BM PRO RVMaster Guía de referencia
RVMaster
HELP GUIDE
PAIRING RVMASTER
2
PAIRING TO THE RVMASTER NODE
Pairing your CONTROLLER, smartphone or tablet to the NODE is done in three easy steps and the APP will guide
you through the pairing process.
NOTE: The CONTROLLER will have been paired to your NODE at the factory. You should only need to pair your
own device or smartphone to the NODE.
While the NODE can be paired to a total of four devices (including the CONTROLLER), you can only pair one
device at a time to the NODE.
1. Launch the APP on your phone
2. Using the < or > button on the CONTROLLER, navigate to the "PA" menu item
3. When "PA" appears on the display, press the EXT button to start the pairing process to the NODE, "PA" will
blink for a maximum of 30 seconds or until a device is connected.
Figure 1: Use < or > to navigate to the 'PA' menu item
Figure 2: Press EXT once, to start the pairing process
3
CANNOT PAIR TO THE RVMASTER NODE
When pairing a mobile device to the NODE and "--" appears on screen, it is mostly likely that four devices are
connected to the NODE simultaneously. To resolve this, either
• Close the app on one of the devices that are connected to the NODE and try again, OR
• Clear the memory of the NODE of all the previously paired devices.
CLEARING RVMASTER NODE OF ALL PREVIOUSLY PAIRED DEVICES
Figure 3: Failed to connect
Clearing the NODE memory will also clear the the NODE and CONTROLLER pairing.
After clearing, the CONTROLLER will need to be paired to the NODE again.
WARNING
1. Go to the APP General Settings and click on Bluetooth Connection
2. Press Unpair RV, to unpair the CONTROLLER from the NODE
Figure 4: Unpairing a mobile device from the NODE
3. Navigate to the “PA” function on the CONTROLLER display
4. Press and hold the EXT button until the number 1 scrolls across the CONTROLLER display.
The NODE is now clear of all connected devices.
TEAM
BMPRO
support@bmpro.zendesk.com
821 E. Windsor Ave, Unit 1
Elkhart, IN 46514
5. Pair the CONTROLLER to the NODE again. Please refer to the Pairing to the NODE.
6. Pair the new device to the NODE, (please refer to the Pairing to the NODE).
Figure 6: CONTROLLER Home screen after pairing successful
Figure 5: Go to PA, then Press and hold EXT until
the number 1 scrolls across the CONTROLLER
The Bluetooth icon will appear in the indicated location
After pairing successfully completes, you will see the home screen of the APP.
DOC PART #035285
REV 1.0
10 sec
