Thank you for purchasing a Braun product.

We hope you are completely satisfied with

your new Braun shaver.

If you have any questions, please call:

US residents 1-800-BRAUN-11

1-800-272-8611

Canadian residents 1-800-387-6657

Merci d’avoir fait l’achat d’un produit Braun.

Nous espérons que vous serez pleinement

satisfait de votre nouveau rasoir Braun.

Si vous avez des questions, veuillez appeler

Braun Canada : 1-800-387-6657

Gracias por haber comprado un producto

Braun.

Esperamos que quede completamente

satisfecho con su nueva afeitadora Braun.

Si tiene alguna duda, por favor llame al:

01(800) 508-5800

English 4

Français 15

Español 25

98574367/XI-07

USA/CDN/MEX

Printed in Germany

Imprimé en Allemagne

Impreso en Alemania

9857467_790cc_NA_S2.indd 19857467_790cc_NA_S2.indd 1 21.11.2007 15:29:58 Uhr21.11.2007 15:29:58 Uhr

washable

reset

trimmer

reset

trimmer

off

high

clean

eco

normal

intensive

auto select

low

empty

9857467_790cc_NA_S3.indd 19857467_790cc_NA_S3.indd 1 21.11.2007 15:30:39 Uhr21.11.2007 15:30:39 Uhr

English

IMPORTANT SAFETY

INSTRUCTIONS

When using an electrical appliance, basic precautions should

always be followed, including the following:

Read all instructions before using this appliance.

When disconnected, the hand-held part of this shaving

appliance may be cleaned under water.

DANGER

To reduce the risk of electric shock:

1. Use only in dry condition.

2. Do not submerge in water.

3. Do not reach for an appliance that has fallen into water. Unplug

immediately.

4. Do not use while bathing or in a shower.

5. Do not place, store or charge the appliance where it can fall or

be pulled into a tub or sink. Do not place in or drop into water or

other liquid.

6. Except when charging, always unplug this appliance from the

electrical outlet immediately after using.

7. Unplug this appliance before cleaning.

8. This appliance is provided with a special cord set with

integrated Safety Extra Low Voltage power supply. Do not

exchange or manipulate any part of it.

9. Do not use an extension cord with this appliance.

FOR HOUSEHOLD USE ONLY

9857467_790cc_NA_S4-38.indd 49857467_790cc_NA_S4-38.indd 4 21.11.2007 15:25:04 Uhr21.11.2007 15:25:04 Uhr

WARNING

To reduce the risk of burns, fire, electric shock, or injury to

persons:

1. Close supervision is necessary when this appliance is used by,

on, or near children or invalids.

2. Use this appliance only for its intended use as described in this

manual.

Do not use attachments not recommended by the manufacturer.

3. Never operate this appliance if it has a damaged cord or plug, if

it is not working properly, if it has been dropped or damaged, or

if the power supply has been dropped into water. Return the

appliance to a service center for examination and repair.

4. Keep the cord away from heated surfaces.

5. Never drop or insert any object into any opening.

6. Do not use outdoors or operate where aerosol (spray) products

are being used or where oxygen is being administered.

7. Do not use this appliance with a damaged or broken foil, as

serious skin injuries may occur.

8. Always attach plug to appliance first, then to outlet.

To disconnect, turn all controls to «off», then remove plug from

outlet.

9. When plugging to an electrical outlet outside the USA, use a

plug adapter to match the outlet’s pin configuration.

SAVE THESE INSTRUCTIONS

9857467_790cc_NA_S4-38.indd 59857467_790cc_NA_S4-38.indd 5 21.11.2007 15:25:06 Uhr21.11.2007 15:25:06 Uhr

Warning

To prevent the cleaning ﬂuid from leaking, ensure

that the Clean&Renew station is placed on a ﬂat

surface. When a cleaning cartridge is installed,

do not tip, move suddenly or transport the

station in any way as cleaning ﬂuid might spill

out of the cartridge. Do not place the station

inside a mirror cabinet, nor place it on a polished

or lacquered surface.

