Our products are designed to meet the highest

standards of quality, functionality and design.

We hope you enjoy your new Braun Shaver.

Warning

Your shaving system is provided with a special

cord set, which has an integrated Safety Extra

Low Voltage power supply. Do not exchange or

tamper with any part of it, otherwise there is risk

of an electric shock.

This appliance is not intended for use by children

or persons with reduced physical, sensory or

mental capabilities, unless they are supervised

by a person responsible for their safety. In

general, we recommend that you keep the

appliance out of reach of children. Children

should be supervised to ensure that they do not

play with the appliance.

To prevent the cleaning uid from leaking, ensure

that the Clean&Renew station is placed on a at

surface. When a cleaning cartridge is installed,

do not tip, move suddenly or transport the

station in any way as cleaning uid might spill

out of the cartridge. Do not place the station

inside a mirror cabinet, nor over a radiator, nor

place it on a polished or lacquered surface.

The cleaning cartridge contains a highly

ammable liquid so keep it away from sources of

ignition. Do not smoke near the station. Do not

expose to direct sunlight for long periods of time.

Do not rell the cartridge and use only original

Braun rell cartridges.

Description

Clean&Renew station

1 Cleaning uid display

2Lift button for cartridge exchange

3Station-to-shaver contacts

4Start button

DFast clean button

5Cleaning program indicators

6Station power socket

7Cleaning cartridge

Shaver

8Foil & Cutter cassette

9Cassette «release» button

0Shaver head «lock» switch

qPop-out long hair trimmer

STOP

English

92275905_790cc-4_RU-UA_S4-34.indd 4 01.06.12 11:05

wOn/off switch

e(–) setting button (sensitive)

r(+) setting button (intensive)

tReset button

zShaver display

uShaver-to-station contacts

iShaver power socket

oTravel case

pSpecial cord set

Before shaving

Prior to rst use you must connect the shaver to

an electrical outlet using the special cord set p

or alternatively proceed as below.

Installing the Clean&Renew station

•Using the special cord set p, connect the

station power socket 6to an electrical outlet.

•Press the lift button 2to open the housing.

•Hold the cleaning cartridge 7 down on a at,

stable surface (e.g. table).

•Carefully remove the lid from the cartridge.

•Slide the cartridge into the base of the station

as far as it will go.

•Slowly close the housing by pushing it down

until it locks.

The cleaning uid display 1will show how much

uid is in the cartridge:

up to 30 cleaning cycles available

up to 7 cleaning cycles remaining

new cartridge required

Charging and cleaning the shaver

Insert the shaver head down into the cleaning

station. (The contacts uon the back of the

shaver will align with the contacts 3in the

cleaning station).

If required, the Clean&Renew station will auto-

matically charge the shaver. The hygiene status

of the shaver will also be analyzed and one of

the following cleaning program indicators 5will

light up:

new

trimmer

Series 7

92275905_790cc-4_RU-UA_S4-34.indd 5 01.06.12 11:05

« » shaver is clean

« » short economical cleaning required

« » normal level of cleaning required

« » high intensive cleaning required

If the station selects one of the required cleaning

programs, it will not start unless you press the

start button 4.For best shaving results, we

recommend cleaning after each shave.

Whilst cleaning is in progress, the respective

cleaning program indicator will blink. Each

cleaning program consists of several cycles,

where cleaning uid is ushed through the

shaver head and a heat drying process dries

the shaver. Depending on the program selected

the total cleaning time will range from 32 to 43

minutes.

The cleaning programs should not be inter-

rupted. Please note that whilst the shaver is

drying, the shaving head may be hot and wet.

When the program is nished, the blue « »

indicator will light up. Your shaver is now clean

and ready for use.

Fast cleaning

Push the fast clean button Dto activate

the fast clean program without drying. This

program takes about 25 seconds only and is

recommended when you do not have time to

wait for one of the automatic cleaning programs.

If you remove the shaver just after the program

has nished, wipe off the shaver head with a

tissue to avoid dripping.

Stand-by mode

10 minutes after completing the charging or

cleaning session, the Clean&Renew station

switches to the stand-by mode: The indicators

of the Clean&Renew station turn off.

Shaver display

The shaver display zshows the charge status of

the battery on the left, and the hygiene status on

the right. (6 dark segments are shown on each

side when the battery is fully charged and the

shaver is hygienically clean).

