Bosch GCY 30-4 Professional Instrucciones de montaje

IMPORTANT:

Read Before Using

IMPORTANT :

Lire avant usage

IMPORTANTE:

Leer antes de usar

For English Version

See page 10 Version française

Voir page XX Versión en español

Ver la página XX

Operating/Safety Instructions

Consignes de sécurité/d’utilisation

Instrucciones de funcionamiento y seguridad

1-877-BOSCH99 (1-877-267-2499)

www.boschtools.com

GCY30-4

Call Toll Free for

Consumer Information

and Service Locations.

Pour obtenir des informa-

tions et les adresses de

nos centres de service

après-vente, appelez ce

numéro gratuit.

Llame gratis para obtener

información para el con-

sumidor y ubicaciones de

servicio

DRAFT

Safety Symbols

The deﬁnitions below describe the level of severity for

each signal word. Please read the manual and pay atten-

tion to these symbols.

This is the safety alert symbol. It

is used to alert you to potential

personal injury hazards. Obey all

safety messages that follow this

symbol to avoid possible injury

or death.

DANGER indicates a hazardous

situation which, if not avoided,

will result in death or serious

injury.

WARNING indicates a hazardous

situation which, if not avoided,

could result in death or serious

injury.

CAUTION, used with the safety

alert symbol, indicates a haz-

ardous situation which, if not

avoided, will result in minor or

moderate injury.

All instructions must be read and

observed in order to enable work

with the GCY30-4 to be carried out safely. Store these

instructions in a safe place and provide them when trans-

ferring the GCY30-4 or any power tool using it to a third

party.

Only use batteries listed in this

operating manual. Do not use any

other button cells or other forms of electrical power supply.

Ensure that battery replacement

is carried out properly. There is a

risk of explosion.

TheconnectivitymoduleGCY30-4

is equipped with a radio interface.

Local operating restrictions, e.g. in airplanes or hospi-

tals, are to be observed.

General Safety Rules

Read all safety warnings and all

instructions. Failure to follow the

warnings and instructions may result in electric shock, ﬁre

and/or serious injury.

SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE

REFERENCE

FCC Caution

The manufacturer is not responsible for radio interference

caused by unauthorized modiﬁcations to this equipment.

Such modiﬁcations could void the user’s authority to oper-

ate the equipment.

This device complies with Part 15 of the FCC Rules. Opera-

tion is subject to the following two conditions:

1) This device may not cause harmful interference, and

2) This device must accept any interference received, in-

cluding interference that may cause undesired operation.

NOTE! This equipment has been tested and found to com-

ply with the limits for a Class B digital devices, pursuant to

Part 15 of the FCC rules. These limits are designed to pro-

vide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

THINK SAFETY

SAFETY IS A COMBINATION OF OPERATOR COMMON

SENSE AND ALERTNESS AT ALL TIMES WHEN THE PRES-

SURE WASHER IS BEING USED.

SAVE THESE INSTRUCTIONS

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular in-

stallation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment oﬀ and on, the user is encouraged to

try to correct the interference by one or more of the following

measures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandre-

ceiver.

• Connecttheequipmentintoanoutletonacircuitdierent

from that to which the receiver is connected.

• Consultthedealeroranexperiencedradio/TVtechnician

for help.

“Exposure to Radio Frequency (RF) Signals: The wireless

device is a radio transmitter and receiver. It is designed and

manufactured not to exceed the emission limit for exposure

to radio frequency (RF) energy set by the Ministry of Health

(Canada), Safety Code 6. These limits are part of compre-

hensive guidelines and established permitted levels of RF

energy for the general population.

SAVE THESE INSTRUCTIONS

These guidelines are based on the safety standards previ-

ously set by international standard bodies. These standards

include a substantial safety margin designed to assure the

safety of all persons, regardless of age and health.

This device and its antenna must not be co-located or oper-

ating in conjunction with any other antenna or transmitter.

Industry Canada

This device complies with Industry Canada licence-exempt

RSS standard(s). Operation is subject to the following two

conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including inter-

ference that may cause undesired operation of the device.

SAVE THESE INSTRUCTIONS

The Bluetooth® word mark and logos are registered trade-

marks owned by Bluetooth SIG, Inc. and any use of such

marks by Robert Bosch Tool Corporation is under license.

Product Features

The numbering of the product fea-

tures refers to the illustrations on

the graphics pages.

1Button cell battery

2Connectivity module GCY30-4

3Placeholder *

4Cover of connectivity module*

* Part of the power tool

Intended Use

The connectivity module GCY30-4

enables power tool customization

and power tool status check as

well as transfer of data and settings

based on Bluetooth® wireless tech-

nology.

NOTE: The data transfer must be

approved by the user.

You will ﬁnd information about available connectivity func-

tionalities in the Bosch Toolbox application (app) or in the

manual of the power tool used.

Getting to Know your GCY30-4

Connectivity Module

Technical Data

Model GCY30-4

Operating temperature 14 °F…+ 104 °F

Storage temperature -4 °F…+ 158 °F

Dimensions 0.275” x 1.18” x 1.18”

Weight according to

EPTA-Procedure 01:2014 0.352 oz

Data transmission

Bluetooth® Bluetooth® 4.0 (Low

Energy)A

Signal Interval 8 s

Signal Range Maximum 98 ft.B

Power Supply

Battery Buttoncell(3Vlithium

battery, CR2032)

Battery service life, approx. 36 months

System Requirements

Mobile terminal device

(tablet, smartphone) Android 4.3 (and above)

iOS 5 (and above)

AThe mobile terminal devices must be compatible with Blue-

tooth® Low Energy devices (version 4.1) and support the Ge-

neric Access Proﬁle (GAP).

BThe signal range may vary greatly depending on external condi-

tions. The Bluetooth® range may be signiﬁcantly weaker inside

closed rooms and through metallic barriers (e.g. walls, shelv-

ing units, cases, etc.).

Installing and setting up the app

(see ﬁgures A1 – A2)

Before you can use the GCY30-4, you need to install the

Bosch Toolbox app.

– Download the BoschToolbox app via the appropriate app

store (Apple App Store, Google Play Store).

Note: A user account is required in the respective app store.

– Then select in the app the subitem MyTools.

– The screen of your mobile terminal device displays all

further steps to connect the power tool to the terminal

device.

Bosch oﬀers a special application (app) for managing the in-

serted GCY30-4 module and determining its location.

– Open the website www.bosch-trackmytools.com and

After registration is complete, you will receive your access

information.

– Download the www.bosch-trackmytools.com app/web-

based application via the appropriate app store (Apple

App Store, Google Play Store) and register using your ac-

cess information.

You can now create and manage your inventory using the

app/web-based application.

Note: A user account is required in the respective app store.

Note: First, fully complete the tutorial for the app. This will

provide you with a better overview of the connection process

and the use of the connectivity functionalities.

Data Transmission via Bluetooth®

The transmission interval of the GCY30-4 is 8 seconds. De-

pending on ambient conditions, several transmission inter-

vals may be required before the GCY30-4 is detected. If the

GCY30-4 is not detected, check the following:

– Is the distance to the mobile terminal device too great?

▷ Reduce the distance between the mobile terminal de-

vice and the GCY30-4.

– Is the battery too low or drained?

▷ Change the battery.
