BLUETTI EB3A
User Manual
Portable Power Station
Canada
USA
Mexico
Australia
Germany
Italy
Spain
South Africa
Nigeria
UK Sweden
Austria
Switzerland
Japan
China
Malaysia
Singapore
Philippines
New Zealand
Thank You
Thank you for making BLUETTI a part of your family.
From the very beginning, BLUETTI has tried to stay true to a sustainable future through green
energy storage solutions for both indoor and outdoor use while delivering an exceptional
eco-friendly experience for our homes and our world.
That's why BLUETTI makes its presence in 70+ countries and is trusted by millions of customers
across the globe.
CONTENTS
Before You Begin
Safety Instructions
What's In The Box
Standard Packaging
Product Overview
Diagram
Specifications
Operation
LCD Screen
Powering On/Off
Standand Mode
UPS
Setting
APP
Charging
Discharging
Appendix
FAQs (Frequently Asked Questions)
Technical Support
4
5
6
6
7
7
8
9
9
10
10
11
11
12
12
14
15
15
16
3
Before You Begin
The information contained herein is subject to change without notice.
For the latest version, please visit https://www.bluettipower.com/pages/user-guides.
The user manual contains instructions and notes on the operation and use of this unit.
BLUETTI recommends that you use genuine accessories from BLUETTI.
BLUETTI shall not be responsible for any damage or expense that might result from the use
of parts other than genuine parts from the BLUETTI.
For your safety and benefit, please read carefully before using and keep it handy for future
reference.
4
Failure to follow these guidelines may cause damage to your unit and injury to yourself or
others.
Keep this unit away from fire, humidity and dust.
Make sure the place where you are using the unit is well ventilated and spacious.
DO NOT place the unit on an unstable or tilted surface.
Turn off the unit IMMEDIATELY in case of malfunction.
When not using the unit for extended periods of time, power off the unit and disconnect the
AC charging cable from the outlet.
Recommended storage temperature: 14-113OF/-10-45OC.
Charge the unit to 80% SOC every 3-6 months for long-term storage.
5
Safety Instructions
What's In The Box
6
AC Charging Cable
Solar Charging CableCar Charging Cable
User Manual
Warranty CardEB3A Portable Power Station
Standard Packaging
Note: Package details are subject to change without prior notice.
* AC Charging Cable: 71in/180cm.
Car Charging Cable: 28in/72cm, 16AWG, Cigarette Lighter Port to DC7909.
Solar Charging Cable: 59in/150cm, 16AWG, MC4 to DC7909.
USB-C to USB-C Cable: 59in/150cm, 16AWG.
USB-C to USB-C Cable
* Below accessories are not included in standard packaging and can be purchased at
https://www.bluettipower.com/.
Product Overview
7
Diagram
1. Cigarette Lighter Port
2. DC5521 Port
3. DC Power Button
4. DC Input Port
5. AC Input Port
6. AC Circuit Breaker*
7. Wireless Charging Pad
8. LCD Screen
9. LED Lamp
10. LED Lamp Button
11. USB-C Port
12. USB-A Port
13. AC Output Port
14. AC Power Button
1
2
3
4
5
6
7
9
10
11
13
12
14
8
* A circuit breaker is an electrical safety switch designed to protect your unit from damage
caused by overcurrent or short circuit. When the AC current exceeds 10A, it will trip
automatically. Press it once to reset the unit after these symptoms cleared.
8
Note: EB3A supports a 268W Max. AC input by default. When operating at a temperature of 10-40oC,
you can set the Turbo Charging on BLUETTI App and get a 430W Max. input.
EB3A also supports 430W Max. PV + AC dual charging. Solar power serves as the primary power
supply to the EB3A when the total input exceeds 430W.
Specifications
Product
Item EB3A US EB3A EU/UK/AU
General
AC Output
DC Output
AC Input
Battery Capacity
Cell Type
Dimensions (L*W*H)
Weight
Discharging Temperature
Charging Temperature
Working Humidity
268.8Wh(12Ah)
LiFePO4
10.04*7.09*7.20IN/255*180*183MM
10.14LB/4.6KG
-4-104°F/-20-40°C
32-104°F/0-40°C
10-90%
Power
Surge
Voltage
Current
Voltage
Current
Voltage
Current
Voltage
Current
Power
Power
12VDC
10A
12VDC
10A
5VDC
3A
100W Max.
5/7.5/10/15W
600W
1200W
Power
Voltage
Current
Frequency
268/430W Max.
DC Input
Power
Voltage
Current
200W Max.
12-28VDC
8.5A Max.
120VAC
5A
220-240VAC
2.6A
120VAC
9A
60Hz
220-240VAC
4A
50Hz
Cigarette Lighter Port *1
DC5521 *2
USB-A *2
USB-C PD3.0 *1
Wireless Charging *1
Operation
9
LCD Screen
a: ECO Mode
b: Turbo Charging
c: Low-battery Alert
d: Input Power
e: Output Power
f: Battery Capacity
g: AC Frequency
h: Temperature Anomaly Alert
i: Short-circuit Alert
j: Overload Alert
k: Remaining Time Indicator*
l: UPS Indicator
m: AC Indicator
n: DC Indicator
* This indicator tells the remaining charge/discharge time.
a
d
f
h
c
e
g
b
ijlm n
k
10
Setting Mode: When the AC power is off and LCD screen is on, press and hold AC and DC power
buttons simultaneously for 2s. The AC frequency indicator will flash.
Press and hold AC and DC power buttons simultaneously to exist ‘Setting Mode’ .
Note: If the unit has been idle for 1 minute under ‘Setting Mode’ , it will automatically exit
‘Setting Mode’ and the setting changes will not be saved.
ECO Mode: Under 'Setting Mode', press the DC power button to turn it on/off.
Note: When on this mode, the AC/DC output will automatically turn off after 4-hour low (≤10W
for AC, ≤1W for DC) or no load to save power.
Note: Please turn on the DC power to enable the wireless charging.
Press any button, the LCD screen will stay on for 30 seconds.
Powering off: Press and hold power buttons to shut down corresponding output.
Note: Press and hold any button for at least 3s, the unit will be off.
Powering on: Press and hold the AC/DC Power Button for 1s to start up corresponding output.
Green light(on the button)
LCD Display
OFF
OFF
Powering On/Off
Green light(on the button)
LCD Display
ON
ON
Standand Mode
