Bosch VJD-8000 Manual de usuario

IP Matrix 9.60 for KBD‑UXF

VJD‑8000 | VJD‑7513

en Operation manual

IP Matrix 9.60 for KBD-UXF Table of contents | en 3

Bosch Security Systems B.V. Operation manual 2019-12 | V1 | DOC

Table of contents

1Introduction 4

1.1 About the manual 4

1.2 Conventions in this manual 4

1.3 Additional documentation 4

2Requirements 5

3Restrictions 6

4Operation 7

4.1 Keyboard layout 7

4.2 Key description 8

4.3 Keyboard operations 11

4.3.1 Selecting a camera 11

4.3.2 Selecting a monitor 11

4.3.3 Controlling digital speed factor 11

4.3.4 Controlling PTZ cameras 11

4.3.5 Locking/unlocking the keyboard 11

5Keyboard print template 12

6Troubleshooting 13

4en | Introduction IP Matrix 9.60 for KBD-UXF

2019-12 | V1 | DOC Operation manual Bosch Security Systems B.V.

1 Introduction

1.1 About the manual

This manual describes how to use the keyboard with the IPMatrix application.

1.2 Conventions in this manual

The following symbols and notations are used to draw attention to special situations:

Notice!

This symbol indicates special features and provides tips and information for easier, more

convenient use of the software.

Terms that you can find in the program, such as menu options, commands or text in the user

interface, are written in bold.

1.3 Additional documentation

Notice!

Read and follow the instructions in the hardware documentation

While setting up the hardware for IPMatrix, read and follow the instructions of the hardware

documentation. The documentation contains important safety messages. It is mandatory to

read and understand the safety messages prior to installation of the hardware.

More information

Find more information, software downloads, and documentation at:

www.boschsecurity.com and the respective product page.

IP Matrix 9.60 for KBD-UXF Requirements | en 5

Bosch Security Systems B.V. Operation manual 2019-12 | V1 | DOC

2 Requirements

A prerequisite for using the keyboard is that the required hardware for an IPMatrix system is

available and configured appropriately.

Requirements for installed software

The Configuration Manager 7.0 program or later is required.

Requirements for operational purpose

Make sure the following requirements are fulfilled:

– 1 to 4ready-to-use Bosch VIDEOJET decoder with firmware 9.60 or later connected to a

surveillance network (fully installed and ready for operation)

– 1 to 4KBD-UXF or KBD-Digital keyboards (fully installed and ready for operation)

– 1 to 8displays with appropriate interface connections or adapters

Note: Up to 2displays per decoder can be connected.

– Fixed or moving cameras connected to the surveillance network

– A PC with Bosch Configuration Manager program installed and connected to the

surveillance network (only for configuration purposes)

Notice!

Prior to operation, the IPMatrix application must be configured using the Configuration

Manager program.

IPMatrix configuration

The IPMatrix application can be configured using the Configuration Manager 7.0 program or

later.

For detailed configuration steps, refer to the IPMatrix configuration manual available on the

online product catalog.

6en | Restrictions IP Matrix 9.60 for KBD-UXF

2019-12 | V1 | DOC Operation manual Bosch Security Systems B.V.

3 Restrictions

Observe the following restrictions when using a IPMatrix system:

– The decoder dynamically adapts its performance to high loads by skipping frames, which

can cause juddering in the video stream.

– Playback is only possible from local recordings, not from recordings managed by VRM.

– A long i-frame distance leads to less exact navigation in playback mode and lower

performance in playback backwards mode.

IP Matrix 9.60 for KBD-UXF Operation | en 7

Bosch Security Systems B.V. Operation manual 2019-12 | V1 | DOC

4 Operation

After configuring the IPMatrix application using a PC with the Configuration Manager

program, the IPMatrix application operates as a stand-alone CCTV surveillance system. All

operations are carried out using the attached keyboard.

Notice!

Refer to the instruction manual delivered with your keyboard. The manual is also available on

the online product catalog.

4.1 Keyboard layout

The following graphic illustrates the different groups of keys on the keyboard, shown in the

right-hand version.

1 2

4 56

1 Numbered function keys and audio. 2 Rotatable knob

Use to control the zoom function of a

device or the built-in digital zoom

factor.

3 Joystick

Use to pan or tilt a PTZ device.

