Bosch D7044 Manual de usuario

D7044

Installation Instructions

EN Multiplex Single Input

Module

D7044 | Installation Instructions | Notices

Notices

These instructions cover the installation of the D7044

Multiplex Single Input Module in a fire system,

supervised by a D7024 or DS9400M Fire Alarm

Control Panel (FACP) with firmware revision 2.0 or

greater and a D7039 or DS9431 Multiplex Expansion

Module.

Install, test, and maintain the D7044 according to these

instructions, NFPA 72, Local Codes, and the Authority

Having Jurisdiction (AHJ).

Follow the procedures in these instructions

to avoid personal injury and damage to the

equipment. Failure to follow the procedures

can result in the D7044 not operating

properly. Bosch is not responsible for

improperly installed, tested, or maintained

devices.

1.0

Description

The D7044 (Figure 1) is a general purpose device that

connects a contact device to the FACP multiplex bus

with a supervised input loop.

Figure 1: D7044 Features

Test the FACP according to NFPA 72.

0 1 A

1 B2

9 0 1

6 5 4

9 0 1

6 5 4

Status LED

Zone input terminals

Mux bus loop terminals

Rotary address switches

All operating power for the D7044 is drawn from the

FACP.

Rotary switches provide convenient address setting.

An on-board Status LED, visible through the faceplate,

indicates normal operation and communication with the

control panel. The LED flash rates are:

•

Fast: Approximately 4 sec indicating an alarm

condition.

Medium: Approximately 8 sec indicating normal

operation.

Slow: Approximately 16 sec indicating a trouble

condition.

The D7044 can be mounted in a standard double-gang

or a 4 in. x 4 in. electrical box.

Bosch | 10/04 | 48337D

D7044 | Installation Instructions | 2.0

Setting the Address

2.0

Setting the Address

Figure 3: Field Wiring Connections

Set the D7044 address using a flat-bladed screwdriver to

position each rotary switch located on the front of the

module (Figure 2). Note that the switches click when

turned.

Figure 2: D7044 Address Setting

1 B2

6 5 4

1 - Hundreds2 - Tens3 - Ones

A = D7024 FACP, B = DS9400M FACP

For example:

0 hundreds, 9 tens, 5 ones = Address 095 on the

D7024 FACP

0 1 A

1B2

The valid D7044 address range is 9 to 255. Refer to the

D7024 Operation and Installation Guide (P/N: 31499) or

the DS9400M Reference Guide (P/N: 44578) for

additional address limitations.

The A address range works on the D7039

Multiplex Expansion Module with the D7024

FACP. The B address range works on the

DS9431 Multiplex Expansion Module with

the DS9400M FACP.

1 - 2.21 kend-of-line (EOL) resistor UL Listed

(P/N: 25899)

2 - Zone in (+)

3 - Zone in (-)

Note: The maximum zone wire resistance = 100 

Figure 4: Loop and Panel Wiring Connections

Figure 2 shows the A address range set at 095, allowing

the D7039 to work with the D7024 FACP.

3.0

Wiring

Ensure all power is removed before making

electrical connections. Failure to do so can

result in personal injury and damage to the

equipment.

9 0 1

6 5 4

Connections are made using the terminals on either side

of the D7044 (Items 2 and 3 in Figure 1 on page 2). All

terminals can accommodate up to and including

12 AWG (2.3 mm) wire. Follow the wiring guidelines as

specified by NFPA-70 and the local AHJ.

All wiring is power limited and supervised. Refer to

Figures 3 and 4 for the two types of wiring connections.

Use normally-open (NO) contacts for

Underwriters Laboratories, Inc. (UL) Listed

fire installations.

Mux bus loop (+)

Mux bus loop (-)

To next device

From previous device, the D7039, or the DS9431

Bosch | 10/04 | 48337D

D7044 | Installation Instructions | 4.0

Installation

4.0

Installation

Complete all wiring before mounting the D7044 and faceplate.

Wire the D7044 according to Figures 3 and 4 on page 3.

2. Mount the D7044 on a standard double-gang box (Figure 5) or 4 in. x 4 in. electrical box (Figure 6).

Figure 5: Mounting the D7044 on a Double-Gang Box

0 1 A

2 1 B

9 0 1

1 - Supplied mounting screws (4)

2 - D7044 Module

3 - Double-gang box

Figure 6: Mounting the D7044 on an Electrical Box

0 1 A

2 1 B

9 0 1

6 54

0 19

6 5 4

1 - Supplied mounting screws (2)

2 - D7044 Module

3 - 4 in. x 4 in. electrical box

Bosch | 10/04 | 48337D

D7044 | Installation Instructions | 4.0

Installation

3. Secure the faceplate to the front of the D7044 (Figure 7).

Figure 7: Mounting the Faceplate

D7044

0 1 A

2 1 B

9 0 1

6 5 4

0 19

6 5 4

1 - Supplied mounting screws (2)

2 - Faceplate

3 - D7044 Module on electrical box

Bosch | 10/04 | 48337D

D7044 | Installation Instructions | 5.0

Specifications

5.0

Specifications

Single input

D7024 FACP with ROM version 2.0 or greater and a D7039 Multiplex Expansion Module

installed. Refer to the D7024 Operation and Installation Guide (P/N: 31499) or the DS9400M

Reference Guide (P/N: 44578) for specific programming information. Refer to the D7039

Installation Instructions (P/N: 38685) or the DS9431 Installation Instructions (P/N: 41381) for

multiplex wiring information.

Alarm: 550 

Standby: 550 

Nominal: 12 V

+32°F to +120°F (0°C to +49°C)

Maximum of 93%, non-condensing

UL 864

California State Fire Marshall (CSFM)

Table 1:

Control Panel

Programming Type

Control Panel

Requirements

Multiplex Bus Average

Current Draw

Operating Temperature

Relative Humidity

Listings and Approvals

Bosch | 10/04 | 48337D

D7044 | Installation Instructions | Notes

Notes

Bosch | 10/04 | 48337D

Bosch

130 Perinton Parkway

Fairport, NY 14450-9199 USA

Customer Service: (800) 289-0096

Technical Support: (888) 886-6189

48337D
