1 Camera Setup

Install and wire the 100 Series AutoDome according to the VG5 AutoDome Installation Manual.

A typical system includes a keyboard, matrix switcher, monitor, and appropriate wiring

connections. Please refer to the individual product manuals for complete installation and

setup instructions for each of the system components.

1.1 Configuring the Camera

To assist setup, the VG5-100 Series camera module can be connected to a monitor through

the miniature 2.5 mm monitor jack located on the camera circuit board. The monitor jack

provides a composite video signal with synchronization. An optional cable (part number

S1460) is available for making this connection.

To access the monitor jack, remove the bubble and covert liner:

1. Insert a small screw driver through the keyway in the Pendant trim-ring, rotate the dome

bubble counterclockwise and remove the dome bubble. For In-Ceiling AutoDomes, you

must loosen the small screw in the trim ring before rotating the bubble.

2. Press and hold the two retention buttons on each side of the camera module and then

pull off the covert liner. See the image below.

Removing the covert liner provides access to the menu keys, and the pan and tilt

thumbscrew adjustment locks.

Figure 1.1 100 Series Camera Module

Ref Description

1FrontView

2 Back View

3 Retention Button (2)

4CovertLiner

5MenuKeyboard

6 Monitor Jack

AutoDome 100 Series Fixed Camera Positioning the Camera | en 5

Bosch Security Systems, Inc. User Manual F.01U.216.346 | 1.0 | 2011.04

2 Positioning the Camera

The camera module position can be adjusted along the horizontal, vertical, and diagonal (for

azimuth) axes. When adjusting the position, ensure that the picture displayed on the monitor

is level. After the covert liner is removed, position the camera by performing the following

steps:

1. For horizontal (pan) adjustment, loosen the thumbscrew at the platform base and rotate

the camera (left or right) to the desired position. The camera can be rotated up to 360º

between stops. If it hits the stop before achieving the desired position, rotate it in the

opposite direction. Retighten the thumbscrew to secure the camera.

2. For vertical adjustment (tilt), loosen the thumbscrew at the tilt wheel and position the

camera (up or down) to the desired position. The camera can be tilted up to 110º

between stops. Retighten the thumbscrew to secure the camera.

3. To compensate for angled ceilings or sidewall mounts, push the camera inward toward

its base and rotate it until the image on the monitor is horizontal. The camera can be

rotated up to 300º between stops.

Figure 2.1 Camera Position Adjustments

WARNING!

To prevent damage to the camera module do not rotate the camera past its stops.

CAUTION!

The CCD image sensors are highly sensitive and require special care for proper performance

and extended lifetime. Do not expose it to direct sunlight or bright spotlights in operating and

non-operation conditions. Avoid bright lights in the field of view of the camera.

Ref Description

1 Camera Module Lock Tab

2 Horizontal (pan) Thumbscrew

3 Tilt Wheel Thumbscrew

4 Diagonal Adj.

6en | Adjusting Focal Length (Zoom) and Focus AutoDome 100 Series Fixed Camera

F.01U.216.346 | 1.0 | 2011.04 User Manual Bosch Security Systems, Inc.

3 Adjusting Focal Length (Zoom) and Focus

To adjust the camera lens focal length and focus, perform the following steps:

1. Select Set Focus Now from the Install menu.

2. To adjust the focal length, loosen the focal (zoom) lock screw and rotate the lens

mechanism (WIDE or TELE.) until you achieve the desired field of view. (Item 1, in the

figure below).

3. To focus the image on the monitor, loosen the focus lock screw and turn the lens

mechanism (NEAR or FAR) until the image is in focus.

4. Repeat both these adjustments until the desired view is in focus.

5. Tighten both adjustment screws.

6. Exit the Install menu.

7. Remove the monitor jack and replace the covert liner and dome bubble when finished.

Figure 3.1 Focus and Zoom Adjustment

AutoDome 100 Series Fixed Camera Advanced Setup | en 7

Bosch Security Systems, Inc. User Manual F.01U.216.346 | 1.0 | 2011.04

4 Advanced Setup

The VG5-100 Series camera module normally provides an optimal picture without the need for

further adjustments. Advanced setup options, however, are available for obtaining the best

results from the camera under special circumstances. There are two upper level On-Screen

Display (OSD) menus: the Main menu and the Install menu.

The Main menu allows you to select and setup the picture enhancement functions. The Install

menu allows you to set the camera ID, focus and synchronization settings. The Main and

Install menus have settings that you can select directly or open to submenus for a more

detailed setup.

