,

0133, 0135, 0136,

0140, 0144, 0149,

0157, 0158, 0162,

0163, 0164, 0165,

0169, 0170, 0172,

0173, 0174, 0178,

0180, 0182, 0183,

0184, 0185, 0186,

0190, 0192, 0198,

0201, 0204, 0205,

0210, 0215, 0222,

0223, 0227, 0228,

0230, 0234, 0235,

0240, 0246, 0248,

0252, 0253, 0254,

0255, 0259, 0262,

0283, 0284, 0291,

0293, 0306, 0308,

0310, 0311, 0312,

0315, 0316, 0326,

0328, 0331, 0333,

0341, 0351, 0354,

0360, 0384, 0392,

0630, 0638, 0647,

0648, 0649, 0659,

0660, 0669, 0673,

0678, 0679, 0686,

0705, 0712, 0723,

0724, 0725, 0726,

0732, 0735, 0737,

0740, 0744, 0750,

0755, 0756, 0759,

0780, 0781, 0786,

2562, 2581, 2582.

569 691569 Gasket−Engine Base

998 690307 Pipe−Oil

998A 690502 Pipe−Oil

Engine Gasket Set−Reference 358

Carburetor Overhaul Kit−Reference 121

Valve Gasket Set−Reference 1095

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Not for

Reproduction

326400

6179−6Assemblies include all parts shown in frames. 03/18/2009

593A

593

228 228A

1141

571 571B

20A

571A

20 691948 Seal−Oil

(PTO Side)

20A 291675s Seal−Oil

(PTO Side)

228 691681 Screw

(Bearing Support)

228A 691058 Screw

(Bearing Support)

571 391062 Support−Bearing

571A 291665 Support−Bearing

Used on Type No(s).

0022, 0050, 0062,

0063, 0112, 0113,

0114, 0116, 0130,

0143, 0147, 0149,

0150, 0151, 0153,

0156, 0160, 0167,

0171, 0172, 0173,

0174, 0175, 0176,

0183, 0185, 0186,

0188, 0192, 0193,

0196, 0197, 0198,

0205, 0208, 0209,

0216, 0217, 0219,

0224, 0233, 0235,

0236, 0241, 0242,

0244, 0247, 0255,

0256, 0257, 0260,

0261, 0265, 0266,

0269, 0272, 0273,

0277, 0278, 0279,

0285, 0286, 0287,

0290, 0291, 0292,

0296, 0297, 0302,

0303, 0304, 0310,

0312, 0318, 0327,

0329, 0334, 0337,

0338, 0340, 0344,

0345, 0347, 0357,

0359, 0361, 0368,

0373, 0374, 0383,

0385, 0395, 0396,

0634, 0636, 0648,

0650, 0656, 0661,

0666, 0670, 0671,

0674, 0675, 0684,

0686, 0690, 0692,

0693, 0696, 0698,

0699, 0702, 0703,

0706, 0708, 0709,

0714, 0717, 0721,

0724, 0726, 0732,

0733, 0735, 0737,

0739, 0740, 0743,

0744, 0745, 0746,

0750, 0751, 0752,

0753, 0754, 0755,

0757, 0759, 0771,

0776, 0780, 0783,

0784, 0789, 0794,

0801, 0802, 2522,

2550, 2562, 2563,

2596.

−−−−−−− Note −−−−−

291710 Support−

Bearing

Used on Type No(s).

0647, 0668, 0682,

0713, 0717, 0755,

0772, 0782, 0788,

0790, 0792, 0793,

0801, 0804, 2521,

2530.

571B 299705 Support−Bearing

(Magneto Side)

593 691311 Gasket−

Bearing Support

593A 270513 Gasket−

Bearing Support

(.015 Thick)

−−−−−−− Note −−−−−

270514 Gasket−

Bearing Support

(.010 Thick)

270515 Gasket−

Bearing Support

(.005 Thick)

1141 690402 Washer

(Bearing Support)

Engine Gasket Set−Reference 358

Carburetor Overhaul Kit−Reference 121

Valve Gasket Set−Reference 1095

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Not for

Reproduction

326400

6179−7Assemblies include all parts shown in frames. 03/18/2009

524

525

523

399

338

704

276

366

587

749A

749

523A

1054

399A

758 3

665A

665

3 691948 Seal−Oil

(Magneto Side)

