BOXLIGHT CD-455m Manual de usuario

CD-455m/555m

BOXLIGHT

19332 Powder HIll Place

Poulsbo WA 98370-7407 USA

www.boxlight.com

U.S. and Canada: 800-762-5757

International: 360-779-7901

USER'S

GUIDE

Downloaded From projector-manual.com Boxlight Manuals

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio communi-

cations. Operation of this equipment in a residential area is likely to cause harm-

ful interference in which case the user will be required to correct the interference

at his own expense.

Canada

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Can-

ada.

Safety Certifications

UL, CUL, TÜV, NOM

EN 55022 Warning

This is a Class A product. In a domestic environment it may cause radio interfer-

ence, in which case the user may be required to take adequate measures. The typ-

ical use is in a conference room, meeting room or auditorium.

Downloaded From projector-manual.com Boxlight Manuals

Declaration of Conformity

Manufacturer: Boxlight

19332 Powder Hill Place, Poulsbo, Washington, USA

We declare under our sole responsibility that the CD-455m and CD-555m projec-

tors conform to the following directives and norms:

Directive 89/336/EEC, Amended by 93/68/EEC

EMC: EN 55022 (1992) Class A

EN 55024 (1998)

Directive 73/23/EEC, Amended by 93/68/EEC

Safety: EN 60950: 1992 + A1 + A2 + A3 + A4: 1997

July, 2000

Trademarks

Apple, Macintosh, and PowerBook are trademarks or registered trademarks of

Apple Computer, Inc. IBM and PS/2 are trademarks or registered trademarks of

International Business Machines, Inc. Microsoft, PowerPoint, and Windows are

trademarks or registered trademarks of Microsoft Corporation. Digital Light Pro-

cessing is a trademark or registered trademark of Texas Instruments.

Downloaded From projector-manual.com Boxlight Manuals

TABLE OF CONTENTS

Safety Instructions iii

Introduction 1

Image Resolution 1

Compatibility 2

Unpacking the Projector 2

Usage Guidelines 4

If You Need Assistance 5

Warranty 5

Setting up the Projector 7

Connecting a Computer 9

Connecting a Video Player 11

Powering up the Projector and Adjusting the Image 13

Turning Off the Projector 14

Using the Projector 15

Basic Image Adjustment 15

Using the Remote Control 15

Adjusting the Projector 17

Using the Keypad and Remote Buttons 18

Using the On-Screen Menus 20

Display Menu 21

Audio Menu 23

Image Menu 24

Controls Menu 27

Language Menu 29

Status Menu 30

Maintenance & Troubleshooting 33

Cleaning the Lens 33

Replacing the Projection Lamp 33

Replacing the Batteries in the Remote Control 36

Using the Security Lock 36

Troubleshooting 37

Downloaded From projector-manual.com Boxlight Manuals

Ta b l e o f C o n t e n t s

Appendix 41

Specifications 41

Accessories 42

Portable and Laptop Activation Chart 44

Using Video Mirroring with a PowerBook Computer 49

Projected Image Size 50

Index 51

Downloaded From projector-manual.com Boxlight Manuals

iii

SAFETY INSTRUCTIONS

Please read and follow all safety instructions provided BEFORE

using your new projector. Failure to comply with safety instruc-

tions may result in fire, electrical shock, or personal injury and

may damage or impair protection provided by equipment. Please

save all safety instructions.

Safety Definitions:

•Warning: Statements identify conditions or practices that

could result in personal injury.

•Caution: Statements identify conditions or practices that could

result in damage to your equipment.

Safety Symbols:

Attention: For information about usage of a feature, please

refer to the User’s Guide.

Warning: Hot surface. Do not touch.

An arrow pointing to the lamp door on the projector.

Safety Terms:

•Warning: Don’t look directly into the lens when the lamp is

turned on.

•Warning: To replace the lamp, turn the projector off by

unplugging the power cord. To avoid burns, wait 30

minutes before opening the lamp door. Follow all instructions

provided in this User’s Guide.

•Warning: Please use the power cord provided. Connect

the power cord to a receptacle with a protective safety

(earth) ground terminal.

•Warning: Refer all service to qualified service personnel. Ser-

vicing your own projector will void the warranty. See the fol-

lowing page for the customer service contact information.

•Caution: Don’t block ventilation openings.

Downloaded From projector-manual.com Boxlight Manuals

Safety Instructions

•Caution: Don’t set liquids on the projector. Spilled liquids may

damage your projector.

•Caution: Don’t place the projector on a hot surface or in direct

sunlight.

•Caution: Do not drop the projector. Transport the projector in a

Boxlight-approved case; see page 43 for a list of cases.

Important Operating Considerations

Do not place the projector on a tablecloth or other soft covering

that may block the vents. In the unlikely event of the bulb ruptur-

ing, thoroughly clean the area behind the projector and discard

any edible items placed in that area.

Customer Service

If you need assistance, call Boxlight at 1-800-762-5757 or

360-779-7901.

Do not place objects in

this area behind the projector

2ft(.6m)

Downloaded From projector-manual.com Boxlight Manuals

INTRODUCTION

The Boxlight®CD-455m™ and CD-555m™ multimedia projec-

tors are specifically designed for multipurpose use. They gener-

ate crisp, clear images using Digital Light Processing™ (DLP)

technology, and feature an M1-DA connector for easy, built-in

digital/analog and USB connectivity. They are easy to connect,

easy to use, easy to transport, and easy to maintain. The

CD-455m has native SVGA 800x600 resolution, the CD-555m has

XGA 1024x768 resolution. The user interfaces of the two products

are identical; information in this user’s guide applies to both

products.

NOTE: The CD-455m automati-

cally expands 640x480 images to

800x600. You can display these

images at their native resolutions

by turning off the Auto Resize fea-

ture. See “Resize” on page 24 for

more information.

Image Resolution

CD-455m

The SVGA resolution of the CD-455m’s projected image is

800x600. The projector cannot compress screen resolutions above

1024x768. If your computer’s screen resolution is higher than

1024x768, reset it to a lower resolution before you connect the

projector.

CD-555m

The XGA resolution of the CD-555m’s projected image is

1024x768. The projector cannot compress screen resolutions

above 1024x768. If your computer’s screen resolution is higher

than 1024x768, reset it to a lower resolution before you connect

the projector.

NOTE: The CD-555m automati-

cally expands 640x480 and

800x600 images to 1024x768.

You can display these images at

their native resolutions by turning

off the Auto Resize feature. See

“Resize” on page 24 for more

information.

Downloaded From projector-manual.com Boxlight Manuals
