Boneco W300 Manual de usuario
19
en
BONECO W300
INSTRUCTION FOR USE
20
en
Cleaning the AW200 evaporator mat 29
About the AW200 evaporator mat 29
Cleaning in the washing machine 29
Cleaning by hand 29
Fan cleaning 30
Cleaning the fan 30
Replacing the accessories 31
A7017 Ionic Silver Stick®31
Availability of accessories 31
Items included 21
Overview and part names 22
Technical data 23
Important notes 23
Start-up 24
Operation 25
Operating modes 25
Fragrance container 26
Basics 26
Use 26
Notes on cleaning 27
About cleaning 27
Recommended cleaning intervals 27
Cleaning the appliance 28
Disassembly and cleaning 28
TABLE OF CONTENTS
21
en
BONECO W300
ITEMS INCLUDED
Power cord
DEAR CUSTOMER,
Congratulations on your purchase of the BONECO W300.
The high-performance air washer keeps humidity at
a comfortable level at all times and improves the well-
being of people and pets – especially during the dry
winter months. At the same time, dust and dirt particles
get caught in the AW200 evaporator mat, resulting in a
significant improvement in air hygiene.
Cleaning the BONECO W300 is as easy as handling it:
Many parts can be conveniently cleaned in a washing
machine or dishwasher.
Regardless of whether it is summer or winter:
You will not want to go without your newly
gained comfort.
Quick Manual Safety instructions
ITEMS INCLUDED
22
en
1
2
3 4 65 7
910811
1On /Off, performance level
2Fan
3Cover / air inlet
4Fragrance container*
5Drum*
6AW200 evaporator mat**
7Water tank
8Air outlet
9 A7017 Ionic Silver Stick®
10 Water base*
11 Water tank cover
* Washable in the dishwasher up to 50°C
** Washable in the washing machine up to
40°C
OVERVIEW AND PART NAMES
23
en
Type designation BONECO W300
Power supply voltage 220 – 240 V ~ 50 / 60 Hz
Power consumption Standby 0 W
Level 1 12.2 W**
Level 2 22.8 W**
Humidity output up to 350 g/h**
Recommended for rooms up to 50 m2/ 125 m3
Water capacity max. 12 liters
Dimensions L × W × H 400 × 280 × 412 mm
Weight (empty) 6.4 kg
Operation noise level Level 1 27 dB(A)**
Level 2 43 dB(A)**
* Subject to change
** At 230 V ~ 50Hz
TECHNICAL DATA*IMPORTANT NOTES
Production-related residue on the water base may
lead to foaming, and thereby to water escaping. For
this reason, before the first use, the water base must
be cleaned with warm water and dish detergent.
Then thoroughly rinse the water base under running
water.
24
en START-UP
Insert the filled water tank.
Connect the power cord to the BONECO W300.
Remove the water tank. Fill the water tank with cold tap water.
Plug the power cord into a power socket. Switch on the appliance.
1
4
2
5
3
6
25
en
OPERATING MODES
The BONECO W300 has two operating modes that can be
switched between using the knob.
• In position , the BONECO W300 works with normal
performance (day mode).
• In position , the BONECO W300 works quietly
(night mode).
A green LED indicates that the BONECO W300 is operat-
ing correctly. The LED is red if the water tank is empty.
OPERATION
26
en
BASICS
Commercially available fragrances and essential oils can
be inserted into the fragrance container on the rear side.
Never mix any fragrances or essential oils into the
water base itself, since doing so can decrease the
performance of the BONECO W300 and even cause
damage. This damage is not covered by the war-
ranty.
The fragrance container can be cleaned in the dish-
washer. The temperature may not exceed 50°C.
USE
1. Remove the water tank.
2. On the rear side, press down on the fragrance con-
tainer to take out the drawer.
3. Sprinkle the felt insert in the drawer with the fra-
grance of your choice.
4. Reinsert the fragrance container.
5. Reinsert the water tank.
FRAGRANCE CONTAINER
27
en
ABOUT CLEANING
Regular maintenance and cleaning are necessary for
trouble-free and hygienic operation.
Recommended cleaning and maintenance intervals vary
depending on air quality, water quality and operating
time.
A soft cloth, dish detergent and a scrub brush are recom-
mended for cleaning by hand.
Always unplug the BONECO W300 from the power
outlet before you begin cleaning! Failure to do so can
result in electric shock and fatal injury!
In the case of cleaning the drum and the water base
in the dishwasher, a temperature of 50 °C may not
be exceeded, as temperatures higher than this can
cause the plastic parts to deform.
RECOMMENDED CLEANING INTERVALS
Interval Action
After the third day without operation Empty water base and water tank and fill with fresh water
Every 2 weeks Clean water base, drum, water tank and AW200 evaporator mat
Annually Replace A7017 Ionic Silver Stick®
Clean the fan and the inner area of the appliance
NOTES ON CLEANING
28
en
7. Clean the inside of the water tank by hand or with a
suitable cleaning brush using a commercially avail-
able dish detergent.
8. Clean the water tank cover with a commercially
available dish detergent and a cleaning brush.
9. Put the BONECO W300 back together by following
the steps in reverse order.
CLEANING THE APPLIANCE
4. Turn both drum discs to release them. In doing so,
note the markings on the outer side of the disc.
5. Remove the AW200 evaporator mat from the drum.
6. Clean the water base and the drum either by hand or
in the dish washer at a max. temperature of 50 °C.
DISASSEMBLY AND CLEANING
1. Take off the upper part of the BONECO W300.
2. Remove the drum with the AW200 evaporator mat.
3. Take out the A7017 Ionic Silver Stick®.
