Boss Audio Systems BV9370NV Manual de usuario
BV9370NV
GPS
SDMAP
BV9370NV
MIC
CONTENTS
01
INSTRUCTIONS
Panel Introduction 02
Basic Functions 03
Remote Control Function 04
Radio Function Operation 07
Disc Function Operation 08
Play/Eject Disc 08
DVD/VCD Disc Playback 08
CD Disc Playback 08
MP3/WMA Format Disc Playback 08
Touch Menu Function 09
Language Setup 13
Touch calibration 13
Wiring Diagram 15
Trouble shooting 15
External input operation 11
Calculator function operation 11
Wallpaper function operation 11
Steering wheel setting 11
iPod function operation 11
Other Function Operations 12
Rear view function 12
Accessory 17
17
DVD Parental control function
Specifications 16
13
Regional radio
13
TV standard
13
System Setting
13
Version Information
13
Time setting
13
Navigation setting
13
Audio Setting
13
Touch calibration
06
Turn on/off Host
06
Access main interface
06
Background Setup
06
Setting method:
06
Darkness bright screen mode
GPS Navigation Function Operation 12
10
Bluetooth Function Operation
INSTRUCTIONS
02
1
2
3
4
5
6
7
8
9 10 11
12
1.SRC Button
2.MUTE/TFT on/off Button
3.GPS Button
4.SD Slot
5.RESET Button
6.SEL/VOL Button
7.AUX IN
8.USB Slot
9.Disk Load Slot
10.OPEN Button
11.Remote Control Receiver
12.MIC Input
13.GPS/MAP (Map Card Socket)
Panel Introduction
SDMAP
GPS
BV9370NV
13
03
INSTRUCTIONS
BASIC FUNCTION
1.SRC Button
4.SD Slot
This is a high-spees transmission interface, which can read high-capacity date in
MP3 or MP4 format.
5.RESET Button
Press this button and this unit will be restored to the initial state.
6.SEL/VOL Button
Turn this button can adjust the volume,Press this button can adjust the
mode according to personal likes.
2.MUTE/TFT on/off Button
Subwoofer Mute Feature:
To turn subwoofer off, push Mute on, then Mute off. The subwoofer output will now be silent.
To turn it back on, push EQ.
7.
9.Disk Load Slot
Opening for disks to enter or retreat.
10.OPEN Button
Press this button can eject the disc
11.Remote Control Receiver
12.MIC Input
Bluetooth MIC input.
20. GPS/MAP (Map Card Socket)
Insert map card to read navigation map data.
8 Dual (front and rear)USB
Warning :You can only use either front or rear USB at a time.Never connect both front
and rear USB at the same time! This could cause malfunctions.
2. GPS Button
Press this button for the navigation.
04
REMOTE CONTROL FUNCTION
INSTRUCTIONS
5.SEEK+ ( )/ SEEK- ( )button
In normal playback MP3, USB, SD songs, press this button to
previous song or next song.
CLASSIC,
2
1315
166
4
57911 13
810 1412
28
28 NAVI
21.UP, DOWN, LEFT, RIGHT, ENTER button
When playing MP3, USB, SD returns to song menu,
up, down selections can be up / " " button or
down / " " key to select up and down, select and
press " " key to confirm. The selected tracks can
be played.
Press the left or right arrow keys to " " or " " key,
can be on the next page function operation.
INSTRUCTIONS
05
28.NAVI
Press the button to enter/exit the
navigation interface.
INSTRUCTIONS
06
Turn on/off Host
Access main interface
When the ignition switch is put in ACC or ON position,Press[ ] button on the front panel
to turn on the unit.After the host starts, hold [ ]button for 3 seconds , the host will turn off.
In the other mode, click on the interface to return the icon will switch to the main interface.
Darkness bright screen mode
In the main interface touch icon in the day or
night to switch between two modes.
Background Setup
In the main interface touch [Wallpaper] icon to enter the following interface:
Touch icon or at the touch pen / finger gently sliding the screen to switch the main
menu page. Touch in different interface style to switch between. Touch the function
icons so as to access the corresponding function operations.
h
h
h
h
h
h
Setting method:
Through the preview window, select the
background picture you want.
INSTRUCTIONS
07
Radio Function Operation
Enter/exit
Touch [ RADIO ] icon in the main interface to enter into the radio interface.
Touch icon to return to main interface, and then touch other function icons so as to exit
radio mode.
AF: touch the button to turn on/off AF mode.
TA: touch the button to turn on/off TA mode.
PTY: touch the button the screen displays program types, users can search station
according to program type.
NOTE: If the unit does not have RDS function, it has no AF/TA/PTY function,
.
