Branson 00 Series Manual de usuario
Branson 00 series
Manual transmission: 2100/2400
Operator’s Manual
Kukje Machinery Co,.LTD
- 2
-
CONTENTS
TO ENSURE SAFE OPERATION ……………………………………………………………… 6
GENERAL PRECAUTIONS…………………………………………..……………………… 6
GENERAL PRECAUTIONS DURING OPERATION………………………………………… 14
GENERAL PRECAUTIONS AFTER OPERATION………………….…………………… 15
GENERAL PRECAUTIONS FOR STORAGE……………………………………………… 17
GENERAL PRECAUTIONS IN INCLINED AREA …………………………………………… .19
MAINTENANCE BEFORE OPERATION…………………………….……………………… 20
MISC. PRECAUTIONS………………………………………………………………………… 21
ABOUT WARRANTY …………………………………………………………………………… 26
OVERVIEW OF THE TRACTOR ……………………………………………………………… 27
LOCATION OF SAFETY DECALS ………………………………………..…………………… 26
FUNCTIONS ………………………………………………………………………………… 31
PARTS FOR ENGINE CONTROL ………………………………….…………………… 31
PARTS FOR DRIVE & PTO ……………………………………………………………… 33
PARTS FOR HYDRAULIC SYSTEM ………………………………..……………………… 36
PARTS FOR ELECTRIC SYSTEM …………………………………..…………………… 37
INSTRUMENT PANEL ………………………………………………………………………… 39
OTHER PARTS ………………………………………………………..……………………… 42
OPERATION & WORK……………………………………………………………………… 43
1. CHECKING BEFORE OPERATION …………………………………………………… 43
2. BREAKING IN YOUR TRACTOR(FIRST 50 HOURS) ………….…………………… 48
3. STARTING AND STOPPING THE ENGINE ……………………….………………… 48
4. TO RAISE OR LOWER IMPLEMENTS ………………………………..………………… 52
5. ADJUSTING THE LOWERING SPEED OF THE IMPLEMENTS …………………… 52
6. DRIVING ON THE ROAD …………………………………………………….…………… 53
7. DRIVING ON A SLOPE ………………………………………………..……………… 54
8. ENTERING AND LEAVING THE PAVEMENT ………………………………………… 55
9. TURNING ON THE PAVEMENT ………………………………….………………… 55
10. DIFFERENTIAL GEAR LOCK ………………………………………..………………… 56
11. INSTALLING 3-POINT HITCH ………………………………………………………… 57
12. AUX. HYDRAULICS ………………………………………………..…………………… 58
13. ADJUSTING WHEEL TREAD ……………………………………………………… 59
14. POWER STEERING ………………………………………………………………… 60
15. PRECAUTIONS FOR CONNECTING THE IMPLEMENT ………………………… 60
18. ROPS FOLDING METHOD ……………………………………………………………… 61
MAINTENANCE AFTER WORK ……………………………………………….……………… 62
- 3
-
1. MAINTENANCE AFTER WORK …………………………………………..……………… 62
2. MAINTENANCE FOR PROLONGED STORAGE ……………………………………… 63
PERIODIC MAINTENANCE AND ADJUSTMENT ……………………….……………… 64
1. PERIODIC MAINTENANCE SCHEDULE ………………………..………………… 65
2. OIL, GREASE, AND ANTI-FREEZE CHART …………………………………………… 66
3. FUEL, OIL, AND COOLANT CHART …………………………………………………… 66
4. OPENGIN AND CLOSING HOOD, SIDE COVER …………..………………… 67
5. CHEKING AND CHANGING OIL ………………………………………………………… 68
6. FILTER REPLACEMENT …………………………………………………….………… 70
7. RADIATOR SCREEN & AIR CLEANER ELEMENT …………………………………… 71
8. CLEANING OF RADIATOR SCREEN ………………………………………….……… 71
9. COOLANT ……………………………………………………………………….………… 72
10. DRAINING AIR FROM FUEL TANK …………………………………………………… 74
11. BATTERY ……………………………………………………………………………… 74
12. PIPES (Fuel Hoses) …………………………………………………………… 75
13. ELECTRICAL CABLES …………………………………………………….…………… 76
14. GREASING ……………………………………………………………………… 76
15. CLUTCH ………………………………………………………….…………………… 77
16. STEERING WHEEL …………………………………………………………… 77
17. BRAKE …………………………………………………………………………………… 78
18. FAN BELT ……………………………………………………….……………………… 79
19. TIRES …………………………………………………………….………….…………… 79
20. COLOR OF EXHAUST GAS ………………………………………………………… 80
21. FUSE & FUSEABLE LINKS …………………………………………………………… 80
22. TOE-IN ………………………………………………………………………..………… 81
TROUBLESHOOTING ………………………………………………………………..………… 82
1. ENGINE …………………………………………………………………………………… 82
2. CLUTCH & BRAKE ……………………………………………………………… 84
3. HYDRAULIC SYSTEM ……………………………………………………… 84
4. ELECTRICAL SYSTEM ……………………………………………………… 85
SPECIFICATIONS ……………………………………………………………………… 86
- 4
-
- 5
-
THANK YOU FOR PURCHASING A BRANSON TRACTOR.
