Bosch EX14 Series Manual de usuario
EX14/14N
All Environment Camera
INSTALLATION INSTRUCTION
S
MAN-14-04
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep this instruction.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with manufacturer instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong is
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the power where they exit from the
apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in a way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
IMPORTANT
For best results, please read this Instruction Booklet prior to
installing the EX14 camera.
WARNING!
CSA Certified / UL Listed CLASS 2 power adaptors must be
used in order to comply with electrical safety standards.
Only qualified personnel shall install any
surveillance product.
Bosch Security Systems, Inc. will not be responsible for
injuries or damages resulting from the
improper installation or use of any product
sold by Bosch Security Systems, Inc their agents,
distributors or dealers.
EU Directives covered by this declaration:
72/9/EC Low Voltage Directives
89/336/EEC Electromagnetic Compatibility Directive
NOTE: This equipment has been tested and found to comply
with the limits for a digital device, pursuant to part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. As part of its’ normal operation this device can
generate radio frequency energy and if not installed and
used in accordance with the installation manual may cause
interference to radio communications. However, there is no
guarantee that interference will not occur on a particular
installation. If the device does cause interference to radio or
television reception the user is encouraged to try to correct
the interference by one or more of the following measures:
1) Fit Ferrite beads on all cable to and from the power
supply box, within the box walls.
2) Route the composite cable between the camera and the
power supply in steel conduit piping over the entire run of the
cable up to and including connection to a deep conduit base
fitted under the camera and a conduit fitting adaptor in the
wall of the PSU box.
3) Contact BOSCH Service Center for further advice.
INDEX – EX14/14N
Page
Description...................................................1
Unpacking....................................................2
Parts List......................................................2
Items Required for Installation.....................2
Initial Preparations.......................................3
Guidelines....................................................3
Section 1. Camera Mounting.......................4
Section 2. Camera I/O Connections............9
Section 3. Input Power Connections………10
Section 4. Camera/LED Adjustments........12
Section 5. Troubleshooting Guide.............15
Section 6. General Specifications..............18
1
DESCRIPTION
The EX14 All Environment Camera consists of a two-
piece injection molded watertight housing with a tough
polycarbonate viewing window. This compact camera
meets IP66 ratings for applications wherever
environmentally sealed CCD cameras are required. The
camera is especially suited for wash down applications
in food processing and industrial clean-room
installations.
The EX14 can be ordered in monochrome or color
versions, featuring varifocal and auto-iris IR-optimized
lenses. A rigid nylon mounting bracket is also included
with the camera.
A voltage regulator circuit allows for 12V dc or 24V ac
operation and a range in between. It also provides
protection from voltage surge, transient spikes, and
reverse voltage.
The EX14N comes with integrated Infra-Red illumination
to permit imaging in 0 Lux conditions
The EX14 is available in several models to meet
individual requirements or specific needs.
See the Light. Get the Picture.™
2
UNPACKING
Care should be taken when unpacking the shipped unit.
Check the parts list and confirm all items have been located.
Inspect the equipment thoroughly to ensure nothing was
damaged in transit.
Contact BOSCH Service Center if a problem is noted,
see the rear page of this booklet for contact numbers.
PARTS LIST (items supplied with unit)
•EX14 Camera or EX14N integrated infraRed
•Two Allen Keys
•One Mounting Bolt
•Nylon Mounting Bracket(supplied with camera)
•Installation Instructions booklet
ITEMS REQUIRED FOR INSTALLATION
(not supplied with unit)
•mounting hardware & tools
3
INITIAL PREPARATIONS
•The camera’s voltage regulator board
(VRB) accepts an input voltage of either
12Vdc or 24Vac, and a range in-between,
from a regulated power supply.
•The VRB automatically switches between
ac or dc inputs, therefore no internal wiring
changes are necessary to accommodate
these input voltages.
•Determine the optimum location for the
camera.
Section 1: Camera Mounting
•All cameras have been tested prior to
shipment.
GUIDELINES
The installation of the EX14 Camera is shown in
Sections 1 to 4 listed below.
It is important that these steps are followed in
sequence:
1. Camera Mounting
2. Camera I/O Connections
3. Input Power Connections
4. Camera/LED Array Adjustments
4
1. CAMERA MOUNTING
Caution: Install the mounting bracket with the
appropriate screws or drywall anchors to suit the
mounting surface. Select a suitable location that is
protected from accidental damage or tampering, and
environmental conditions that could exceed the
camera’s general specifications.
See page 18.
Caution: Ensure the selected location is protected from
falling objects, accidental contact with moving objects,
and unintentional interference from personnel. Follow
all applicable building codes.
The following installation guidelines
must be followed:
•Locate the camera such that it cannot be easily
interfered with, either intentionally or accidentally.
•Select a mounting surface capable of supporting
the combined weight of the camera and its
mounting hardware under all expected conditions of
vibration and temperature.
•Secure all cabling.