The cleaning cartridge contains a highly

ﬂammable liquid so keep it away from sources

of ignition. Do not expose to direct sunlight and

cigarette smoking nor store it over a radiator.

Keep it out of reach of children.

Do not reﬁll the cartridge and use only original

Braun reﬁll cartridges.

Description

Clean&Renew station

1Cleaning ﬂuid display

2Lift button for cartridge exchange

3Station-to-shaver contacts

4«start cleaning» button

D«fast clean» button

5Cleaning program diodes

6Station power socket

7Cleaning cartridge

Shaver

8Foil & cutter cassette

9Cassette release button

0Shaver head «lock» switch

qPop-out long hair trimmer

wOn/off switch

e«reset» button

rShaver display

tShaver-to-station contacts

zShaver power socket

uTravel case

iSpecial cord set

9857467_790cc_NA_S4-38.indd 69857467_790cc_NA_S4-38.indd 6 21.11.2007 15:25:06 Uhr21.11.2007 15:25:06 Uhr

Before shaving

Prior to ﬁrst use you must connect the shaver to

an electrical outlet using the special cord set i

or alternatively proceed as below.

Installing the Clean&Renew station

• Using the special cord set i, connect the

station power socket 6to an electrical outlet.

• Press the lift button 2to open the housing.

• Hold the cleaning cartridge 7down on a ﬂat,

stable surface (e.g. table).

• Carefully remove the lid from the cartridge.

• Slide the cartridge into the base of the station

as far as it will go.

• Slowly close the housing by pushing it down

until it locks.

The cleaning ﬂuid display 1will show how much

ﬂuid is in the cartridge:

«high» up to 30 cleaning cycles available

«low» up to 7 cleaning cycles remaining

«empty» new cartridge required

Charging and cleaning the shaver

Insert the shaver head down into the cleaning

station. (The contacts ton the back of the

shaver will align with the contacts 3in the

cleaning station).

If required, the Clean&Renew station will now

charge the shaver. The hygiene status of the

shaver will also be analyzed and one of the

following cleaning program diodes 5will light

up:

«clean» shaver is clean

«eco» short economical cleaning required

«normal» normal level of cleaning required

«intensive» high intensive cleaning required

If the station selects one of the required cleaning

programs, it will not start unless you press the

«start cleaning» button 4.For best shaving

results, we recommend cleaning after each

shave.

new

high

clean

eco

normal

intensive

auto select

low

empty

cle

eco

nor

mal

ive

sel

high

clean

eco

normal

intensive

auto select

low

empty

high

clean

eco

normal

intensive

auto select

low

empty

new

high

clean

eco

normal

intensive

auto select

low

empty

cle

eco

nor

mal

ive

sel

high

clean

eco

normal

intensive

auto select

low

empty

high

clean

eco

normal

intensive

auto select

low

empty

high

low

empty

high

low

empty

high

low

empty

high

low

empty

high

low

empty

high

low

empty

high

clean

eco

normal

intensive

auto select

low

empty

washable

trimmer

reset

high

clean

eco

normal

intensive

auto select

low

empty

washable

trimmer

reset

auto select

intensive

normal

eco

clean

auto select

intensive

normal

eco

clean

high

clean

eco

normal

intensive

auto select

low

washable

high

clean

eco

normal

intensive

auto select

low

washable

9857467_790cc_NA_S4-38.indd 79857467_790cc_NA_S4-38.indd 7 21.11.2007 15:25:06 Uhr21.11.2007 15:25:06 Uhr

While cleaning is in progress, the respective

cleaning program diode will blink. Each cleaning

program consists of several cycles, where

cleaning ﬂuid is ﬂushed through the shaver head

and a heat drying process dries the shaver.

Depending on the program selected the total

cleaning time will range from 32 to 43 minutes.

The cleaning programs should not be

interrupted. Please note that while the shaver is

drying, the shaving head may be hot and wet.