92275905_790cc-4_RU-UA_S4-34.indd 6 01.06.12 11:06

Battery segments:

During charging or when using the shaver, the

respective battery segments will blink. When

fully charged all 6 segments are shown. With

decreasing charge the segments gradually

disappear.

Low charge indicator:

The low charge indicator provided with a red

frame blinks to indicate that the charge has

dropped below 20%. The remaining battery

capacity is sufcient for 2 to 3 shaves.

Hygiene segments:

All 6 hygiene segments will appear after the

shaver has been cleaned in the Clean&Renew

station. When the shaver is being used, the

hygiene segments will gradually disappear.

Once the shaver is returned to the station, the

system will automatically select the appropriate

cleaning program and restore the segments

to maximum hygiene. Given that rinsing the

shaver under tap water is not as hygienic as the

cleaning station, the hygiene segments will only

restore themselves when the shaver has been

cleaned in the Clean&Renew station.

Charging information

•A full charge provides up to 50 minutes

of cordless shaving time. This may vary

according to your beard growth.

•The best environmental temperature for

charging is between 5 °C to 35 °C. Do not

expose the shaver to temperatures higher than

50 °C for extended periods of time.

Personalizing your shaver

With the (–) eand (+) rbuttons you can choose

the best setting for shaving different areas of

your face and as per your specic needs.

The different settings are indicated by the pilot

light incorporated in the on/off switch w:

•dark blue (powerful shave)

•light blue (normal)

•white (for a thorough comfortable shave in

sensitive areas of your face such as neck)

normal

92275905_790cc-4_RU-UA_S4-34.indd 7 01.06.12 11:06

For a thorough and fast shave we recommend

the (+) setting.

When switching on next time, the last used

setting will be activated.

How to use

Press the on/off switch w to operate the shaver:

•The pivoting shaver head and oating foils

automatically adjust to every contour of your

face.

•To shave hard to reach areas (e.g. under the

nose) slide the shaver head «lock» switch 0to

the back position to lock the pivoting head at

an angle.

• To trim sideburns, moustache or beard, slide

the pop-out long hair trimmer upwards.

Tips for the perfect shave

For best shaving results, Braun recommends you

follow 3 simple steps:

1. Always shave before washing your face.

2. At all times, hold the shaver at right angles

(90°) to your skin.

3. Stretch your skin and shave against the

direction of your beard growth.

Shaving with the cord

If the shaver has run out of power (discharged),

and you do not have the time to recharge it in the

Clean&Renew station, you may also shave with

the shaver connected to an electrical outlet via

the special cord set.

Cleaning

Automatic cleaning

After each shave, return the shaver to the

Clean&Renew station and proceed as described

above in the section «Before shaving».

All charging and cleaning needs are then

automatically taken care of. With daily use, a

cleaning cartridge should be sufcient for about

30 cleaning cycles.

The hygienic cleaning cartridge contains

izopropanol, which once opened will naturally

evaporate slowly into the surrounding air. Each

cartridge, if not used daily, should be replaced

after approximately 8 weeks.

lock

trimmer

lock

release

trimmer

92275905_790cc-4_RU-UA_S4-34.indd 8 01.06.12 11:06

The cleaning cartridge also contains lubricants,

which may leave residual marks on the outer foil

frame after cleaning. However, these marks can

be removed easily by wiping gently with a cloth

or soft tissue paper.

Manual cleaning

The shaver head is suitable for cleaning

under running tap water.

Warning: Detach the shaver from the

power supply before cleaning the shaver

head in water.

Rinsing the shaving head under running water

is an alternative way to keep the shaver clean,

especially when travelling:

•Switch the shaver on (cordless) and rinse

the shaving head under hot running water.

You may use liquid soap without abrasive

substances. Rinse off all foam and let the

shaver run for a few more seconds.

•Next, switch off the shaver, press the «release»

button 9to remove the Foil & Cutter cassette

8and let it dry.

•If you regularly clean the shaver under

water, then once a week apply a drop of

light machine oil on top of the Foil & Cutter

cassette.

Alternatively, you may clean the shaver using the

brush provided:

•Switch off the shaver. Remove the Foil & Cutter

cassette 8 and tap it out on a at surface.

Using the brush, clean the inner area of the

pivoting head. However, do not clean the

cassette with the brush as this may damage it.

Cleaning the housing

From time to time clean the housing of the

shaver and the Clean&Renew station with a

damp cloth, especially inside the cleaning

chamber where the shaver rests.

