BRAVILOR BONAMAT Matic Manual de usuario

ECopyright Bravilor Bonamat B.V.

MATIC / THA

The programming of the Matic is divided in two

levels:

1. Quantity of water (included in the user

instructions)

2. Other options

WARNING

nThe lower hot plate will become hot during

programming.

Level 1

P1 Quantity of water adjustment

Level 2

P2 Maximum number of cups

P3 Default on display

P4 Masking quantities

P5 Drip time

P6 Display options during brewcycle

P7 Total amount

Access level 1

P1 Adjusting the quantity of water (per cup)

You can adjust the quantity of hot water used to

brew the coffee. This is set to a standard amount

when the machine leaves the factory. If you think the

factory setting is supplying too much or too little wa-

ter, you can change the amount as follows:

1. Press the and the 1/0keys at the same time

and keep them pressed in until P1 appears in

the display (after about 10 seconds).

2. Release the keys. The display will now show the

setting for the current quantity of water. This

quantity varies from machine to machine, see

table 1 .

3. Press the key for more water or the 1/0key for

less.

4. The settings available range from 0, 2, 4, 6... to

98. Two steps higher will give you 3 to 5 ml.

extra water in the decanter, see table 1 .

5. Wait for about 20 seconds.

During programming

+

1/0

 1/0both Next option

Keys Display Remark

1/0Press both keys

P1 Release keys

/

Adjust



Adj

Wait 20 sec.

12 Ready to brew

The machine is now ready for use again.

ÓÓ

ECopyright Bravilor Bonamat B.V.

Stand

Position

Matic 2/3 WB Twin (3N) THa10 THa20 Matic Twin (1N)

Per cup Per decanter

(12)

Per cup Per decanter

(16)

Per cup Per decanter

(16)

Per cup Per decanter

(12)

096 cc 1.15 L 96 cc 1.53 L 98 cc 1.57 L 96 cc 1.15 L

4100 cc 1.20 L 100 cc 1.60 L 102 cc 1.64 L 99 cc 1.19 L

8105 cc 1.26 L 105 cc 1.67 L 107 cc 1.71 L 102 cc 1.23 L

12 109 cc 1.31 L 109 cc 1.74 L 112 cc 1.79 L 105 cc 1.26 L

16 113 cc 1.36 L 113 cc 1.82 L 116 cc 1.86 L 108 cc 1.30 L

20 118 cc 1.42 L 118 cc 1.89 L 121 cc 1.93 L 111 cc 1.34 L

24 122 cc 1.47 L 122 cc 1.96 L 125 cc 2.01 L 114 cc 1.37 L

28 127 cc 1.52 L 127 cc 2.03 L 130 cc 2.08 L 118 cc 1.41 L

32 131 cc 1.57 L 131 cc 2.09 L 135 cc 2.16 L 120 cc 1.44 L

36 134 cc 1.61 L 134 cc 2.15 L 140 cc 2.24 L 123 cc 1.48 L

40 138 cc 1.66 L 138 cc 2.21 L 145 cc 2.31 L 126 cc 1.51 L

44 142 cc 1.70 L 142 cc 2.27 L 149 cc 2.39 L 129 cc 1.55 L

48 146 cc 1.75 L 146 cc 2.33 L 154 cc 2.47 L 132 cc 1.58 L

52 149 cc 1.79 L 149 cc 2.39 L 159 cc 2.55 L 134 cc 1.61 L

56 153 cc 1.84 L 153 cc 2.45 L 164 cc 2.62 L 137 cc 1.65 L

60 157 cc 1.88 L 157 cc 2.51 L 196 cc 2.70 L 140 cc 1.68 L

64 161 cc 1.93 L 161 cc 2.58 L 173 cc 2.77 L 143 cc 1.72 L

68 165 cc 1.98 L 165 cc 2.65 L 178 cc 2.84 L 147 cc 1.76 L

72 169 cc 2.03 L 169 cc 2.71 L 182 cc 2.92 L 150 cc 1.80 L

76 174 cc 2.08 L 174 cc 2.78 L 187 cc 2.99 L 153 cc 1.84 L

80 178 cc 2.13 L 178 cc 2.84 L 191 cc 3.06 L 157 cc 1.88 L

84 182 cc 2.18 L 182 cc 2.91 L 196 cc 3.13 L 160 cc 1.92 L

88 186 cc 2.23 L 186 cc 2.98 L 200 cc 3.21 L 163 cc 1.96 L

94 192 cc 2.31 L 192 cc 3.08 L 207 cc 3.31 L 168 cc 2.02 L

98 197 cc 2.36 L 197 cc 3.14 L 212 cc 3.39 L 172 cc 2.06 L

Table 1 Adjust the quantity of water

Access level 2

Go to level 1 (press both keys and 1/0keys at the

same time for about 10 seconds) and after that

press both keys and 1/0keys again about 10

second until P2 appears in the display.

P2 Maximum number of cups

The maximum number of cups the machine brews

can be adjusted here, Matic 12 and THa 16.

When smaller or larger cups are used, another

quantity can be selected. Adjust with the and 1/0

keys, minimum 2 and maximum 30. Don’t forget to

readjust P1 (water quantity per cup).

Keys Display Remark

1/0Press both keys 10 sec

P1 Release keys

1/0Press both keys 10 sec

P2 Release keys

/

Adjust



Adj

ECopyright Bravilor Bonamat B.V.

P3 Number of cups default on display

The Matic has default 12 cups on the display (THa

16). With the keys and 1/0, you can select the

number of cups which will be shown as default on

the display.

Keys Display Remark

1/0Press both keys

P3 Release keys

/

Adjust



Adj

P4 Masking Quantities

It is possible to mask certain quantities so that they

can not be selected.

All quantities from 2 can be selected as follows:

Dmask =  key

Dshow = 1/0key

The quantities will be showed one by one on the

display.

Keys Display Remark

1/0Press both keys

P4 Release keys

/

Adjust



Adj

P5 Drip time

When the brewing of the hot water in the filter has

stopped, the filter needs time to empty. This time

can be adjusted.

Longer or shorter 2 = 20 sec., 5 = 50 sec. etc.

(range 1 –20).

Keys Display Remark

1/0Press both keys

P5 Release keys

/

Adjust



Adj

P6 Display options during brew

You can select here what is displayed during the

brewcycle

1. chosen number during whole brew cycle

2. count down, alternated with the chosen number

3. count up, alternated with the chosen number

Keys Display Remark

1/0Press both keys

P6 Release keys

/

Adjust



Adj

P7 Total amount brewed

Shows the total amount the machine has brewed in

its lifetime.

8 cups = 1 liter

Keys Display Remark

1/0Press both keys

P7 Release keys

32421 Total liters

The machine is now ready for use again
