217900

Illustrated Parts List

Model Series

217900

TYPE NUMBER

0015 through 0141.

TABLE OF CONTENTS

Air Cleaner 6. . . . . . . . . . . . . . . . . . . . . . . . .

Alternator 9. . . . . . . . . . . . . . . . . . . . . . . . . .

Blower Housing 6. . . . . . . . . . . . . . . . . . . . .

Camshaft 3. . . . . . . . . . . . . . . . . . . . . . . . . . .

Carburetor 5. . . . . . . . . . . . . . . . . . . . . . . . . .

Controls 8. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Crankshaft 3. . . . . . . . . . . . . . . . . . . . . . . . .

Cylinder 2. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cylinder Head 4. . . . . . . . . . . . . . . . . . . . . .

Electric Starter 7. . . . . . . . . . . . . . . . . . . . . .

Engine Sump 2. . . . . . . . . . . . . . . . . . . . . . .

Exhaust System 6. . . . . . . . . . . . . . . . . . . .

Flywheel 7. . . . . . . . . . . . . . . . . . . . . . . . . . .

Fuel Supply 8. . . . . . . . . . . . . . . . . . . . . . . . .

Gasket Set −Engine 4. . . . . . . . . . . . . . . . .

Gasket Set −Valve 4. . . . . . . . . . . . . . . . . .

Intake Manifold 4. . . . . . . . . . . . . . . . . . . . .

Ignition 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Kit −Carburetor Overhaul 5. . . . . . . . . . . .

Lubrication 3. . . . . . . . . . . . . . . . . . . . . . . . .

Operator’s Manual 2. . . . . . . . . . . . . . . . . .

Piston, Rings, Connecting Rod 3. . . . . . .

Rewind Starter 7. . . . . . . . . . . . . . . . . . . . . .

Valves 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Warning Label 2. . . . . . . . . . . . . . . . . . . . . .

217900

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5708−2Assemblies include all parts shown in frames. 03/03/2008

750

943

1024

965

1024A

307

306

691

718

552

584

1263

1264

1027

1017

415

239

1058 OPERATOR’S MANUAL 1319 WARNING LABEL

REQUIRED when replacing parts

with warning labels affixed.

850

217900

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5708−3Assemblies include all parts shown in frames. 03/03/2008

842

524

847

523

525

741

146

357

1270

757

758

759

217900

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5708−4Assemblies include all parts shown in frames. 03/03/2008

654

635

830

1034

1022

883

238

36 868

1022

1023

914

1022

868

1095 VALVE GASKET SET

383

192

1022

358 ENGINE GASKET SET

868

691

524

883

1266

842

1029

1026

1266A

337

705

943

617 51

51A

617

51A

617

51A

850

50B 51

617

186

217900

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5708−5Assemblies include all parts shown in frames. 03/03/2008

104

105

106

137

142

987

127

634

276

121 CARBURETOR OVERHAUL KIT

977 CARBURETOR GASKET SET

51 137 276

1266

1266A

950

276

137

104

105

142 1091

987

130

LMT / PART

NUMBER

LOCATIONS 106

131

133

975

WALBRO

143

127

141

231

108

692

104A

105A

634A

987A

95A

130A

NIKKI

98A

133A

94A

141A

131A

127A

108A

117

118

1091

125A

1127

975A

137A

121A CARBURETOR OVERHAUL KIT

95A

104A

105A

127A

634A

1266

1266A

987A

137A137A137A137A

977A CARBURETOR GASKET SET

137A137A137A137A

135A

634

617

51A

217900

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5708−6Assemblies include all parts shown in frames. 03/03/2008

445

1267

967

305

305A

643

968

304 1040

883

823

677

864

676

613

300A

676A

677

1266A

1266

431

1036 EMISSIONS LABEL

883

613B

1040A

883

613A

613

300G

217900

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5708−7Assemblies include all parts shown in frames. 03/03/2008

697

783

1051

363

729A

802

579

1051

310

803

544

801

311

797

513

783

37A

597

456

689

459

1044

309

510

608

1090

455

23A

78A

1005

1005A 415A

1070A

73A

1070

1005B

217900

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5708−8Assemblies include all parts shown in frames. 03/03/2008