Replacing the cleaning cartridge

After having pressed the lift button 2to open the

housing, wait for a few seconds before removing

the used cartridge to avoid any dripping.

Before discarding the used cartridge, make sure

to close the openings using the lid of the new

cartridge, since the used cartridge will contain

contaminated cleaning solution.

oil

trimmer

click! Series 7

Series 7

Series

Series 7

new old

92275905_790cc-4_RU-UA_S4-34.indd 9 01.06.12 11:06

Keeping your shaver in top shape

Replacing the Foil & Cutter cassette

reset

To maintain 100% shaving performance, re-

place the Foil & Cutter cassette 8, when the

replacement symbol lights up on the shaver

display z(after about 18 months) or when

cassette is worn.

The replacement symbol will remind you during

the next 7 shaves to replace the Foil & Cutter

cassette. Then the shaver will automatically reset

the display.

After you have replaced the Foil & Cutter

cassette, use a ball-pen to push the reset button

tfor at least 3 seconds to reset the counter.

While doing so, the replacement light blinks and

goes off when the reset is complete. The manual

reset can be done at any time.

Accessories

Available at your dealer or Braun Service

Centres:

•Foil & Cutter cassette 70S

•Cleaning cartridge Clean&Renew CCR

Environmental notice

This product contains rechargeable

batteries. In the interest of protecting the

environment, please do not dispose of the

product in household waste at the end of

its useful life. Disposal can take place at a

Braun Service Centre or at appropriate

collection points provided in your country.

The cleaning cartridge can be disposed with

regular household waste.

Subject to change without notice.

For electric specications, see printing on the

special cord set.

70S

Series 7

70S

92275905_790cc-4_RU-UA_S4-34.indd 10 01.06.12 11:06

Otros manuales para shaver

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Rasuradora eléctrica de Braun

Braun

Braun Exact Power battery EP 15 Manual de usuario

Braun

Braun cruZer 6 clean shave Manual de usuario

Braun

Braun InterFace 3615 Manual de usuario

Braun

Braun Flex Integral+ 5410 Manual de usuario

Braun

Braun Silk-epil LS 5360 Manual de usuario

Braun

Braun Contour Series 5875 Manual de usuario

Braun

Braun Series1 170 Manual de usuario

Braun

Braun BT7040 Manual de usuario

Braun

Braun CruZer FACE Manual de usuario

Braun

Braun 5434 Manual de usuario

Braun

Braun 7 series Manual de usuario

Braun

Braun 60-B7200CC Manual de usuario

Braun

Braun BT 32 Manual de usuario

Braun

Braun 5692 limited design edition Manual de usuario

Braun

Braun BG5030 Manual de usuario

Braun

Braun 4840 Manual de usuario

Braun

Braun Prosonic 9595 Manual de usuario

Braun

Braun 7 series Manual de usuario

Braun

Braun Gillette Prosonic 720 Manual de usuario

Braun

Braun 8 Pro Series Manual de usuario

Braun

Braun 7 Seres Manual de usuario

Braun

Braun BS 8795 Manual de usuario

Braun

Braun 9 SERIES Manual de usuario

Braun

Braun 320 Manual de usuario

Manuales populares de Rasuradora eléctrica de otras marcas

Philips

Philips MicroAction 4402LC Manual de usuario

Philips

Philips HQ7740 Manual de usuario

Philips

Philips Norelco BG2022 Bodygroom Manual de usuario

Norelco

Norelco Quadra 7610X Manual de usuario

Philips

Philips 7616X Manual de usuario

Philips

Philips HQ802 Manual de usuario

Philips

Philips HQ7363/17 Manual de usuario

Philips

Philips NORELCO S7371 Manual de usuario

Daga

Daga MT-400 Manual

Philips

Philips RQ119x Manual de usuario

Remington

Remington BHT100 Manual de usuario

Philips

Philips Bodygroom BG2000 Manual de usuario

Kompernass

Kompernass KH 5537 Manual de usuario

Remington

Remington BHT6100 Manual de usuario

Philips

Philips qc5365 Manual de usuario

MIA

MIA Aqua Body Manual de usuario

Philips

Philips NORELCO AT880 Manual de usuario

Matheo

Matheo MLR 15 Manual de usuario

Braun shaver Manual de usuario

Manuales populares de Rasuradora eléctrica de otras marcas
