Briggs & Stratton 31P700 Series Guía de configuración

in any form or by any means, electronic or mechanical, including photocopying,

recording or by any information storage and retrieval system, without permission

in writing from Briggs & Stratton Corporation.

PRINTED IN U.S.A.

FORM MS--5766--10/17/2008

REPLACES FORM MS--5766--04/11/2008

FILE IN SECT. 2 OF SERVICE MANUAL

31P700

Illustrated Parts List

Model Series

31P700

TYPE NUMBERS

0115 through 1076.

TABLE OF CONTENTS

Air Cleaner 5.........................

Alternator 7..........................

Blower Housing 5.....................

Camshaft 2...........................

Carburetor 4..........................

Controls 7............................

Crankshaft 2..........................

Cylinder 2............................

Cylinder Head 3.......................

Electric Starter 7......................

Engine Sump 2.......................

Exhaust System 5.....................

Flywheel 6............................

Fuel Supply 4.........................

Gasket Set -- Engine 2.................

Gasket Set -- Valve 3..................

Governor Spring 7....................

Ignition 7.............................

Intake Manifold 3.....................

Kit -- Carburetor Overhaul 4............

Lubrication 3.........................

Operator’s Manual 2..................

Piston, Rings, Connecting Rod 2.......

Valves 3..............................

Warnining Label 2....................

Not for

Reproduction

31P700

5766--6 Assemblies include all parts shown in frames. 10/17/2008

783

1051

363 1044

1070

1005

1005A

415A

1070A

73A

1005B

73B

Not for

Reproduction

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

31P700

KIncluded in Engine Gasket Set--Ref. No. 358.

DIncluded in Carburetor Overhaul Kit--Ref. No. 121, or 121A.

zIncluded in Carburetor Gasket Set--Ref. No. 977.

∆Included in Valve Gasket Set--Ref. No. 1095.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5766--10 Assemblies include all parts shown in frames. 10/17/2008

117 694352 Jet--Main

(Standard)

117A 843099 Jet--Main

(Standard)

Used on Type No(s).

0140, 0141, 0203.

-- -- -- -- -- -- N o t e -- -- -- -- -- --

843099 Jet--Main

(Standard)

(Used After Code Date

08042700).

Used on Type No(s).

0131, 0135.

699457 Jet--Main

(Standard)

(Used Before Code

Date 08042800).

Used on Type No(s).

0131, 0135.

843099 Jet--Main

(Standard)

(Used After Code Date

08051300).

Used on Type No(s).

0116, 0125, 0133,

0134, 0293, 0299,

0371, 0378, 0581,

0602, 0899.

699457 Jet--Main

(Standard)

(Used Before Code

Date 08051400).

Used on Type No(s).

0116, 0125, 0133,

0134, 0293, 0299,

0371, 0378, 0581,

0602, 0899.

699457 Jet--Main

(Standard)

118 697228 Jet--Main

(High Altitude)

118A 790890 Jet--Main

(High Altitude)

Used on Type No(s).

0140, 0141, 0203.

-- -- -- -- -- -- N o t e -- -- -- -- -- --

790890 Jet--Main

(High Altitude)

(Used After Code Date

08042700).

Used on Type No(s).

0131, 0135.

699458 Jet--Main

(High Altitude)

(Used Before Code

Date 08042800).

Used on Type No(s).

0131, 0135.

790890 Jet--Main

(High Altitude)

(Used After Code Date

08051300).

Used on Type No(s).

0116, 0125, 0133,

0134, 0293, 0299,

0371, 0378, 0581,

0602, 0899.

699458Jet--Main

(High Altitude)

(Used Before Code

Date 08051400).

Used on Type No(s).

0116, 0125, 0133,

0134, 0293, 0299,

0371, 0378, 0581,

0602, 0899.

699458 Jet--Main

(High Altitude)

121 697241 Kit--Carburetor

Overhaul

(Walbro Carburetor)

121A 699521 Kit--Carburetor

Overhaul

(Nikki Carburetor)

125 793224 Carburetor

(Walbro)

125A 796109 Carburetor

(Nikki)

Used on Type No(s).

0140, 0141, 0203.

-- -- -- -- -- -- N o t e -- -- -- -- -- --

796109 Carburetor

(Nikki)

(Used After Code Date

08042700).

Used on Type No(s).

0131, 0135.

792358 Carburetor

(Nikki)

(Used Before Code

Date 08042800).

Used on Type No(s).

0131, 0135.

796109 Carburetor

(Nikki)

(Used After Code Date

08051300).

Used on Type No(s).

0116, 0125, 0133,

0134, 0293, 0299,

0371, 0378, 0581,

0602, 0899.

792358 Carburetor

(Nikki)

(Used Before Code

Date 08051400).

Used on Type No(s).

0116, 0125, 0133,

0134, 0293, 0299,

0371, 0378, 0581,

0602, 0899.

792358 Carburetor

(Nikki)

127 695005 Plug--Welch

(5/16” Diameter)

127A D690727 Plug--Welch

130 691750 Valve--Throttle

Not for

Reproduction

Not for

Reproduction