276 690258 Washer−Sealing

338 690270 Gasket−Dipstick

366 690304 Screw

(Timing Hole Plug)

399 691310 Gasket−

Counterweight Cover

(Magneto Side)

399A 692914 Gasket−

Counterweight Cover

(PTO Side)

523 691352 Dipstick

523A 690620 Dipstick

524 281370s Seal−Dipstick Tube

525 690622 Tube−Dipstick

−−−−−−− Note −−−−−

690623 Tube−Dipstick

Used on Type No(s).

0121, 0144, 0157,

0158, 0164, 0165,

0169, 0170, 0182,

0184, 0192, 0198,

0210, 0222, 0234,

0235, 0240, 0248,

0262, 0266, 0309,

0312, 0316, 0331,

0338, 0341, 0351,

0358, 0630, 0638,

0679, 0705, 0707,

0724, 0744, 0750,

0755, 0770, 1160,

2581.

587 690389 Clamp−Cable

665 298860 Minder−Oil

665A 692939 Minder−Oil

704 691083 Screw

(Counterweight Cover)

749 391061 Cover−Counterweight

749A 391361 Cover−Counterweight

(Used on Alternator

Equipped Engines)

758 393164 Counterweight

1054 280275 Tie−Cable

Engine Gasket Set−Reference 358

Carburetor Overhaul Kit−Reference 121

Valve Gasket Set−Reference 1095

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Not for

Reproduction

326400

6179−8Assemblies include all parts shown in frames. 03/18/2009

109

134

1227

SEE PAGE 9

FOR ADDITIONAL

SERVICE PART

INFORMATION

90 391065 Carburetor

−−−−−−−Note −−−−−

391068 Carburetor

Used on Type No(s).

0121, 0144, 0157,

0158, 0164, 0165,

0169, 0170, 0184,

0192, 0240, 0331.

391070 Carburetor

Used on Type No(s).

0127, 0133, 0134,

0135, 0136, 0139,

0140, 0149, 0162,

0163, 0166, 0172,

0173, 0180, 0185,

0186, 0201, 0204,

0206, 0211, 0212,

0213, 0226, 0227,

0228, 0229, 0249,

0251, 0271, 0298,

0326, 0328, 0332.

392035 Carburetor

Used on Type No(s).

0182, 0210, 0222,

0309.

393431 Carburetor

Used on Type No(s).

0262, 0630.

392235 Carburetor

Used on Type No(s).

0198, 0234, 0235,

0248, 0266, 0312,

0316, 0338, 0341,

0351, 0358, 0707,

0724, 0744, 0750,

0759, 0770.

109 691353 Shaft−Choke

−−−−−−− Note −−−−−

690617 Shaft−Choke

Used on Type No(s).

0121, 0127, 0133,

0134, 0135, 0136,

0139, 0140, 0144,

0149, 0157, 0158,

0162, 0163, 0164,

0165, 0166, 0169,

0170, 0172, 0180,

0184, 0185, 0186,

0192, 0201, 0204,

0206, 0211, 0212,

0213, 0226, 0227,

0228, 0229, 0249,

0251, 0271, 0298,

0326, 0328, 0332,

2581, 2582.

134 394681 Kit−Needle/Seat

−−−−−−− Note −−−−−

394682 Kit−Needle/

Seat

(Includes Brass Seat)

394683 Kit−Needle/

Seat

(Includes Brass Seat)

(For Use With Impulse

Pump)

1227 99525s Valve−High Speed

Engine Gasket Set−Reference 358

Carburetor Overhaul Kit−Reference 121

Valve Gasket Set−Reference 1095

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Not for

Reproduction

326400

6179−9Assemblies include all parts shown in frames. 03/18/2009

108

109

127

102

133

104

101

150

689

130

231

1146

689A

267

110

971

132

158

800

142

186

51A

134

107 94

1227

50 691152 Manifold−Intake

−−−−−−−Note −−−−−

692525 Manifold−

Intake

Used on Type No(s).

0248, 0308, 0358,

0638, 0707, 0770.