4.1 Accessing and Navigating Menus

There are five (5) keys used for navigating through the various menus. To access the setup

menus, press the center Select key to open and display the Main menu. Use the four

directional keys to navigate through the menus.

Figure 4.1 Menu Keyboard and Monitor Jack

Use the menu keys to perform the following:

– To access the Main menu or to select a sub-menu item, press the center Menu Select key.

– To open the Install menu press the Menu Select key for approximately 1.5 seconds.

– To scroll up or down a menu press the Up or Down keys.

– To move through options or to set parameters, press the Left or Right keys.

NOTICE!

Active menu selections can vary depending or the combination of camera, CPU and COMM

(communication) modules used. The menu selections described in this manual are typical for

a VG5-100 Series system.

Ref Description Ref Description

1 Menu Keyboard 5 Select Button

2 Monitor Jack 6 Right Button

3 Up Button 7 Down Button

4 Left Button

8en | Advanced Setup AutoDome 100 Series Fixed Camera

F.01U.216.346 | 1.0 | 2011.04 User Manual Bosch Security Systems, Inc.

The VG5-100 Series also supports a variety of remote methods to make camera adjustments,

including the following:

– A Universal keyboard using Bilinx over coax or UTP. For example, using a Bosch DiBos 8,

a Bilinx capable DIVAR, or an Allegiant system.

– A PC running the optional Bosch Configuration Tool for Imaging Devices (CTFID)

software with a USB Bilinx adapter (Part No. VP-CFGSFT).

4.2 Main Menu Function

This section provides a graphical representation of the Main menu and descriptions for all

functions.

1. Available in Day/Night version cameras only, other versions show NightSense.

2. Only available when White Balance is set to Manual mode.

NOTICE!

To restore a selected menu item to its factory default, quickly press the Menu Select key

twice.

To exit the OSD menus from any menu item, hold down the Menu Select key until the OSD

disappears.

NOTICE!

To prevent unauthorized changes to the camera settings, the camera menu buttons can be

disabled using Bilinx communication through the CTFID software. Select the Online Config

button, then select the Miscellaneous branch and set Camera Buttons to Disable.

MAIN Menu

ALC ALC

ENHANCE ALC LEVEL

COLOR SHUT GAIN SHUTGAIN

BLC PEAK AVERAGE SHUTTER

EXIT ALC SPEED DEFSHUT

EXIT FIXSHUT

SENSUP

ENHANCED GAIN

AUTO BLACK MAXGAIN DAY/NIGHT

SHARPNESS FIXGAIN DAY/NIGHT

DNR DAY/NIGHT1SWITCH LVL

XF-DYN NIGHTSENSE PRIORITY

EXIT EXIT IR CONTRAST

MONO BURST

COLOR EXIT

WHITE BALANCE

WB SPEED

RED (GAIN)

GREEN

BLUE (GAIN)

SAT

EXIT

BLC

BLC LEVEL

BLC AREA AREA

EXIT

AutoDome 100 Series Fixed Camera Advanced Setup | en 9

Bosch Security Systems, Inc. User Manual F.01U.216.346 | 1.0 | 2011.04

4.2.1 Main Menu

4.2.2 ALC Submenu

4.2.3 ALC -> SHUTGAIN Submenu

Function Selections Description

ALC Selects Submenu Accesses the Auto Level Control menu.

ENHANCE Selects Submenu Accesses the Picture Enhancement menu.

COLOR Selects Submenu Accesses the Color Control menu.

BLC ON, OFF, or selects submenu – Enables Back Light Compensation (BLC).

– Accesses the BLC submenu.

EXIT Exits this menu.

Function Selections Description

ALC LEVEL (-15 to +15) Adjusts the video output level.

SHUTGAIN Selects Submenu Accesses the Shutter and Gain control menu.

PEAK AVERAGE (-15 to +15) Adjusts the balance between peak and average

video control.

ALC SPEED ON, OFF, or selects

submenu

Adjusts the speed of the video level control loop.

EXIT Returns to the MAIN menu.

Function Selections Description

SHUTTER AES, FL, FIXED – AES (Auto Electronic Shutter): The camera

automatically sets the optimum shutter

speed.

– FL (Flickerless): Avoids interference from

light sources.

– FIXED: Allows the user to define the

shutter speed.

DEFSHUT 1/60 (1/50), 1/100, 1/120,

1/250, 1/500, 1/1000,

1/2000, 1/5000, 1/10K

The camera tries to maintain the selected

shutter speed as long as the light level of the

scene permits.

(Only available if SHUTTER is set to AES

mode.)