When the program is ﬁnished, the blue «clean»

diode will light up. Your shaver is now clean and

ready for use.

Fast cleaning

Push the «fast clean» button Dto activate

the fast clean program without drying. This

program takes about 25 seconds only and is

recommended when you do not have time to

wait for one of the automatic cleaning programs.

If you remove the shaver just after the program

has ﬁnished, wipe off the shaver head with a

tissue to avoid dripping.

Stand-by mode

10 minutes after completing the charging or

cleaning session, the Clean&Renew station

switches to the stand-by mode: The diodes of

the Clean&Renew station turns off.

Shaver display

The shaver display rshows the charge status of

the battery on the left, and the hygiene status on

the right. (6 dark segments are shown on each

side when the battery is fully charged and the

shaver is hygienically clean).

Battery segments:

During charging or when using the shaver, the

respective battery segments will blink. When

fully charged all 6 segments are shown. With

decreasing charge the segments gradually

disappear.

Low charge indicator:

The low charge segment provided with a red

frame blinks to indicate that the charge has

dropped below 20%. The remaining capacity is

sufﬁcient for 2 to 3 shaves.

auto select

intensive

normal

eco

clean

auto select

intensive

normal

eco

clean

high

clean

eco

normal

intensive

auto select

low

empty

washable

high

clean

eco

normal

intensive

auto select

low

empty

washable

9857467_790cc_NA_S4-38.indd 89857467_790cc_NA_S4-38.indd 8 21.11.2007 15:25:08 Uhr21.11.2007 15:25:08 Uhr

Hygiene segments:

All 6 hygiene segments will appear after the

shaver has been cleaned in the Clean&Renew

station. When the shaver is being used, the

hygiene segments will gradually disappear.

Once the shaver is returned to the station, the

system will automatically select the appropriate

cleaning program and restore the segments

to maximum hygiene. Given that rinsing the

shaver under tap water is not as hygienic as the

cleaning station, the hygiene segments will only

restore themselves when the shaver has been

cleaned in the Clean&Renew station.

Charging information

• A full charge provides up to 50 minutes

of cordless shaving time. This may vary

according to your beard growth.

• The best environmental temperature for

charging is between 41 °F to 95 °F / 5 °C to

35 °C. Do not expose the shaver to

temperatures higher than 122 °F / 50 °C for

extended periods of time.

Shaving

Press the on/off switch wto operate the shaver:

• The pivoting shaver head and ﬂoating foils

automatically adjust to every contour of your

face.

• To shave hard to reach areas (e.g. under the

nose) slide the shaver head «lock» switch 0to

the back position to lock the pivoting head at

an angle.

• To trim sideburns, moustache or beard, slide

the pop-out long hair trimmer qupwards.

Tips for the perfect shave

For best shaving results, Braun recommends you

follow 3 simple steps:

1. Always shave before washing your face.

2. At all times, hold the shaver at right angles

(90°) to your skin.

3. Stretch your skin and shave against the

direction of your beard growth.

reset

lock

trimmer

lock

off

reset

lock

trimmer

lock

off

release

9857467_790cc_NA_S4-38.indd 99857467_790cc_NA_S4-38.indd 9 21.11.2007 15:25:09 Uhr21.11.2007 15:25:09 Uhr

Shaving with the cord

If the shaver has run out of power (discharged),

and you do not have the time to recharge it in the

Clean&Renew station, you may also shave with

the shaver connected to an electrical outlet via

the special cord set i.

Cleaning

Automatic cleaning

After each shave, return the shaver to the

Clean&Renew station and proceed as described

above in the section «Before shaving».

All charging and cleaning needs are then

automatically taken care of. With daily use, a

cleaning cartridge should be sufﬁcient for about

30 cleaning cycles.

The hygienic cleaning cartridge contains alcohol,

which once opened will naturally evaporate

slowly into the surrounding air. Each cartridge,

if not used daily, should be replaced after

approximately 8 weeks.