527

356B

1054

356

729

851

334

333

240 240A

918

601

187

601

957

972

601

187B

521

356A

356C

601

187A

601

187B

601

187C

958

601A

216

202

232

267

265

209

222

188

616

404

614

562

505

227

621

268

269

271

270

359

507 520

373

1136

688

843

689A

261

687

205

203

216A

385A

387

387A

385

788

385

387A

217900

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5708−9Assemblies include all parts shown in frames. 03/03/2008

877C

10 −16 AMP

474D

878

474B 474C

877B

877

DUAL

CIRCUIT

NOTE: All stators use a No. mounting screw.

1119

NOTE: The proper flywheel part number and/or the alternator magnet size will

determine the alternator type or output. See repair instruction manual

for additional information.

1059 1059

501A

526A

5 −9 AMP

1059

578578

501D

526B

REF. PART REF. PART REF. PART

NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION

217900

KIncluded in Engine Gasket Set−Ref. No. 358.

DIncluded in Carburetor Overhaul Kit−Ref. No. 121 or 121A.

zIncluded in Carburetor Gasket Set−Ref. No. 977 or 977A.

ΔIncluded in Valve Gasket Set−Ref. No. 1095.

Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.

5708−10 Assemblies include all parts shown in frames. 03/03/2008

1 697377 Cylinder Assembly

2 399265 Kit−Bushing/Seal

(Magneto Side)

3K391086S Seal−Oil

(Magneto Side)

4 697106 Sump−Engine

4A 697188 Sump−Engine

Used on Type No(s).

0112, 0118, 0122.

5 792964 Head−Cylinder

7KΔ273280S Gasket−Cylinder Head

9K697109 Gasket−Breather

(Used Before Code

Date 07071900).

(After Date Code Use

Liquid Sealant

Reference 850)

10 697157 Screw

(Breather Assembly)

11 794683 Tube−Breather

(Used After Code Date

07071800).

−−−−−− Note −−−−−−

697113 Tube−Breather

(Used Before Code

Date 07071900).

12 K697110 Gasket−Crankcase

(.015” Thick)

(Standard)

13 690360 Screw

(Cylinder Head)

14 790560 Stud

(Cylinder Head)

15 690946 Plug−Oil Drain

(3/8” Standard)

16 697390 Crankshaft

20 K791892 Seal−Oil

(PTO Side)

22 692125 Screw

(Crankcase

Cover/Sump)

23 698281 Flywheel

Used on Type No(s).

0025, 0028, 0112,

0118, 0128, 0133,

0135.

−−−−−− Note −−−−−−

698282 Flywheel

Used on Type No(s).

0122.

693557 Flywheel

Used on Type No(s).

0019, 0116, 0123.

693556 Flywheel

Used on Type No(s).

0125, 0140, 0141.

23A 693555 Flywheel

Used on Type No(s).

0015, 0020, 0117,

0119, 0124, 0127.

−−−−−− Note −−−−−−

698283 Flywheel

Used on Type No(s).

0016, 0134.

24 222698S Key−Flywheel

25 792305 Piston Assembly

(Standard)

−−−−−− Note −−−−−−

792728 Piston

Assembly

(.020” Oversize)

26 792306 Ring Set

(Standard)

−−−−−− Note −−−−−−

792643 Ring Set

(.020” Oversize)

27 698469 Lock−Piston Pin

(Used After Code Date

02100300).

−−−−−− Note −−−−−−

698138 Lock−Piston

(Used Before Code

Date 02100400).

28 697099 Pin−Piston

29 791633 Rod−Connecting

(Standard)

−−−−−− Note −−−−−−

697262 Rod−

Connecting

(.020” Undersize)

(Used Before Code

Date 05040400).

32 791118 Screw

(Connecting Rod)

33 791934 Valve−Exhaust

(Used After Code Date

06120300).

−−−−−− Note −−−−−−

695760 Valve−Exhaust

(Used Before Code

Date 06120400).

