BREIL Chrono FS00 Manual de usuario
Instruction book pag. 1 • Mode d'emploi pag. 13
Gebrauchsanleitung pag. 25 • Manuale di funzionamento pag. 37
Manual de instrucciones pag. 49
CHRONO
FS00
CAL-FS00_COP 26-09-2003 15:26 Pagina 3
12
93
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
6
22
12
18 6
24
45 15
30
60
45 15
30
60
(1) (2)
CAL-FS00_COP 26-09-2003 15:26 Pagina 1
When reading this instruction booklet, keep the watch diagram on the left
unfolded and in full view. The symbols (A, B, etc.) on the diagram are
those referred to in the section describing the operating instructions.
Pendant la lecture de ce mode d'emploi, gardez le schéma d'illustration
de la montre ci-contre ouvert et bien en vue. Les symboles (A, B, etc.)
utilisés dans les différents chapitres du mode d'emploi correspondent à
ceux indiqués sur ce schéma.
Zur Lektüre dieser Gebrauchsanleitung sollten Sie die nebenstehend
gezeigte Übersichtsdarstellung der Uhr ausklappen und im Blick
behalten. Die in den einzelnen Abschnitten der Gebrauchsanleitung
verwendeten Zeichen (A, B, usw.) entsprechen den Kennzeichnungen in
dieser Übersicht.
Durante la lettura di questo manuale di istruzioni, tenere lo schema
illustrativo dell’orologio a sinistra aperto e in vista. I simboli (A, B, ecc.)
usati nelle sezioni delle istruzioni sul funzionamento corrispondono a
quelli indicati in questo schema.
Mientras lee este manual de instrucciones, mantenga el esquema
ilustrativo del reloj aquí presentado al lado izquierdo, abierto y bien
visible. Los símbolos (A, B, etc.) utilizados en las secciones de
instrucciones sobre el funcionamiento, corresponden a los que se
utilizan en este esquema.
CAL-FS00_COP 26-09-2003 15:26 Pagina 2
Thank you very much for purchasing a BREIL WATCH. To ensure its correct use, please
read these instructions carefully.
In order to be able to make full use of the guarantee service (subject to the guarantee
terms), please ensure that the Breil international guarantee card is supplied with the
watch at the time of purchase.
Nous vous remercions de la préférence que vous nous avez accordée en achetant une
montre BREIL. En vue d'une utilisation correcte de celle-ci, lire attentivement les
instructions contenues dans ce livret.
Lors de l'achat, contrôlez que la montre soit accompagnée de la garantie qui devra être
présentée pour obtenir les prestations qui y sont décrites.
Wir danken Ihnen für das Vertrauen, daß Sie uns mit dem Kauf einer BREIL Uhr
erwiesen haben. Damit Sie Ihre Uhr immer einwandfrei gebrauchen können, möchten wir
Sie bitten, die in dieser Gebrauchsanleitung enthaltenen Anweisungen gewissenhaft zu
lesen.
Beim Kauf sollten Sie kontrollieren, ob Ihnen zusammen mit der Uhr auch die
Garantiekarte ausgehändigt wurde, denn diese Karte müssen Sie vorlegen, um die darin
genannten Leistungen in Anspruch nehmen zu können.
Vi ringraziamo per la preferenza accordataci con l’acquisto di un orologio BREIL.
Per un corretto uso dello stesso, Vi preghiamo leggere attentamente le istruzioni
contenute in questo libretto.
Al momento dell’acquisto controllate che insieme all’orologio Vi venga fornita anche la
garanzia, da presentare per ottenere le prestazioni in essa descritte.
Le agradecemos su preferencia por un reloj BREIL. Para poder utilizar correctamente el
reloj, le rogamos leer atentamente las instrucciones contenidas en este folleto.
Al comprarlo, controle que junto al reloj le sea entregada la garantía que debe ser
presentada para obtener los servicios que en la misma se describen.
CAL-FS00_COP 26-09-2003 15:26 Pagina 4
CONTENTS
MAIN COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
SETTING THE TIME AND DATE . . . . . . . . . . . . . . . . . . . . . . . . . .3
USING THE CHRONOGRAPH . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
CHRONOGRAPH RESET
(INCL. AFTER REPLACING BATTERY) . . . . . . . . . . . . . . . . . . . .5
TACHYMETER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
TELEMETER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
PRECAUTIONS AND USEFUL INFORMATION . . . . . . . . . . . . . . .8
TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
A
B
C
D
E
F
G
H
GB
1043_CAL FS00_GB 26-09-2003 15:27 Pagina 1
2
MAIN COMPONENTS
Hour hand Button
Minute hand Button
Chronograph second hand Crown
Chronograph minute hand
24-hour hand
Continuous second hand
Calendar
A
1043_CAL FS00_GB 26-09-2003 15:27 Pagina 2
SETTING THE TIME AND DATE
To set the time:
1. Pull the crown out to the 2nd position so that the second hand stops at “0” position.
2. Turn the crown to set the hour and minute hands.
3. After the date has been set, push the crown back to the normal position.
To set the date:
1. Pull the crown out to the 1st position (1).
2. Turn the crown by clockwise to set the date.
* If the date is set between the hours of around 9:00 PM and 1:00 AM, the date may
not change on the following day.
3. After the date has been set, push the crown back to the normal position.
B
3
1043_CAL FS00_GB 26-09-2003 15:27 Pagina 3
USING THE CHRONOGRAPH
• This chronograph is able to measure and display time in 1/1 second united up to
maxinum of 1 hour.
Measuring time with the chronograph
1. The chronograph can be started and stopped each time button is pressed.
2. To reset, press button and the chronograph second and minute hands return to
their “0” positions.
4
C
RESET TIME MEASUREMENT STOP
1043_CAL FS00_GB 26-09-2003 15:27 Pagina 4
5
DCHRONOGRAPH RESET
(INCL. AFTER REPLACING BATTERY)
This procedure shoud be performed when the chronograph second hand do not return
to the 0 second position after the chronograph has been reset, and including after the
battery has been replaced.
1. Pull the crown out to the 2nd position (2).
2. Press button to set the chronograph second hand to the “0” position.
3. The chronograph hands can be advanced rapidly by continuously pressing
button .
4. Once the hands have been zeroed, reset the time and return the crown to its normal
position.
* Do not return crown to normal position while chronograph second hand returns to
12:00 (“0” position).
Hand stops on the way when crown are returned to normal position and these
positions are recognized as 12:00 (“0” position).
1043_CAL FS00_GB 26-09-2003 15:27 Pagina 5
6
ETACHYMETER*
The Tachymeter is the device which measures the speed of an automobile. Knowing is
how many seconds the car covers a distance of 1km, the meter can measure the
approximate average speed per hour during a journey (up to the maxinum measurable
range of tachymeter is 60 seconds).
If the chronograph is started at the same time as measurement, and stopped after 1km,
the average speed per hour can be determined according to the position of the second
hand. If the car covers the distance of 1km in 45 seconds, the average hourly speed
during the journey will be about 80 km.
* Not available on all models.