The cleaning cartridge also contains lubricates,

which may leave residual marks on the outer foil

frame after cleaning. However, these marks can

be removed easily by wiping gently with a cloth

or soft tissue paper.

Manual cleaning

The hand-held unit shall be detached from the

power supply cord before cleaning. The shaver

shall not be used until it has dried.

Rinsing the shaving head under running water

is an alternative way to keep the shaver clean,

especially when travelling:

• Switch the shaver on (cordless) wand rinse

the shaving head under hot running water.

You may use liquid soap without abrasive

substances. Rinse off all foam and let the

shaver run for a few more seconds.

• Next, switch off the shaver, press the release

button 9to remove the foil and cutter cassette

8and let it dry.

• If you regularly clean the shaver under

water, then once a week apply a drop of

light machine oil on top of the foil and cutter

cassette.

high

clean

eco

normal

intensive

auto select

low

empty

washable

trimmer

reset

high

clean

eco

normal

intensive

auto select

low

empty

washable

trimmer

reset

oil

washable

trimmer

washable

trimmer

click!

oil

washable

trimmer

washable

trimmer

click!

9857467_790cc_NA_S4-38.indd 109857467_790cc_NA_S4-38.indd 10 21.11.2007 15:25:10 Uhr21.11.2007 15:25:10 Uhr

Otros manuales para 790 cc

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Rasuradora eléctrica de Braun

Braun

Braun MobileShave M-90 Manual de usuario

Braun

Braun Series 7 790 cc Manual de usuario

Braun

Braun 360 complete Manual de usuario

Braun

Braun 5723 Manual de usuario

Braun

Braun CruZer2 2776 Manual de usuario

Braun

Braun Flex Integral 5312 Manual de usuario

Braun

Braun Syncro 7526 Manual de usuario

Braun

Braun Flex Integral 6525 Guía rápida

Braun

Braun SyncroPro 5492 Manual de usuario

Braun

Braun CruZer FACE Manual de usuario

Braun

Braun SERIES 3 320S-4 Manual de usuario

Braun

Braun CRUZER3 5733 Manual de usuario

Braun

Braun 4815 Manual de usuario

Braun

Braun 3050cc Manual de usuario

Braun

Braun Silk & Soft LS 5100 Manual de usuario

Braun

Braun 7720s Manual de usuario

Braun

Braun Contour Pro Special Edition Series Manual de usuario

Braun

Braun 360S-4 Manual de usuario

Braun

Braun SmartControl 150s-1 Manual de usuario

Braun

Braun SILK-??PI X'ELLE 5380 Manual de usuario

Braun

Braun Silk-epil 5-541 Manual de usuario

Braun

Braun TriControl 4736 Manual de usuario

Braun

Braun CT6cc Manual de usuario

Braun

Braun SERIES 3 330S-4 Manual de usuario

Manuales populares de Rasuradora eléctrica de otras marcas

Philips

Philips MicroAction 4402LC Manual de usuario

Philips

Philips HQ7740 Manual de usuario

Philips

Philips Norelco BG2022 Bodygroom Manual de usuario

Norelco

Norelco Quadra 7610X Manual de usuario

Philips

Philips 7616X Manual de usuario

Philips

Philips HQ802 Manual de usuario

Philips

Philips HQ7363/17 Manual de usuario

Philips

Philips NORELCO S7371 Manual de usuario

Daga

Daga MT-400 Manual

Philips

Philips RQ119x Manual de usuario

Remington

Remington BHT100 Manual de usuario

Philips

Philips Bodygroom BG2000 Manual de usuario

Kompernass

Kompernass KH 5537 Manual de usuario

Remington

Remington BHT6100 Manual de usuario

Philips

Philips qc5365 Manual de usuario

MIA

MIA Aqua Body Manual de usuario

Philips

Philips NORELCO AT880 Manual de usuario

Matheo

Matheo MLR 15 Manual de usuario