34 791935 Valve−Intake

(Used After Code Date

06120300).

−−−−−− Note −−−−−−

695761 Valve−Exhaust

(Used Before Code

Date 06120400).

35 691279 Spring−Valve

(Intake)

36 691279 Spring−Valve

(Exhaust)

37 697352 Guard−Flywheel

37A 697626 Guard−Flywheel

(Electric Start)

Used on Type No(s).

0015, 0016, 0020,

0117, 0119, 0124,

0127, 0134.

42 499586 Keeper−Valve

43 691968 Slinger−Governor/Oil

45 690564 Tappet−Valve

46 793880 Camshaft

50 697361 Manifold−Intake

50B 795756 Manifold−Intake

Used on Type No(s).

0015G1, 0016G1,

0019G1, 0025G1.

51KΔDz692137 Gasket−Intake

51AKΔDz791312 Gasket−Intake

Otros manuales de Motor de Briggs & Stratton

Briggs & Stratton

Briggs & Stratton Classic 100000 Series Manual de usuario

Briggs & Stratton

Briggs & Stratton Vanguard 290000 Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 44M700 Series Guía de configuración

Briggs & Stratton

Briggs & Stratton 91400 Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 190000 Series Manual de usuario

Briggs & Stratton

Briggs & Stratton 19E400 Instrucciones de instalación

Briggs & Stratton

Briggs & Stratton 402400 Series Manual de usuario

Briggs & Stratton

Briggs & Stratton 250000 Series Manual de usuario

Briggs & Stratton

Briggs & Stratton Vanguard 610000 Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton Vanguard 10V300 Instrucciones de funcionamiento

Briggs & Stratton

Briggs & Stratton Vanguard EFI 380000 Instrucciones de funcionamiento

Briggs & Stratton

Briggs & Stratton 120200 Series Guía de configuración

Briggs & Stratton

Briggs & Stratton P2132E Guía de configuración

Briggs & Stratton

Briggs & Stratton 110600 series Manual de usuario

Briggs & Stratton

Briggs & Stratton 675EXi Series Manual de usuario

Briggs & Stratton

Briggs & Stratton Vanguard 130000 Manual de usuario

Briggs & Stratton

Briggs & Stratton 310000 Intek Manual de usuario

Briggs & Stratton

Briggs & Stratton 20000 Manual de usuario

Briggs & Stratton

Briggs & Stratton 440000 Professional Series Manual de usuario

Briggs & Stratton

Briggs & Stratton Vanguard 540000 Series Manual de usuario

Briggs & Stratton

Briggs & Stratton 441700 Series Guía de configuración

Briggs & Stratton

Briggs & Stratton 91200 Series Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton 12K300 INTEK series Manual de instalación y operación

Briggs & Stratton

Briggs & Stratton Vanguard 540000 Series Manual

Manuales populares de Motor de otras marcas

Rotax

Rotax 125 senior MAX evo Manual de usuario

Kohler

Kohler K361 Manual de usuario

MTD

MTD OHV Series Manual de usuario

Kohler

Kohler COMMAND CH18-745 Manual de usuario

Mercury

Mercury D4.2L D-Tronic Manual de usuario

Selve

Selve SE Plus-RC Series Manual de usuario

Perkins

Perkins 1206E-E66TA Manual de usuario

Skov

Skov DA 174 Manual

Rossi

Rossi TX11 Series Manual de usuario

Siemens

Siemens SIMOTICS T-1FW3 Hoja de instrucciones

AL-KO

AL-KO PRO 350 Manual de usuario

MTU

MTU 12 V 4000 Lx4 Manual de usuario

Nanni

Nanni N3.30 Manual de instrucciones

Nanni

Nanni N5.160 CR2 Manual de usuario

KSB

KSB SuPreme Series Instrucciones de instalación

Hiwin

Hiwin EM1 Series Manual de usuario

Rotax

Rotax 912 i series Instrucciones de funcionamiento

Siemens

Siemens SIMOTICS XP 1MB1 Manual de usuario
