BREIL CHRONO OS10 Manual de usuario

Instruction book pag. 1 •Mode d’emploi pag. 11

Gebrauchsanleitung pag. 21 •Manuale di funzionamento pag. 31

Manual de instrucciones pag. 41

CHRONO

CAL OS10

Thank you very much for purchasing a BREILWATCH.To ensure its correct use,

please read these instructions carefully.

In order to be able to make full use of the guarantee service (subject to the

guarantee terms), please ensure that the Breil international guarantee card is

supplied with the watch at the time of purchase.

Nous vous remercions de la préférence que vous nous avez accordée en achetant

une montre BREIL. En vue d'une utilisation correcte de celle-ci, lire attentivement

les instructions contenues dans ce livret.

Lors de l'achat, contrôlez que la montre soit accompagnée de la garantie qui devra

être présentée pour obtenir les prestations qui y sont décrites.

Wir danken Ihnen für dasVertrauen, daß Sie uns mit dem Kauf einer BREIL

QUARTZ-Uhr erwiesen haben. Damit Sie Ihre Uhr immer einwandfrei gebrauchen

können, möchten wir Sie bitten, die in dieser Gebrauchsanleitung enthaltenen

Anweisungen gewissenhaft zu lesen.

Beim Kauf sollten Sie kontrollieren, ob Ihnen zusammen mit der Uhr auch die

Garantiekarte ausgehändigt wurde, denn diese Karte müssen Sie vorlegen, um die

darin genannten Leistungen in Anspruch nehmen zu können.

Vi ringraziamo per la preferenza accordataci con l’acquisto di un orologio BREIL.

Per un corretto uso dello stesso,Vi preghiamo leggere attentamente le istruzioni

contenute in questo libretto.

Al momento dell’acquisto controllate che insieme all’orologioVi venga fornita

anche la garanzia, da presentare per ottenere le prestazioni in essa descritte.

Le agradecemos su preferencia por un reloj BREIL. Para poder utilizar

correctamente el reloj, le rogamos leer atentamente las instrucciones contenidas

en este folleto.

Al comprarlo, controle que junto al reloj le sea entregada la garantía que debe ser

presentada para obtener los servicios que en la misma se describen.

When reading this instruction booklet, keep the watch diagram on the

left unfolded and in full view.The symbols (A, B, etc.) on the diagram

are those referred to in the section describing the operating instructions.

Pendant la lecture de ce mode d'emploi, gardez le schéma d'illustration

de la montre ci-contre ouvert et bien en vue. Les symboles (A, B, etc.)

utilisés dans les différents chapitres du mode d'emploi correspondent à

ceux indiqués sur ce schéma.

Zur Lektüre dieser Gebrauchsanleitung sollten Sie die nebenstehend

gezeigte Übersichtsdarstellung der Uhr ausklappen und im Blick

behalten. Die in den einzelnen Abschnitten der Gebrauchsanleitung

verwendeten Zeichen (A, B, usw.) entsprechen den Kennzeichnungen

in dieser Übersicht.

Durante la lettura di questo manuale di istruzioni, tenere lo schema

illustrativo dell’orologio a sinistra aperto e in vista. I simboli (A, B, ecc.)

usati nelle sezioni delle istruzioni sul funzionamento corrispondono a

quelli indicati in questo schema.

Mientras lee este manual de instrucciones, mantenga el esquema

ilustrativo del reloj aquí presentado al lado izquierdo, abierto y bien

visible. Los símbolos (A, B, etc.) utilizados en las secciones de

instrucciones sobre el funcionamiento, corresponden a los que se

utilizan en este esquema.

(0) (1) (2)

251

6 3

CONTENTS

MAIN COMPONENTS

SETTINGTHETIME

SETTINGTHE DATE

CHRONOGRAPH OPERATION

ADJUSTINGTHE CHRONOGRAPH

TACHYMETER

TELEMETER

PRECAUTIONS AND USEFUL INFORMATION

TECHNICAL DATA

MAIN COMPONENTS

Hour hand

Minute hand

Continuous second hand

CHR hour hand

CHR minute hand

SETTINGTHETIME

When the small second hand (3) is on “0” seconds, pull out the crown (C) to position

(2) to stop the watch.

Tu rn the crown to adjust the hands to the correct time.

Restart the watch by pushing the crown back to position (0).

SETTINGTHE DATE

Pull out the crown (C) to position (1)

Rotate the crown anticlockwise until the required date appears.

* Do not set the date between 9.00 p.m. and 1.00 a.m. in that it is during this period

that the automatic date change mechanism is active and may be damaged.

Push the crown back to position (0)

CHR second hand

CHR start/stop button

CHR reset button

Crown

Legend: CHR = chronograph

If the hands of the chronograph do not return to the "0" position when the

chronograph is reset:

Pull the crown out to position (2).

Press button to move the second hand of the CHR to the “0” position.

Set the watch to the correct time.

Push the crown back to position “0”.

Press button to reset the CHR minute hand and hour hand to “0”.

CHRONOGRAPH OPERATION

With the crown in its normal position.

The chronograph can measure up to 12 hours in one second intervals.

Press button or as required:

START

START

STOP

RESET

RESTART

A A

RESET

Pressing button repeats the accumulation.

The hour hand and minute hand show the correct time even when the chronograph is in use.

A B

STOP

ADJUSTINGTHE CHRONOGRAPHE

TA CHYMETER*F

TELEMETER*

* Not available on all models

The tachymeter is used to measure the speed of an automobile.

By knowing how many seconds it takes for the vehicle to travel

one kilometre, the tachymeter can measure the approximate

average speed in km/h during a journey (over a maximum

measurable time of 60 seconds).

If the chronograph is started at the same time as the start of the

distance measurement and stopped after one kilometre, the

average speed can be calculated from the position of the second

hand. If the vehicle covers a distance of one kilometre in 45

seconds, then the average approximate speed is 80 km/h.

The telemeter is a distance indicator which allows distance to

be calculated on the basis of the speed of sound. It is useful,

therefore, for aviation, navy, army and artillery purposes. It can

also measure how far away a thunderstorm is.

The hand is started the second a flash, smoke or lightning is

seen and stopped when the actual sound is heard.The

distance, from 1 to 20 kilometres, between the observer and

the explosion or storm is read from the telemetry scale.

The words “WATER RESISTANT” may sometimes be abbreviated to “WATER RESIST”.

WATER RESISTANT

50M (5bar)

WATER RESISTANT

—

A—

—

Indication

Dial Case

Spray, sweat,

light rain,

washing, etc.

Swimming,

etc.

Use in

YES

PRECAUTIONS AND USEFUL INFORMATION

In order to prevent water coming into contact with the internal mechanism, never pull

the crown out when the watch is wet.

If any watches designed for sportswear or use in water come into contact with salt

water or heavy sweating, they should be rinsed in fresh water and dried thoroughly.

Contact with water may cause a deterioration in the quality of some leather straps.

–

CWATER RESISTANT YES YES

DWATER RESISTANT

100M (10bar) WATER RESISTANT YES YES

WATER RESISTANT

200M (20bar) or more

WATER RESISTANT YES YES

Degree of water

resistance
