Bose 302 A Instrucciones de montaje

Bose

Panaray

302

™

A Loudspeaker

Installer’s Guide

English

Safety Information

Safety reminders

1.1 Read and keep all safety and operating instructions for future

reference.

1.2 For your safety, follow all cautions and warnings in the operating

instructions and on the speakers.

1.3 Follow the instructions in this guide carefully when installing this

product.

1.4 Do not install the loudspeakers near excessive heat sources.

This includes installations near or above radiators, ranges, grills,

fryers, stoves, or other appliances.

1.5 Always route cables so heavy or sharp objects cannot pinch or

cut them.

1.6 Service by a qualified service person if:

A. The loudspeaker cone is visibly damaged;

B. The loudspeakers do not operate normally even though the

instructions in this guide have been followed;

C. The loudspeakers exhibit a distinct change in performance.

In accordance with EMC Directive 89/336/EEC and Article 10(1) of the Directive,

is in compliance with the following norm(s) or document(s):

Technical regulations: EN50081-1, EN50082-1

Accredited by:

Bose Corporation, The Mountain, Framingham, MA 01701-9168 USA

Bose Products B.V.

Nijverheidstraat 8, 1135 GE Edam

The Netherlands

Nic Merks

Vice President Europe

Manufacturer’s authorized EU representative

29 April 2000

DECLARATION OF CONFORMITY

We, the offerer:

Bose®Corporation, The Mountain, Framingham, MA 01701-9168 USA

acknowledge our sole responsibility, that the product:

Kind of equipment: Loudspeaker

Type designation: 302TMA loudspeaker

English

Installation

1.0 Package contents

2.0 Steps for loudspeaker installation

To install the Bose

Panaray

302

™

A loudspeaker, first remove the

transformer cover from the bracket.

2.1 Changing the voltage and tap setting

The transformer is set at the factory for 70V, 200W operation.

To change from 70V, replace the orange wire with:

•Yellow for 100V

To change from 200W, replace the red wire with:

•Green for 100W

•Violet for 50W

•Blue for 25W

Caution: Do not replace or remove the black ground wire.

Be sure to put a wire nut or electrical tape over the bare end of the

wire you remove.

Blue

Violet

Green

Red

White

Red

Black

Yellow

Orange

Black

25W

50W

100W

200W

English

2.2 Mounting the bracket

Caution: Install the loudspeakers in compliance with local building

and electrical codes. Use minimum size #10 (M4) pan head screws.

In the U.S., this version is designed for installation using Class 2

wiring methods in accordance with Articles 640 and 725 of NFPA

70, National Electrical Code.

2.2.1 Prepare the mounting surface

For either wall or ceiling mounting, use all four mounting holes on

the bracket, and use anchors as needed. For indoor installations on

wallboard, be sure that at least two of the screws attach to a stud.

Warning: For outdoor installations, do not attach the bracket to

wallboard construction.

Wall mounted Ceiling mounted

3.25"

8.25 cm

2.62"

6.65 cm

2.62"

6.65 cm

Installation

English

25"Ø

0.625 cm

0.625"

1.58 cm

2.2.2 Make an allowance for the wiring

Consider how the amplifier wires will thread into the bracket.

• To use the rear opening on the bracket, be sure to

insert the wires first, before you mount the bracket.

• To use the bottom opening, remove the plug from that

opening. Insert the wires through that opening after the

bracket is attached.

2.2.3 Steps for adding a safety cable

Installation

English

2.4 Attaching the speaker to the bracket

2.3 Connecting the amplifier wires

Installation

English

2.5 Connecting the speaker wires

Red (+)

Installation

Red (+)

Black (-)

2.6 Adjusting the speaker
