BOXLIGHT CD-450m Manual de usuario

BOXLIGHT

CD-450m/ CD-550m

USERS GUIDE

Free phone within these areas:

United Kingdom: 0800-762-575

Germany: 0800-180-8381

France: 0800-9132-88

USA and Canada: 800-762-5757

Direct Phone:

USA: (360) 779-7901

Europe: +44 (0) 1732-840-404

19332 Powder Hill Place

Poulsbo, WA 98370-7407 USA

www.boxlight.com

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio communi-

cations. Operation of this equipment in a residential area is likely to cause harm-

ful interference in which case the user will be required to correct the interference

at his own expense.

Canada

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du

Canada.

Safety Certifications

UL, CUL, TÜV, NOM

EN 55022 Warning

This product is intended for use in a commercial, industrial, or educational envi-

ronment. It is not intended for residential use.

This is a Class A product. In a domestic environment it may cause radio interfer-

ence, in which case the user may be required to take adequate measures. The typ-

ical use is in a conference room, meeting room or auditorium.

Wenn das Produkt CD-450m/550m in Deutschland verkauft wird, muss es

Umwelt geschuetzt sein. (Klasse B) Dieses Product muss mit dem Bundesamt

fuer Post und Telekommunikation registriert sein. (BAPT)

Declaration of Conformity

Manufacturer: Boxlight

19332 Powder Hill Place, Poulsbo, Washingotn, USA

We declare under our sole responsibility that the CD-450m and CD-550m Projec-

tors conform to the following directives and norms:

Directive 89/336/EEC, Amended by 93/68/EEC

EMI: EN 55022 (1992) Class A

EMC: EN 50082-1 (1992)

IEC 801-2, IEC 801-3, IEC 801-4

Directive 73/23/EEC, Amended by 93/68/EEC

Safety: EN 60950: 1992 + A1 + A2 + A3: 1995

March, 1999

Trademarks

Apple, Macintosh, and PowerBook are trademarks or registered trademarks of

Apple Computer, Inc. IBM and PS/2 are trademarks or registered trademarks of

International Business Machines, Inc. MicroSaver and Kensington are trademarks

or registered trademarks of Kensington Microware Limited. Microsoft, Power-

Point, and Windows are trademarks or registered trademarks of Microsoft Corpo-

ration. Digital Light Processing is a trademark or registered trademark of Texas

Instruments. CablePro is a trademark or registered trademark of Boxlight.

TABLE OF CONTENTS

Safety Instructions iii

Introduction 1

Image Resolution 1

Compatibility 2

Unpacking the Projector 2

Usage Guidelines 5

If You Need Assistance 5

Warranty 5

Setting up the Projector 7

Connecting the CablePro III to the Projector 8

Preparing to Connect Your Equipment to the Projector 9

Connecting a Laptop Computer 10

Connecting a Desktop Computer 12

Connecting a Video Player 14

Powering up the Projector and Adjusting the Image 16

Turning Off the Projector 17

Using the Projector 19

Basic Image Adjustment 19

Using the Remote Control 19

Adjusting the Projector 21

Using the Keypad and Remote Buttons 22

Using the On-Screen Menus 24

Display Menu 25

Audio Menu 27

Image Menu 28

Controls Menu 30

Language Menu 32

Status Menu 33

Maintenance & Troubleshooting 35

Cleaning the Lens 35

Replacing the Projection Lamp 35

Replacing the Batteries in the Remote Control 38

Using the Kensington Lock 39

Troubleshooting 39

Table of Contents

Appendix 43

Specifications 43

Accessories 45

Portable and Laptop Activation Chart 47

Using Video Mirroring with a PowerBook Computer 52

Projected Image Size 53

Index 57

iii

SAFETY INSTRUCTIONS

Please read and follow all safety instructions provided BEFORE

using your new projector. Failure to comply with safety instruc-

tions may result in fire, electrical shock, or personal injury and

may damage or impair protection provided by equipment. Please

save all safety instructions.

Safety Definitions:

•Warning: Statements identify conditions or practices that

could result in permanent personal injury.

•Caution:Statements identify conditions or practices that could

result in damage to your equipment.

Safety Symbols:

Attention:For information about usage of a feature, please

refer to the User’s Guide.

Warning: Hot surface. Do not touch.

An arrow pointing to the lamp door on the projector.

Safety Terms:

•Warning: Don’t look directly into the lens when the projector is

turned on.

•Warning: Don’t block ventilation openings.

•Warning: To replace the lamp, turn the power off and

unplug the power cord. To avoid burns, wait 30 minutes

before opening the lamp door. Follow all instructions provided

in this User’s Guide.

•Warning: Please use the power cord provided. Connect

the power cord to a receptacle with a protective safety

(earth) ground terminal.

•Warning: Refer all service to qualified service personnel. Ser-

vicing your own projector will void the warranty. See the fol-

lowing page for the customer service contact information.

Safety Instructions

•

Caution: Don’t set liquids on the projector. Spilled liquids may

damage your projector.

•Caution:Don’t place the projector on a hot surface or in direct

sunlight.

•Caution: Do not drop the projector. Transport the projector in a

Boxlight-approved case; see page 46 for a list of cases.

•Caution: For ceiling mount installations, please use the ceiling

mount recommended in this User’s Guide on page 46 and fol-

low all instructions provided with it.

Customer Service

If you need assistance, call Boxlight at 1-800-762-5757.

INTRODUCTION

The Boxlight®CD-450m and CD-550m lightweight multimedia

projectors are specifically designed for the mobile presenter. They

generate crisp, clear images using Digital Light Processing™

(DLP) technology. The projectors are easy to connect, easy to use,

and easy to maintain. The soft carry case makes it easy to trans-

port the 7.4 pound projectors. The 450m has SVGA 800x600

graphics, the 550m has XGA 1024x768 graphics. The user inter-

faces of the two products are identical; information in this User’s

Guide applies to both products.

NOTE: The 450m automatically

expands 640x480 images to

800x600. You can display these

images at 640x480 by turning off

the Auto Resize feature. See “Auto

Resize” on page 28.

Image Resolution

CD-450m

The SVGA resolution of the 450m’s projected image is 800x600.

Screen resolutions between 800x600 and 1024x768 are com-

pressed to 800x600. The projector cannot compress screen resolu-

tions above 1024x768. If your computer’s screen resolution is

higher than 1024x768, reset it to a lower resolution before you

connect the projector.

CD-550m

NOTE: The 550m automatically

expands 640x480 and 800x600

images to 1024x768. You can dis-

play these images at their original

resolutions by turning off the Auto

Resize feature. See “Auto Resize”

on page 28.

The XGA resolution of the 550m’s projected image is 1024x768.

The projector cannot compress screen resolutions above

1024x768. If your computer’s screen resolution is higher than

1024x768, reset it to a lower resolution before you connect the

projector.

Introduction

Compatibility

The projector is compatible with a wide variety of computers and

video devices, including:

•IBM-compatible computers, including laptops, up to 1024x768

resolution at 75 Hz

•Apple Macintosh and PowerBook computers up to 1024x768

resolution at 75 Hz.

•Most standard VCRs, DVD players, camcorders and laser disc

players.

Unpacking the Projector

The projector comes with the items shown in Figure 1. Check to

make sure all are included. Contact Boxlight immediately if

anything is missing.

If you are experienced in setting up presentation systems, use the

Quick Start card that was included in the shipping box. For com-

plete details on connecting and operating the projector, refer to

this User’s Guide.

NOTE: The contents of your

shipping box may vary depending

on the projector configuration

you’ve ordered.