FIXSHUT 1/60 (1/50), 1/100, 1/120,

1/250, 1/500, 1/1000,

1/2000, 1/5000, 1/10K

Selects the shutter speed. (Only available if

SHUTTER is set to FIXED mode.)

SENSUP OFF or (2x to 10x) Selects the sensitivity factor the camera is set

to. (Only available if SHUTTER is set to AES

mode.)

GAIN AGC, FIXED – AGC mode: The camera automatically sets

the gain to the lowest possible value

needed to maintain a good picture.

– FIXED mode: The gain is set at a

predefined value.

MAXGAIN (0 to 26) Selects the maximum value the gain can have

during AGC operation.

FIXGAIN (0 to 26) Selects the gain setting. (Only available if GAIN

is set to FIXED mode.)

DAY/NIGHT3Selects submenu Accesses the Day/Night Control menu.

10 en | Advanced Setup AutoDome 100 Series Fixed Camera

F.01U.216.346 | 1.0 | 2011.04 User Manual Bosch Security Systems, Inc.

3. Only available in Day/Night version cameras, color versions show NightSense.

4.2.4 ALC -> SHUTGAIN -> DAY/NIGHT Submenu

NIGHTSENSE AUTO, OFF, FORCED – UTO mode: Camera automatically

switches to NIGHTSENSE in low light

conditions.

– OFF mode: NIGHTSENSE is turned off.

– FORCED mode: The camera is set to

NIGHTSENSE (black and white) mode.

EXIT Returns to the ALC menu.

Function Selections Description

NOTICE!

If SensUp is active, some noise or spots may appear in the picture. This behavior is normal.

SensUp may cause some motion blur on moving objects.

Depending on the camera GAIN setting, unrelated menu items are not active.

Function Selections Description

DAY/NIGHT AUTO, COLOR, MONO – AUTO: Switches the filter between COLOR

and MONO depending on the scene

illumination level.

– COLOR: Use for normal daylight conditions.

– MONO: Removes the IR filter, providing full IR

sensitivity.

SWITCH LEVEL (-15 to +15) Sets the video leveling threshold when the camera

switches to monochrome operation.

PRIORITY COLOR, MOTION in AUTO mode:

– COLOR: Displays a color image as long as the

light level permits.

– MOTION: Avoids motion blur as long as the

light level permits.

IR CONTRAST NORMAL, ENHANCED – NORMAL: Optimizes contrast in monochrome

applications with visible light illumination.

– ENHANCED: Optimizes contrast in

applications with high IR illumination levels.

MONO BURST ON, OFF – ON: The color burst remains active, even in

Monochrome mode.

– OFF: The color burst in the video signal is

switched OFF in Monochrome mode.

EXIT Returns to the SHUTGAIN menu.

NOTICE!

Depending on the camera’s DAY/NIGHT setting, unrelated menu items are not active.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de Bosch

Bosch

Bosch NDE-8503-R Manual de usuario

Bosch

Bosch NUC-52051-F0 Manual de usuario

Bosch

Bosch NCD-274-PM Manual de usuario

Bosch

Bosch AUTODOME IP starlight 5100i Manual de usuario

Bosch

Bosch VTC-206 Series Manual de usuario

Bosch

Bosch DINION 5000 IP Manual de usuario

Bosch

Bosch VCM8637/00T Manual de usuario

Bosch

Bosch AUTODOME IP starlight 5000i NDP?5512?Z30C Manual de usuario

Bosch

Bosch VG5 800 SERIES Manual de usuario

Bosch

Bosch VDC-250 Manual de usuario

Bosch

Bosch NDP-7512-Z30C Manual de usuario

Bosch

Bosch MIC IP dynamic 7000 HD Manual de usuario

Bosch

Bosch FLEXIDOME IP starlight 8000i Manual de usuario

Bosch

Bosch MIC Series 440 Manual de usuario

Bosch

Bosch MIC Series 400 Manual de usuario

Bosch

Bosch KBE-498V28-20 Manual de usuario

Bosch

Bosch AUTODOME IP 4000i NDP-4502-Z12 Manual de usuario

Bosch

Bosch FlexiDomeXF VDC-485V03-20 Manual de usuario

Bosch

Bosch KBE-335V28-20 Manual de usuario

Bosch

Bosch VDC-455V09-20S Manual de usuario

Bosch

Bosch NDN-921 Manual de usuario

Bosch

Bosch FLEXIDOME AN outdoor 4000 Manual de usuario

Bosch

Bosch FlexiDomeVF VDM-345V03-20 Manual de usuario

Bosch

Bosch FlexiDomeXF VDC-485V03-20 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