51 27381 Gasket−Intake

51A 692214 Gasket−Intake

54 691681 Screw

(Intake Manifold)

90 Carburetor

(See Previous Page)

91 299687 Body−

Upper Carburetor

−−−−−−− Note −−−−−

391067 Body−

Upper Carburetor

Used on Type No(s).

0121, 0144, 0157,

0158, 0164, 0165,

0169, 0170, 0182,

0184, 0192, 0240,

0309, 0331, 0630,

0707, 0724, 0770.

94 292681 Kit−Idle Mixture

95 691437 Screw

(Throttle Valve)

97 691944 Shaft−Throttle

98 693942 Kit−Idle Speed

101 691616 Pin−Shaft

102 692215 Gasket−

Carburetor Body

104 691775 Pin−Float Hinge

107 391069 Body−

Lower Carburetor

108 690621 Valve−Choke

109 Shaft−Choke

(See Previous Page)

110 691186 Washer

(Choke Shaft)

127 690627 Plug−Welch

130 691727 Valve−Throttle

132 691708 Stop−Throttle

133 692265 Float−Carburetor

134 Kit−Needle/Seat

(See Previous Page)

142 691966 Nozzle−Carburetor

(Standard)

(Labeled B)

(Used After Code Date

81090800).

−−−−−−− Note −−−−−

390950 Nozzle−

Carburetor

(Standard)

(Labeled 40)

(Used Before Code

Date 81090900).

150 691610 Gasket−Nozzle

158 27590 Plug−

Carburetor Filter/Drain

186 691764 Connector−Hose

231 691437 Screw

(Choke Valve)

267 691082 Screw

(Casing Clamp)

689 691591 Spring−Friction

689A 691590 Spring−Friction

800 Retainer−

Carburetor Drain

(NO LONGER

AVAILABLE)

971 691090 Screw

(Air Cleaner Base

to Carburetor)

1146 691587 Screw

(Choke Shaft)

1227 Valve−High Speed

(See Previous Page)

Engine Gasket Set−Reference 358

Carburetor Overhaul Kit−Reference 121

Valve Gasket Set−Reference 1095

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Not for

Reproduction

326400

6179−10 Assemblies include all parts shown in frames. 03/18/2009

212

208

206A

162

209 211

232

203

614

404

206

205

562

505

668

270

268

269

271

629

227

616

205A

414

201

266

162 690267 Collar−Bell Crank

201 261027 Link−Air Vane

Used on Type No(s).

0234, 0705.

203 690263 Crank−Bell

205 691681 Screw

(Bell Crank)

Used on Type No(s).

0136, 0139, 0204,

0228, 0234, 0248,

0328, 0678, 0705.

205A 690810 Screw

(Bell Crank)

206 691079 Nut−Governor

Adjusting

206A 691584 Nut−

Governor Adjusting

208 393613 Rod−Governor Control

209 691596 Spring−Governor

−−−−−−− Note −−−−−

691789 Spring−

Governor

Used on Type No(s).

0611, 0630, 0647,

0651, 0690, 0760,

0781, 0801, 2520,

2527, 2528, 2529,

2550, 2581, 2582.

211 691790 Spring−Governed Idle

Used on Type No(s).

0611, 0630, 0647,

0651, 0690, 0760,

0781, 0801, 2520,

2527, 2528, 2529,

2550, 2581, 2582.

212 691791 Link−Throttle

−−−−−−− Note −−−−−

691595 Link−Throttle

Used on Type No(s).

0248, 0308, 0358,

0638, 0707, 0770.

227 690607 Lever−

Governor Control

−−−−−−− Note −−−−−

690616 Lever−

Governor Control

Used on Type No(s).

0611, 0630, 0647,

0651, 0684, 0690,

0706, 0721, 0660,

0671, 0675, 0681,

0683, 0685, 0689,

0692, 0694, 0697,

0699, 0801, 2520,

2527, 2528, 2529,

2550, 2561, 2581,

2582.

232 690545 Spring−Governor Link

−−−−−−− Note −−−−−

692207 Spring−

Governor Link

Used on Type No(s).

0248, 0308, 0358,

0638, 0707, 0770.

