Bontrager GoTime Manual de usuario

GoTime

Basic Instructions

About this manual

Please read this manual carefully. If you do not understand the

information, or you have a question that this manual does not cover,

consult your Bontrager dealer or download the complete instruction

manual from www.bontrager.com/support/owners_manuals.

Contents

Safety.................................................................2

Getting started

Process overview..............................................3

Tools required ...................................................3

Parts list............................................................3

Installing your GoTime

To install the speed sensor & wheel magnet...... 4

To insert the battery .......................................... 5

To set-up your preferences ...............................6

To attach the computer................................... 10

Using your GoTime

Viewing the screens........................................12

Starting your ride ............................................12

Changing the set-up

To re-set the tire size....................................... 14

To re-set the odometer ...................................16

To re-set the time............................................ 18

To re-set all data and settings ......................... 20

Custom tire size

To measure rollout ..........................................23

To set-up a custom tire size............................ 24

Safety

When riding your bicycle, do not stare at the computer for a long time (Figure 1).

If you do not watch the road, you could hit an obstacle, which might cause you

to lose control and fall.

Figure 1. Do not stare at computer for long periods of time.

Getting started: process overview

Getting your GoTime up and running is easy and takes only about 10 minutes.

However, it will help you through the process if you take the time to completely

read this manual before you start. For example, you cannot complete the setup

process (#3 below) if the sensor cannot read the magnet in the wheel (#1).

Here are the steps in the process:

1 - Install the speed sensor and wheel magnet.

2 - Install the battery in the computer.

3 - Setup your preferences for time, miles, etc.

4 - Install the computer on the handlebar.

Tools required

Screwdriver, small slot type

Parts list

ASpeed sensor

BSpoke magnet

CBattery cover

DBattery

ELarge strap

FSmall strap

A D

B F

To install the speed sensor and wheel magnet

3-5mm

4. 5. 6.

2. 3.

Installing your GoTime

To insert the battery

To increase battery life, the GoTime is shipped with the battery NOT INSTALLED.

Before proceeding with the setup, you must install the battery.

After you install the battery, do not place

the computer back into the band because

you will need access to the SET button

on the back of the computer. Instead,

follow the set-up procedure, which starts

automatically when you install the battery.

The instructions start on the next page.

2.1.

To set up your preferences

After you install the battery, the Setup procedure starts automatically. Place the

GoTime within 27” (70 cm) of the sensor, and be ready to activate the sensor as

explained in the next section.

You can begin the Setup procedure without re-installing the battery.

See “To re-set all data and settings,” page 20.

1. To change units (choose kmh or mph), press M.

To save and proceed to the Tire Size screen, press SET .

2. To change the tire size, press M. Repeat until your preferred tire

size appears.

You can also set a custom tire size; see Setting a Custom Tire Size, page 11.

3. To save and proceed to the clock screen, press SET .

4. To change the Clock Type (choose 12 or 24 hour), press M.

To save and proceed to the Hours screen, press SET .

Tire size menu

26 x 1.9

26 x 2.0

26 x 2.1

26 x 2.2

700 x 23

700 x 25

700 x 28

700 x 32

700 x 35

700 x 38

29 x 2.1

29 x 2.3

Custom

SET

5. To change the hours, press M. To scroll faster, hold M.

To save and proceed to the Minutes screen, press SET .

6. To change the minutes, press M. To scroll faster, hold M.

To save and exit the programming mode, press SET .

The Ride screen appears with Speed/Clock mode.

7. Carefully insert the computer back into its band, and follow the steps on the

next page.

SET

To attach the computer

You can attach the computer to the handlebar (only). Consider your preference

for left and right, and your access to the button on the computer.
