Installation Instructions

Observation Camera

Manuale d installation

Caméra d Observation

Installationshandbuch

Beobachtungskamera

Installatiehandleiding

Observatie Camera

Manuale di installazione

Telecamera di Osservazione

Manual de Instalação

Câmara de Observação

Manual de instalación

Cámara de Observación

Installations manual

Observationskamera

Installationshandbok

Bevakningskamera

Asennusohje

Valvontakamera

Installasjons manual

Overvåkingskamera

Bosch Security Systems | 2004-06

8637 & 8638 | Installation Instructions

Installation Instructions

00697

Figure A

100697

200m

0-50m

100m

300m

1415

FIGURE A

Bosch Security Systems | 2004-06

8637 & 8638 | Installation Instructions

4-5

2-3

4-5

2-3

FIGURE B

Bosch Security Systems | 2004-06

8637 & 8638 | Installation Instructions

TABLE OF CONTENTS

ENGLISH ................................................................ 2

FRANÇAIS ............................................................. 6

DEUTSCH .............................................................. 11

ESPAGÑOL ............................................................ 16

NEDERLANDS ...................................................... 21

ITALIANO .............................................................. 25

PORTUGUÊS ......................................................... 30

DANSK .................................................................... 35

SVENSKA ............................................................... 40

SUOMI .................................................................... 44

NORSK .................................................................... 48

GREEK .................................................................... 52

TECHNICAL SPECIFICATION ........................ 57

Bosch Security Systems | 2004-06

| 1

8637 & 8638 | Installation Instructions

ELECTRO MAGNETIC COMPATIBILITY (EMC)

Installation Instructions

This equipment complies with European rules for EMC according to

EN55013, EN55020 and EN50082-1.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation.

The equipment conforms with the EMC directive and low-voltage

directive.

This device complies to FCC rules under test conditions that included

use of system cables and connectors between system components. If

you have any problems, contact your dealer.

WARNINGS

Any unauthorized modification to this equipment may cause

violation of the FCC rules resulting in the revocation of the

authorization to operate the equipment.

To prevent fire or shock hazard, do not expose this accessory to rain

or moisture. Do not attempt to disassemble the camera. In order to

prevent shock and fire hazard, do not remove screws or covers.

There are no user-serviceable parts inside.

WARNING:

The exclamation mark within a triangle is intended to alert

the user to the presence of important operating and

maintenance (servicing) instructions in the literature

accompanying the appliance.

Bosch Security Systems | 2004-06

EN | 2

8637 & 8638 | Installation Instructions

Observation Camera ENGLISHEN

INTRODUCTION

Your new CCD camera is developed for use with a special

observation system monitor. It features a sensitive microphone thus

registering both images and sound via the monitor, as well as input

contacts for connecting external alarm devices.

INSTALLATION

When the mains supply is connected, all camera lines are scanned.

The monitor uses this to register the camera configuration of the

system and to check whether any modifications have been made.

Sound

If required, the microphone incorporated in the camera, can be

switched off (fig. A-14).

If an intercom box is included in the camera line, the sound of

camera and intercom box will be reproduced by the monitor.

WARNING:

Disconnect the monitor from the mains supply before

disconnecting a camera or accessory.

Only operating the stand-by key is not sufficient.

The illustrations to which this manual refers, are shown on the front

and back jacket flap.

Bosch Security Systems | 2004-06

EN | 3

8637 & 8638 | Installation Instructions

Alarm inputs

The camera has a three-pole terminal block (fig. A-13) for connecting

alarm sensors, such as doorcontacts. For normally open (N.O.)

sensors, connect to contacts N.O.. For normally closed (N.C.) sensors,

connect to contacts N.C..

Position

First you need to determine where the camera is to be installed. The

best results are obtained when the camera looks a little downwards

and not into a bright source of light.

• Hold the camera in your hand at the spot where you want to

install it and check on the monitor whether the camera does

actually cover the required area from that spot.

• Fasten the mounting bracket to the ceiling, the wall, or another

even and firm surface by means of the supplied screws and plugs.

• Tighten the knob (fig. A-3) of the ball-and-socket joint.

• Fasten the camera to the bracket by screwing the mounting hole

in the back or bottom of the camera (fig. A-1) onto the threaded

end (fig. A-2).

• Loosen the knob of the ball-and-socket joint (fig. A-3) and, if

necessary, the screw (fig. A-4) on the mounting bracket and direct

the camera accurately at the object or area you want to have on

screen.

• The knob and screw can be tightened again when the camera is

in the required position.

Remark: The camera can also be mounted on any other camera

tripod standardly provided with a 1/4" 20 UNC thread.

• Check if the cable length compensation (fig. A-15) selector is set

to the correct length. The length set must be the same as the

length of the system cable (0-300m/900ft max.) connecting

monitor and camera.

Bosch Security Systems | 2004-06

EN | 4

8637 & 8638 | Installation Instructions

Focus adjustment

Adjust the focus ring (fig. B-1) of the camera lens to obtain an optimal

image sharpness.

Protective cover

For outdoor use a protective cover (fig. A-10) (optional) has to be

used to protect the camera from rain and snow.

System connection

Connect the system cable to the output of the camera (fig. A-12).

The lens

Focus range

The built-in lens provides an optimal image sharpness for objects

between 1 metre and infinity (depth of field).

Cable

A 4-wire system cable (see specifications) is supplied standardly.

For an optimum picture and sound quality a dual 'twisted-pair' cable

should be used.

CAUTION:

Do not touch the glass of the lens. This could damage the

delicate coating on its surface. If the lens has to be

cleaned, use a special lens cleaning tissue, available at any

good camera store.

Bosch Security Systems | 2004-06

EN | 5

8637 & 8638 | Installation Instructions

There is an extensive range of plugs and tools available in the hobby

and professional trade to extend the cable. Always pay attention that

the connection corresponds to figure B.

The maximum distance that can be bridged (without a cable

extension adapter) between the monitor and the cameras is 300

meters.

TIPS FOR MAINTENANCE

Cleaning

The outside of the camera can be cleaned with a moist fluff-free cloth

or a shammy leather cloth.

When cleaning the objective a special lens cleaning cloth should be

used. Do NOT use cleaning fluids based on alcohol, methylated

spirit, ammonia, etc..

Avoid direct contact with water.

CAUTION:

The plugs used for the observation system have the same

dimensions as standard telephone plugs. Never connect a

telephone to the camera or system monitor.