Use to move the field of view in a

digitally zoomed viewing pane.

4 Client control keys

These keys are shortcuts to certain

client functions.

5 Playback controls

In playback mode: Use to control the

playback speed of recorded tracks.

6 Number keys

Use to select favorite views, sequences

or single devices.

8en | Operation IP Matrix 9.60 for KBD-UXF

2019-12 | V1 | DOC Operation manual Bosch Security Systems B.V.

7 Shuttle ring

In Live mode: Use to select a certain

monitor in a multi-monitor view.

In playback mode: Use to increase or

decrease the playback speed factor.

8 Jog dial

Use to scroll through monitors.

4.2 Key description

The following list shows the icons on the keyboard and their respective function.

Displays monitor numbers and decoder IP addresses

4Press the key to display the monitor numbers and decoder IP addresses as overlay on the

monitors.

Displays camera numbers and camera IP addresses

4Press this key to display the camera numbers and camera IP addresses as overlay on the

monitors.

Calls-up favorites. Maximum 9favorites are available.

4Press the key, enter the number using the number keys, then click OK.

Note: The layouts and camera connections on all displays are re-established.

Saves up to 9favorites.

4Press the key, enter the number using the number keys, then click OK.

Note: The layouts and camera connections on all displays are saved.

Turns audio on/off

4Press the key to turn audio on/off. This applies only to the monitor in the top left of the

screen.

Note: Blinking indicates that the function is enabled.

Starts/stops recording.

Not supported in firmware 9.60.

Switches the keyboard to left-hand use and back.

The key assignment is rotated by 180 degrees.

4Press the key, then click OK.

Note: You must also rotate the printed keyboard inlay with the key labeling by 180 degrees.

IP Matrix 9.60 for KBD-UXF Operation | en 9

Bosch Security Systems B.V. Operation manual 2019-12 | V1 | DOC

Switches between live mode and playback mode.

Blinking indicates that the function is enabled.

4Press the key to switch.

Note: Only supported by firmware9.60 and later. Playback permission must be available.

Loads a camera sequence

4Press the key, enter a valid sequence number (1 to 32), then click OK.

Note: Blinking indicates that the input of a number is required.

Switches to previous layout with less monitors

4Press the key to decrease the number of monitors on the current display.

Note: This key provides a round-trip function. The last layout starts again, if the first layout is

reached.

Switches to next layout with more monitors

4Press the key to increase the number of monitors on the current display.

Note: This key provides a round-trip function. The first layout starts again, if the last layout is

reached.

Turns full-screen of currently selected monitor on/off

4Press the key to turn full-screen on or off.

Turns full-screen with picture-in-picture on/off

4Press the key to turn full-screen with picture-in-picture on or off.

1 …. 0 Number keys

4Use to select favorite views, sequences or single devices.

ESC Cancels a number entry.

4Press the key to cancel the entering of a number.

OK Confirms a number entry.

4Press the key to confirm.

Enables/disables focus control

4Press the key, then turn the joystick control knob to change the focus control.

Enables/disables iris control

10 en | Operation IP Matrix 9.60 for KBD-UXF

2019-12 | V1 | DOC Operation manual Bosch Security Systems B.V.

4Press the key, then turn the joystick control knob to change the iris control.

Displays the next camera

4Press the key to display the next camera on the selected monitor.

Displays the previous camera

4Press the key to display the previous camera on the selected monitor.

Selects a monitor.

4Press the key, enter the monitor number using the number keys, then click OK.

Locks/unlocks the keyboard

4Press the key to lock or unlock the keyboard.

Note: Key is highlighted if state is locked.

Plays recordings fast backwards (stepwise)

4Press the key to play recordings fast backward (stepwise).

Note: Available in playback mode.

Plays recordings backwards

4Press the key to play recordings backwards with normal speed.

Note: Available in playback mode.

Freezes video on monitors on/off (in live mode) or pauses playback (in playback mode)

In live mode:

4Press the key to freeze/unfreeze the video on all monitors.

Note: Selecting another layout, camera or monitor also unfreezes the video.

In playback mode:

4Press the key to pause the playback on the selected monitor.

Starts playback

4Press the key to start the playback with normal speed.

Note: Available in playback mode.

Fast forward (stepwise)

4Press the key to move stepwise fast forward in recordings.

Note: Available in playback mode.
