VerciseTM DBS
Charging
Handbook
91171709-15
Content: MP91171709-15 REV A
en tr ru ar hearar
VerciseTM DBS Charging Handbook
91171709-15 Page ii of iv
VerciseTM DBS Charging Handbook
en
Trademarks
All trademarks are the property of their respective holders.
Guarantees
Boston Scientic Corporation reserves the right to modify, without prior notice, information relating to its products in order to improve their
reliability or operating capacity.
Drawings are for illustration purposes only.
Additional Information
Refer to the appropriate Information for Patients DFU and Remote Control Handbook for additional instructions and information about your DBS
System. Refer to the Labeling Symbols document for an explanation of labeling symbols.
References to the Charging System or charging process are applicable only when using a rechargeable DBS Stimulator.
Contacting Boston Scientic
To contact Boston Scientic, see the “Technical Support” section of this manual.
Product Model Numbers
Model Number Product Name
DB-64125 Vercise Charging System
DB-6300-C Vercise Charging Collar Accessories
DB-6200-C Vercise Charging Collar, Small
DB-6100-C Vercise Charging Collar, Medium
NM-6350 Adhesive Kit
NM-5312 Charger
NM-5305 Base Station
NM-6305 Power Supply & Adapter For Charger (EU)
VerciseTM DBS Charging Handbook
91171709-15 Page iii of iv
en
Table of Contents
Introduction............................................................................................................................................................. 1
Using the Charging System................................................................................................................................... 2
Getting Set Up...............................................................................................................................4
Charging the Charger....................................................................................................................5
Understanding the Charger Sound Alerts......................................................................................7
Charging Your Stimulator ..............................................................................................................8
Using the Charging Collar .............................................................................................................9
Using the Adhesive Patch ........................................................................................................... 11
Properly Aligning the Charger .....................................................................................................12
Tips for Properly Aligning the Charger ........................................................................................14
Cleaning Instructions...................................................................................................................16
Technical Support ................................................................................................................................................ 17
VerciseTM DBS Charging Handbook
91171709-15 Page iv of iv
VerciseTM DBS Charging Handbook
en
This page intentionally left blank.
VerciseTM DBS Charging Handbook
91171709-15 Page 1 of 109
Introduction
en
Introduction
The Boston Scientic Deep Brain Stimulation (DBS) System provides a reversible therapy that stimulates structures in the
brain with small electrical pulses. The Boston Scientic DBS System includes a rechargeable Stimulator that requires periodic
recharging. The Charging System allows you to recharge the Stimulator battery as needed.
The Charging System for the Stimulator consists of the Charger, a Base Station, and a Power Supply. The Charging System also
includes a Charging Collar that holds the Charger over the Stimulator.
This manual provides you with instructions for charging your Stimulator. We encourage you to read this and your other Boston
Scientic manuals entirely. If you have any questions, or need clarication on anything contained in this manual, contact
Technical Support.
VerciseTM DBS Charging Handbook
91171709-15 Page 2 of 109
VerciseTM DBS Charging Handbook
en
Using the Charging System
You should expect a daily recharging time of 5 to 30 minutes per day or a periodic recharging time of 30 minutes to 4 hours every
1 to 2 weeks. Your recharge routine may vary depending on your stimulation settings. Some stimulation settings will require more
frequent charging. Boston Scientic recommends any recharge routine that ts your schedule and lifestyle while maintaining
sufcient charge to maintain stimulation.
Developing a recharge routine involves nding the right balance between four factors:
●How much power is required to experience effective therapy
●How often you want to recharge
●How long you want to recharge
●How you would like to manage your personal schedule
The Boston Scientic DBS System’s programming software gives your healthcare provider a conservative recommendation for
how often to charge. This estimate assumes stimulation is on 24 hours per day, 7 days per week at the programmed energy
output level. While you may want to follow these recommendations, you and your physician can also develop an appropriate
charge routine that best ts your schedule.
The Remote Control provides an easy‑to‑view Stimulator battery meter on the Home screen and messages to inform you of the
battery’s condition. When the Remote Control indicates a low battery, the Stimulator should be recharged as soon as possible.
Failure to recharge may result in loss of stimulation. After stimulation stops, communication with the Stimulator will also stop until
the Stimulator is sufciently charged. Refer to your Remote Control Handbook for more information.
VerciseTM DBS Charging Handbook
91171709-15 Page 3 of 109
Using the Charging System
en
The rechargeable Stimulator battery should provide at least ve years of service. In many cases, the Stimulator battery should
provide at least 25 years of service. Battery life is dependent on the stimulation settings and conditions.
Over time and with repeated charging, the battery in the Stimulator will lose its ability to recover its full capacity. As a result, the
Stimulator may require shorter intervals between charges. The Stimulator will need replacement when stimulation can no longer
be maintained with a routine charging.
VerciseTM DBS Charging Handbook
91171709-15 Page 4 of 109
VerciseTM DBS Charging Handbook
en
Getting Set Up
Check that you have received all the components included in your DB‑64125 Vercise Charging System (see Table 1). If any item
is missing, contact Technical Support for a replacement.
Table 1: Components of the Vercise Charging System
Label Description
ACharging Collar (2)
BBase Station (1)
CPower Supply (1) and Adapter (1)
DCounterweight (1)
E Charger (1)
F Charging Spacer (1)
Also, be sure you received your Patient Identication Card from your healthcare provider.
A B C
D E F
VerciseTM DBS Charging Handbook
91171709-15 Page 5 of 109
Using the Charging System
en
Charging the Charger
The Charger contains a rechargeable battery that is used to recharge your Stimulator’s battery (see Table 2).
Cautions:
●Keep the Charging System dry. It should not be exposed to
moisture.
●Do not connect the Charger to any other device except to the
Base Station provided with it.
●Keep the Charging System away from pets, pests, and
children to avoid damage to the device.
To charge the Charger:
1. Find a convenient electrical outlet that will allow you to place
the Base Station on a clear, at surface and will not expose the
Charging System to water or direct heat.
2. Plug the Power Supply into a standard AC wall outlet.
3. Connect the Power Supply to the Base Station.
4. Place the Charger in the Base Station with the power button
facing up.
Note: The Base Station is designed to remain connected to a power outlet at all times. When it is not being used, keep the
Charger on the Base Station so that it is always ready to deliver a charge.
Table 2: Vercise Charger System Components
Label Description
APower Supply
B Charger
C Indicator Light
DPower Button
EBase Station
VerciseTM DBS Charging Handbook
91171709-15 Page 6 of 109
VerciseTM DBS Charging Handbook
en
The Charger is ready to fully charge your Stimulator when the Charger’s indicator light is green. If the indicator light is yellow, the
Charger can only partially charge the Stimulator. While the Charger may be used when the indicator light is yellow, it may not be
able to fully charge your Stimulator and you may need to charge sooner than usual.
Charger
Indicator Light Description
Green The Charger is fully charged and ready to charge the Stimulator.
Yellow The Charger is partially charged. The Charger may still be used, but it may not be able to fully
charge the Stimulator. To fully charge the Charger, place it in the Base Station.
Off The Charger is off – or – the Charger battery is empty. If pressing the Power Button does not
turn on the Charger, place the Charger in the Base Station to charge.
Charger Battery Service Life
The Charger battery has a typical service life of 500 charging cycles.