266 494554 Control−Throttle

−−−−−−− Note −−−−−

Control−Throttle

(Dial Control)

(NO LONGER

AVAILABLE)

Used on Type No(s).

0640, 0652, 0653,

0665.

268 691025 Casing−Control Wire

(Cut to

Required Length)

269 691026 Wire−Control

(Cut to

Required Length)

270 691027 Nut

(Control Wire Casing)

271 691028 Lever−Control

−−−−−−− Note −−−−−

221987 Lever−Control

Used on Type No(s).

0678, 0705.

404 690264 Washer

(Governor Crank)

414 692810 Washer

(Bell Crank)

Used on Type No(s).

0136, 0139, 0204,

0228, 0234, 0248,

0328, 0678, 0705.

505 691251 Nut

(Governor

Control Lever)

562 92613 Bolt

(Governor

Control Lever)

614 691620 Pin−Cotter

616 291364 Crank−Governor

629 690538 Spring−Throttle Return

Used on Type No(s).

0234, 0631, 0632,

0637, 0641, 0642,

0705, 0803, 2580.

668 690313 Spacer

(Governor

Control Rod)

Engine Gasket Set−Reference 358

Carburetor Overhaul Kit−Reference 121

Valve Gasket Set−Reference 1095

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

Not for

Reproduction

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Motor de Briggs & Stratton

Briggs & Stratton

Briggs & Stratton 82500 Manual

Briggs & Stratton

Briggs & Stratton 133200 Series Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 400000 Professional Series Manual de usuario

Briggs & Stratton

Briggs & Stratton 080000 Manual de usuario

Briggs & Stratton

Briggs & Stratton 120000 Manual de usuario

Briggs & Stratton

Briggs & Stratton 110600 series Manual de usuario

Briggs & Stratton

Briggs & Stratton 90000 series Manual de usuario

Briggs & Stratton

Briggs & Stratton 84100 Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 440000 Professional Series Manual de usuario

Briggs & Stratton

Briggs & Stratton 192400 Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 386447-0090-G1 Manual de usuario

Briggs & Stratton

Briggs & Stratton Vanguard 290000 Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 445600 Series Guía de configuración

Briggs & Stratton

Briggs & Stratton 319700 Series Guía de configuración

Briggs & Stratton

Briggs & Stratton Quantum 650 Series Manual de usuario

Briggs & Stratton

Briggs & Stratton 290000 A Manual de usuario

Briggs & Stratton

Briggs & Stratton 405777 Series Manual de usuario

Briggs & Stratton

Briggs & Stratton Vanguard 540000 Series Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 83100 Manual de usuario

Briggs & Stratton

Briggs & Stratton 150000 HORIZONTAL SERIES Manual de usuario

Briggs & Stratton

Briggs & Stratton VANGUARD 810 EFI Instrucciones de funcionamiento

Briggs & Stratton

Briggs & Stratton 310000 VERTICAL SERIES Manual de usuario

Briggs & Stratton

Briggs & Stratton MS3419 Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 12L800 Series Guía de configuración

Manuales populares de Motor de otras marcas

Rotax

Rotax 125 senior MAX evo Manual de usuario

Kohler

Kohler K361 Manual de usuario

MTD

MTD OHV Series Manual de usuario

Kohler

Kohler COMMAND CH18-745 Manual de usuario

Mercury

Mercury D4.2L D-Tronic Manual de usuario

Selve

Selve SE Plus-RC Series Manual de usuario

Perkins

Perkins 1206E-E66TA Manual de usuario

Skov

Skov DA 174 Manual

Rossi

Rossi TX11 Series Manual de usuario

Siemens

Siemens SIMOTICS T-1FW3 Hoja de instrucciones

AL-KO

AL-KO PRO 350 Manual de usuario

MTU

MTU 12 V 4000 Lx4 Manual de usuario

Nanni

Nanni N3.30 Manual de instrucciones

Nanni

Nanni N5.160 CR2 Manual de usuario

KSB

KSB SuPreme Series Instrucciones de instalación

Hiwin

Hiwin EM1 Series Manual de usuario

Rotax

Rotax 912 i series Instrucciones de funcionamiento

Siemens

Siemens SIMOTICS XP 1MB1 Manual de usuario