-
This Manual contains handling tips and precautions for safe operation of your
new tractor. Read it carefully before you operate your tractor, and make sure
that you have a full understanding of this Manual. This will ensure correct
operation and to keep the tractor in optimum condition.
-
After reading the Manual, keep it close to the tractor for immediate reference.
-
When you loan your tractor to someone else, loan the Manual as well.
-
In case the Manual is lost or damaged, please contact your nearest
authorized dealer for a copy.
-
Some parts of this product may have been changed for the improvement of
quality or for safety reasons, in which case the photographs or drawings of
the parts in this booklet may not be the same as the actual parts installed on
this product.
-
If you find anything in this Manual unclear or need further explanation, please
contact your authorized dealer.
The instructions given with the following marks are very important for your safety．
Failure to observe the instruction given with this mark may result in death
or injury.
Failure to observe the instruction given with this mark may expose you to
the risk of death or injury.
Failure to observe the instruction given with this mark may expose you to
injury.
• The section, “ To Ensure Safe Operation,” on the following pages details safety points to
be observed to ensure safe operation of your tractor．Please make sure you read it
carefully before operating the tractor.
Read this Manual for correct and safe use of the product．Failure to use the product properly
may result in an accident. Keep this Manual close to the tractor after you have read it.
- 6
-
TO ENSURE SAFE OPERATION
Be sure to observe the instructions given in this section to avoid machinery
breakdown or personal injury or death.
• GENERAL PRECAUTIONS
Beware of exhaust gas
Do not start or operate the engine in an enclosed
space.
And you should only operate engine outside or in a
well ventilated area.
[Otherwise]
The exhaust gas can cause intoxication and lead
to fatal consequences.
Carry out maintenance on a flat and
safe place.
Select a flat and safe location to secure the tractor
in place and will not cause a risk to people passing
by. Before carrying out the maintenance, block the
front and rear tires to prevent moving while servicing
tracks.
[Otherwise]
An unexpected accident may occur, such as
overturning of the tractor.
Carry out maintenance in a
well-lit place.
Make sure work area is properly lighted.
Use safety work lights with protective covering.
[Otherwise]
An unexpected accident may occur, possibly fire
or explosion.
- 7
-
Prepare for emergencies
Keep a first aid kit and fire extinguisher handy at all
times while operating equipment.
Do not drive if you are:
• Unable to concentrate because of fatigue, under
treatment of medicine.
• Under the influence on alcohol
• Pregnant
• Under the age of 18
Wear the appropriate
clothing when operating
equipment
Do not wear loose fitting clothes.
Do wear proper foot wear with anti-slip soles,
safety helmet and protective comfortable clothes to
allow freedom of movement.
【Otherwise】
You will be exposed to a risk of being entangled
will equipment resulting in injury
Use only recommended
implements
Be sure to use only implements which are
recommended by manufacturer.
【Otherwise】
An unexpected accident may occur or tractor
may not perform properly
- 8 -
Fasten your seat belt at all
times
Keep your seat belt fasten at all times while
operation tractor．
【Otherwise】
There is a risk of death or serious injury if an
accident occurs.
Check the safety of the
tractor and start to move
slowly．
Only operate tractor while people or animal are at
safe distance away.
Check around the tractor, start the engine, and
move slowly．
【Otherwise】
There is a risk of injury．
Pay attention to the
shoulder of the road
When moving along the unpaved road with ditches
or slanted sides, pay attention to the shoulders．
【Otherwise】
There is a risk of falling over．
Connect the break pedals
when driving on a road．
Make sure to connect the brake pedals when driving
on a road．
【Otherwise】
There is a risk of abrupt turning or overturning
due to one-sided braking.
- 9
-
Avoid braking, or turning at
excessive Speed
Reduce throttle speed when making a turn, apply
brake on driving on a hilly or curved road.
.
【Otherwise】
There is a risk of overturning
Observe traffic regulations
and drive safely.
When driving on the road, observe the traffic
regulations and wear a hardhat and seat belt.
【Otherwise】
There is a risk of accident or injury．
Only driver should be
aboard the tractor while in
operation
This tractor is designed to allow only one operator.
The driver must not allow anyone else to get on the
tractor.
* Especially, children
【Otherwise】
An unexpected accident may occur．
Donot allow anyone near
while operating the tractor
or implement.
When engaging or disengaging the implement by
moving the tractor, make sure that no one is around
the tractor or between the implement and the tractor．
【Otherwise】
There is a risk of accident or injury．
- 10 -
Keep children away from
the tractor.
Fully warn the children and keep them away from
the tractor at all times.
【Otherwise】
There is a risk of injury．
Properly train anyone
operating
Explain the handling tips in detail and make sure the
driver reads the Manual before driving．
【Otherwise】
There is a risk of death, serious injury,
or damage to tractor．
Treatment of hazardous materials
zProperly discard hazardous materials.
zHazardous materials from tractor are the
following: Coolant, brake oil, oil, filter elements,
battery and so on.
● When draining fuel, oil or other liquids, use a
container without holes. Do not dispose of
chemicals on the ground or in rivers or
waterways.
No smoking or open flame when
fueling.
Absolutely no lit cigarettes, matches, or lighters any where
near when fueling the tank.
【Otherwise】
Fire or explosion may occur.
