Bosch NWC-0455-20P Manual de usuario

Dinion IP

NWC-455-10P | NWC-455-20P

en Operating Instructions

Dinion IP | en 3

Bosch Security Systems Operating Instructions V 2.5 | 2007.6

Table of Contents

1 Introduction 15

1.1 Type number overview 16

1.2 Unpacking 16

1.3 System requirements 17

1.4 Overview of functions 17

1.4.1 Wide dynamic range 18

1.4.2 Power-over-Ethernet 18

1.4.3 Receiver 18

1.4.4 Video encoding 18

1.4.5 Tri Streaming 18

1.4.6 Recording 18

1.4.7 Multicast 19

1.4.8 Encryption 19

1.4.9 Configuration 19

1.4.10 Tampering recognition and motion detectors 19

1.4.11 Snapshots 19

1.4.12 Backup 19

1.4.13 Intelligent Video Motion Detection 20

2 Connections 21

2.1 Power 21

2.2 Network (and power) 22

2.3 Video service monitor 22

2.4 Alarm connector 23

3Mounting 24

3.1 Lens mounting 24

3.2 Mounting the camera 25

4 Quick set-up 26

4.1 Back focus adjustment 26

4.2 Accessing and navigating quick set-up menu 27

4.2.1 How to use the navigation keys 27

4en | Dinion IP

V 2.5 | 2007.6 Operating Instructions Bosch Security Systems

4.2.2 Install menu 28

4.3 Adjustment procedure DC-iris Lens 28

4.4 Adjustment procedure Manual-iris Lens 29

4.5 Adjustment procedure Video-iris Lens 29

4.6 Install IP address submenu 29

4.7 Defaults 30

5 Network connection 31

5.1 System requirements 31

5.2 Establishing the connection 31

5.3 Secured network 33

6 Operation via the browser 34

6.1 Livepage 34

6.1.1 Processor load 34

6.1.2 Image selection 35

6.1.3 Digital I/O 35

6.1.4 System log / Event log 35

6.1.5 Saving snapshots 35

6.1.6 Recording video sequences 36

6.1.7 Running recording program 37

6.2 Recordings page 37

6.2.1 Selecting recordings 38

6.2.2 Controlling playback 38

7 Configuration via the browser 41

7.1 Settings 41

7.2 General Settings 43

7.2.1 Camera identification 43

7.2.2 Password protection 44

7.2.3 Language selection 45

7.2.4 Date and time 45

7.2.5 Time server 46

7.3 Display Settings 47

7.3.1 Display stamping 47

7.4 Encoder Settings 48

Dinion IP | en 5

Bosch Security Systems Operating Instructions V 2.5 | 2007.6

7.4.1 Selecting an encoder profile 48

7.4.2 Changing profiles 50

7.4.3 JPEG posting 53

7.5 Camera settings 55

7.5.1 ALC 55

7.5.2 Enhance 56

7.5.3 Color 57

7.5.4 Installer options 58

7.6 Recording 58

7.6.1 Type 59

7.6.2 Storage information 59

7.7 iSCSI settings 60

7.7.1 iSCSI IP address 60

7.7.2 iSCSI LUN map 61

7.7.3 Target IP address 61

7.7.4 Target node 61

7.7.5 Target LUN 61

7.7.6 Target password 61

7.7.7 Initiator name 62

7.7.8 Initiator extension 62

7.7.9 Decoupling the drive used 62

7.7.10 Storage information 62

7.8 Partitioning 63

7.8.1 Creating a partition 63

7.8.2 Partition status 65

7.8.3 Editing a partition 65

7.8.4 Deleting partitions 68

7.9 Recording profile 68

7.10 Recording scheduler 71

7.10.1 Activating recording 72

7.10.2 Recording status 73

7.11 Alarm Settings 73

7.11.1 Alarm in 73

7.11.2 Alarm connections 74

7.12 VCA 76

7.12.1 Analysis 76

7.12.2 Analysis type 77

6en | Dinion IP

V 2.5 | 2007.6 Operating Instructions Bosch Security Systems

7.12.3 Motion detector 77

7.12.4 Sensitivity 78

7.12.5 Tamper detection 79

7.13 Alarm e-mail 81

7.13.1 Send alarm e-mail 81

7.13.2 Mail server IP address 81

7.13.3 Layout 82

7.13.4 Destination address 82

7.13.5 Sender name 82

7.13.6 Send e-mail for testing 82

7.14 Relay Settings 82

7.14.1 Alarm out 83

7.15 Service Settings 84

7.15.1 Network 84

7.15.2 Multicasting 87

7.15.3 Encryption 89

7.15.4 Version information 90

7.15.5 Livepage configuration 91

7.15.6 Licenses 93

7.15.7 Maintenance 94

7.16 Function test 96

8 Connections between video servers 97

8.0.1 Installation 97

8.0.2 Establishing the connection 97

8.0.3 Connect on alarm 97

8.0.4 Connecting with a Web browser 98

8.0.5 Closing the connection 98

9 Operation with decoder software 99

10 Maintenance 100

10.1 Testing the network connection 100

10.2 Repairs 100

10.2.1 Transfer and disposal 100

Dinion IP | en 7

Bosch Security Systems Operating Instructions V 2.5 | 2007.6

11 Troubleshooting 101

12 Specifications 103

12.1 Dimensions (mm/inch) 105

12.2 Accessories 106

12.2.1 Recommended lenses 106

12.2.2 Power transformers 106

13 Glossary 107

8en | Dinion IP

V 2.5 | 2007.6 Operating Instructions Bosch Security Systems

Important safety instructions

Read, follow, and retain all of the following safety instructions.

Heed all warnings on the unit and in the operating instructions

before operating the unit.

1. Cleaning - Unplug the unit from the outlet before cleaning.

