Systems | ARD-AYCF64 - RFID with keypad

The ARD-AYCF64 offers programmable PIN and proximity

transmission formats. The red backlit keypad is clearly

visible day or night. With the rugged ultraviolet-resistant

housing and the waterproofed enclosure the reader is

suitable for outdoor installation.

Certifications and Approvals

Europe: CE

Installation/Configuration Notes

Comes with a mounting and drilling label, security screw,

and tool set to prevent unauthorized opening.

Parts Included

•60 cm shielded interface cable

•User manual

Technical Specifications

Electrical Characteristics

Operating voltage range 5 – 16 Vdc

Maximum input current Standby: 105 mA @ 12 Vdc

Read: 140 mA @ 16 Vdc

Proximity card reader Max. read range*: 80 mm

Modulation: ASK @ 125 kHz

Compatible cards: all 26-Bit EM cards

Tamper output Open collector, active low,

max. sink current 32 mA

Operational Characteristics

Keypad 3 x 4 keys for local programming and 4

to 8 digit PIN codes entry

Design Epoxy potted, fully sealed in a rugged

polycarbonate enclosure. Red illumi-

nated rubber keys. Suitable for harsh

environments.

Audi/Visual Two tri-color LED indicators, built-in

buzzer

LED control Dry contact, N.O.

Facility code Programmable

Card read format Selectable Wiegand 26 Bits or

Clock&Data

PIN code formats 8 selectable formats, from 1 to 8 digit

length PIN codes

ARD-AYCF64 - RFID with keypad

▶Smooth and attractive design with indoor and

outdoor operation

▶Large red backlit keypad

▶Supports up to 8 digit PINs

▶Can read RFID cards and tags with 125 kHz (EM)

technology

▶Two tri-colored LEDs and an integrated sounder for

programming and operation

www.boschsecurity.com

2 | ARD-AYCF64 - RFID with keypad

Electrical Characteristics

Environmental Characteristics

Operating temperature range -30 °C to 65 °C

Operating humidity 0 to 95% (non condensing)

Environment class IP 65

Physical Characteristics

Dimensions (H x W x D) 120 x 76 x 21 mm

Weight 215 g

* Range also depends on electrical environment and

proximity to metal.

Ordering Information

ARD-AYCF64 - RFID with keypad

Outdoor backlit keypad reader for 125 kHz

EM technology.

ARD-AYCF64

Americas:

Bosch Security Systems, Inc.

130 Perinton Parkway

Fairport, New York, 14450, USA

Phone: +1 800 289 0096

Fax: +1 585 223 9180

[email protected]

www.boschsecurity.us

Europe, Middle East, Africa:

Bosch Security Systems B.V.

P.O. Box 80002

5600 JB Eindhoven, The Netherlands

Phone: + 31 40 2577 284

Fax: +31 40 2577 330

[email protected]

www.boschsecurity.com

Asia-Pacific:

Robert Bosch (SEA) Pte Ltd, Security Systems

11 Bishan Street 21

Singapore 573943

Phone: +65 6258 5511

Fax: +65 6571 2698

[email protected]

www.boschsecurity.com

Represented by

T6771164427 | Cur: en-US, V3, 2 Dec 2010