Touch the
corresponding icon had no effect
Click [ ] icon so as to switch among AM1, AM2 bands.FM1,FM2, FM3,
Band selection
Search/Save radio stations
Short touch the [ / ] button , single-step reverse / forward adjustment FM / AM
reception frequency;
Long touch the [ / ] button, automatic reverse / forward search for FM / AM radio.
Short touch the [ ] button, browse 1-6 sets of bits stored on the radio, Long touch the
[ ] button to long-automatic station search,and the strongest radio signals P1-P6 are
stored in the display position on the table.
Play radio station selection
Touch [ ] icon pop-up selection sets the keyboard input radio frequency selectable
radio frequency spectrum or you can drag directly touch the icon to select a stored radio
station.
Other Functions
Touch [ ] icon to access sound setting interface.
Touch [ ] icon so as to turn on/off loudness function.
Touch [ ] icon so as to turn on/off Long/Short-Range function.
Touch[ ] icon to turn on/off stereo.
Each band can be stored six radio stations, radio stations can be stored directly click
(P1-P6) choice, and will be displayed on the screen.
Operation stored radio
Select a band, and then select a radio station. Press and hold button (P1-P6) to select the
preset number will appear in the corresponding number button on the screen.
How to save radio stations
RDS function provides series information (such as traffice information, name of station) ,
and can automatically switch to the station with stronger signal andcarries the same
program.
RDS Function
PTY TA AF
INSTRUCTIONS
08
Disc Function Operation
Do not insert two discs or more.
Eject disc
(1) Click button on the panel to eject the disc.
(2) If a disc has not been took away 15 seconds after it is ejected, system will
automatically take in the disc but not play.
Play/eject disc
Play disc
Insert the disc into the disc slot with the printing surface up, system will detect the disc
and automatically take it in to read and play.
During playback of disc, touch the middle lower area of the screen to pop up the touch
menu, operate the touch menu to perform various playback controls.(PIC 1)
DVD/VCD disc playback
CD Disc Playback
After a CD is inserted, system shall access disk reading state immediately.
When there is a disk in the device, click [Disk] at the main interface so as to access disk
reading state.
After the disk being read out, system shall automatically play in sequence.
MP3/JPEG/MPEG4 disk playing
When the disk contains readable files, such as MP3/JPEG/MPEG4 files, it shall be
automatically read out and played after slipping into DVD player.
During playing, touch the screen area and the touch menu shall pop up. Operate the
touch menu for various playing.
PIC 1
INSTRUCTIONS
09
Touch Menu Function Description
The disc read, touch area of the screen, pop-up touch menu. Operate a variety of
playback controls the touch menu.
Screen display
Press the button to display title, chapter, play time and left time.
Language Selection
Touch the button, can switch subtitle language.
DVD Setup Menu
Touch the button, pop-up system settings menu,
you can set the system language settings, audio
settings, video settings, and Dolby Digital settings.
Number Button
Touch the button, pop-up numeric keypad. By
touching the numeric keypad for direct selections
played.
Repeat play
During VCD playing, this function only works
when PBC is off.
In playing state, touch this button to start repeat
play function: Chapter → Title → REP All →Off.
Back to Root Menu
Touch the button: to back to root menu in DVD
status; to enter PBC menu play in VCD status.
The interface displays all chapters of disc.Directly
touch the chapters icon option play
Angle Play
When the angle number displays on the screen, press the button repeatedly to switch among
recorded angles.
Access title menu
Press this button to return to title menu of the disk. Directly click menu bar at title menu interface
for playing.
Play/pause
Stop
Eject disc
Sound Settings
The next page menu
Screen display
DVD Setup Menu
Number Button
Loudness on / off
Appears Up/Down/Left/Right
Direction Button
Repeat play
Back to Root Menu
Audio (Dialogue) Button
Access title menu
Language Selection
Angle
Magnify the screen
Insert/Eject USB storage device
1. Connect a U disc recorded with media information to the unit by a USB connecting cable.
2. When there is a need to eject the USB device, exit the USB device playback screen first, and then
take out the device.
Insert/eject SD card
1. Insert a SD card recorded with media information into the SD card slot in the unit correctly until it
is locked.
2. When pulling out the SD card, exit SD card playing state first, then press the SD card and it shall
pop up after unlocking.
Enter/exit
Insert a USB storage device or SD card to automatically play data contained in it. If the unit has
connected with a USB device or SD card, touch[ USB ]icon in the multimedia interface to enter into
the external storage playback interface; Touch[ SD ]icon to enter into the SD card playback interface.
During playback, touch the top center area of the screen to pop up the touch menu, operate touch
menu to perform various playback controls.
When there is a USB device/SD card connected, the unit can conduct the playback of
image files in the USB device/SD card.
audio/video/
U Disc/SD Card function operation
Play
After SD card/USB removable device being read out, the operation methods are similar to disk
operation methods.
previous/next