Follow any instructions provided with the unit. Generally,

using a dry cloth for cleaning is sufficient, but a moist fluff-

free cloth or leather shammy may also be used. Do not use

liquid cleaners or aerosol cleaners.

2. Heat Sources - Do not install the unit near any heat sources

such as radiators, heaters, stoves, or other equipment

(including amplifiers) that produce heat.

3. Water - Do not use this unit near water, for example near a

bathtub, washbowl, sink, laundry basket, in a damp or wet

basement, near a swimming pool, in an unprotected out-

door installation, or in any area classified as a wet location.

To reduce the risk of fire or electrical shock, do not expose

this unit to rain or moisture.

4. Object and liquid entry - Never push objects of any kind

into this unit through openings as they may touch danger-

ous voltage points or short-out parts that could result in a

fire or electrical shock. Never spill liquid of any kind on the

unit. Do not place objects filled with liquids, such as vases

or cups, on the unit.

5. Controls adjustment - Adjust only those controls specified

in the operating instructions. Improper adjustment of

other controls may cause damage to the unit. Use of con-

trols or adjustments, or performance of procedures other

than those specified, may result in hazardous radiation

exposure.

6. Overloading - Do not overload outlets and extension cords.

This can cause fire or electrical shock.

7. Power cord and plug protection - Protect the plug and

power cord from foot traffic, being pinched by items

placed upon or against them at electrical outlets, and its

exit from the unit. For units intended to operate with

Dinion IP | en 9

Bosch Security Systems Operating Instructions V 2.5 | 2007.6

230 VAC, 50 Hz, the input and output power cord must

comply with the latest versions of IEC Publication 227 or

IEC Publication 245. For outdoor use the power cord must

comply to NEC400-4 (CEC Rule 4-010) and marked with

OUTDOOR, W, or W-A. .

8. Power sources - Operate the unit only from the type of

power source indicated on the label. Before proceeding,

be sure to disconnect the power from the cable to be

installed into the unit.

– For battery powered units, refer to the operating

instructions.

– For external power supplied units, use only the rec-

ommended or approved power supplies.

– For limited power source units, this power source

must comply with EN60950. Substitutions may dam-

age the unit or cause fire or shock.

– For 24 VAC units, voltage applied to the unit's power

input should not exceed 28 VAC. User-supplied wiring

must comply with local electrical codes (Class 2

power levels). Do not ground the supply at the termi-

nals or at the unit's power supply terminals.

– If unsure of the type of power supply to use, contact

your dealer or local power company.

9. Servicing - Do not attempt to service this unit yourself.

Opening or removing covers may expose you to dangerous

voltage or other hazards. Refer all servicing to qualified

service personnel.

10. Damage requiring service - Unplug the unit from the main

AC power source and refer servicing to qualified service

personnel when any damage to the equipment has

occurred, such as:

– the power supply cord or plug is damaged;

– exposure to moisture, water, and/or inclement

weather (rain, snow, etc.);

– liquid has been spilled in or on the equipment;

– an object has fallen into the unit;

– unit has been dropped or the unit cabinet is damaged;

10 en | Dinion IP

V 2.5 | 2007.6 Operating Instructions Bosch Security Systems

– unit exhibits a distinct change in performance;

– unit does not operate normally when the user cor-

rectly follows the operating instructions.

11. Replacement parts - Be sure the service technician uses

replacement parts specified by the manufacturer, or that

have the same characteristics as the original parts. Unau-

thorized substitutions may cause fire, electrical shock, or

other hazards.

12. Safety check - Safety checks should be performed upon

completion of service or repairs to the unit to ensure

proper operating condition.

13. Installation - Install in accordance with the manufacturer's

instructions and in accordance with applicable local codes.

14. Attachments, changes, or modifications - Only use attach-

ments/accessories specified by the manufacturer. Any

change or modification of the equipment, not expressly

approved by Bosch, could void the warrantee or, in the

case of an authorization agreement, authority to operate

the equipment.
