Blue Sky Network 9575P Manual de usuario

PTT Bagdock

User Guide

BLUE SKY NETWORK, LLC

5353 Mission Center Rd. #222

San Diego, CA 92108, USA

Any operation. Any asset. Anywhere. PTT Bagdock User Guide v2.0

PTT Bagdock

User Guide

Version 2.0

Part Number: 9575P

PTT Bagdock User Guide v2.0

NOTICE

This guide is published and copyrighted by Blue Sky Network (BSN). All information and

specifications in this document are subject to change without notice. Nothing in this document is

intended to create additional or separate warranties or guarantees.

Blue Sky Network, 5353 Mission Center Rd. #222, San Diego, CA 92108

Phone: +1 858-551-3894 | Fax: +1 858-225-0794

Email: support@blueskynetwork.com | Website: www.blueskynetwork.com

Any operation. Any asset. Anywhere. PTT Bagdock User Guide v2.0

Page 4of 17 © 2022 Blue Sky Network, All Rights Reserved
TABLE OF CONTENTS
NOTICE .........................................................................................................................3
ABOUT THIS DOCUMENT ........................................................................................6
SAFETY INFORMATION............................................................................................6
Precautions ...........................................................................................................................................................6
BAG FEATURES .........................................................................................................9
ACCESSORIES............................................................................................................9
EQUIPMENT SET UP ...............................................................................................10
Step 1 –Dock Iridium 9575 Phone in Cradle .............................................................................................10
Step 2 –Charge Dock and Iridium 9575 Phone ........................................................................................10
EQUIPMENT DEPLOYMENT...................................................................................11
Step 1 –Install 9575 Dock in Bag .................................................................................................................11
Step 2 –Deploy Antenna.................................................................................................................................11
HOW TO USE MODES .............................................................................................12
Transferring Between Modes.........................................................................................................................12
Using Iridium 9575 Phone in PTT Mode......................................................................................................12
Using Iridium 9575 Phone in Standard Mode ...........................................................................................13
PRODUCT WARRANTY ...........................................................................................14
DECLARATION OF CONFORMITY........................................................................16
TECHNICAL SUPPORT ...........................................................................................17









PTT Bagdock User Guide v2.0

PAGE INTENTIONALLY LEFT BLANK

Any operation. Any asset. Anywhere. PTT Bagdock User Guide v2.0

ABOUT THIS DOCUMENT

This User Guide was designed to be easy to read and follow. It is organized based on the steps

needed to set up and use the PTT Bagdock with a 9575 Iridium phone.

SAFETY INFORMATION

Precautions

Please read and understand this User Guide before installing your docking station. Careless or

incorrect installation can degrade performance, damage new and existing equipment, and incur

unexpected network airtime charges.

1. FAA Regulations

Blue Sky Network products are not FAA-approved and are not intended for aircraft use.

2. Exposure to Radio Frequency Signals

Your Iridium-designed satellite unit is a low power radio transmitter and receiver. When it is

ON, it receives and sends out radio frequency (RF) signals.

International agencies have set standards and recommendations for the protection of public

exposure to RF electromagnetic energy:

• International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996

• Verband Deutscher Elektrotechniker (VDE) DIN-0848

• United States Federal Commission, Radio Frequency Exposure Guidelines (1996)

• National Radiological Protection Board of the United Kingdom, GS 11, 1988

• American National Standards Institute (ANSI) IEEE C95, 1-1992

• National Council on Radiation Protection and Measurements (NCRP) Report 86

• Department of Health and Welfare Canada, Safety Code 6

These standards are based on extensive scientific review. Over 120 scientists, engineers, and

physicians from universities, government health agencies, and industry reviewed the

available body of research to develop the updated ANSI standard. Your phone’s design

complies with these standards when used as described under “Unit Operation.”

3. Antenna Care

Use only the antenna supplied by your service provider or an approved replacement

antenna. Unauthorized antennas, modifications, or attachments could degrade performance

or damage the phone and may violate local agency regulations.

PTT Bagdock User Guide v2.0

4. Unit Operation

Do not operate the unit when a person or object is within 4 in. (10 cm) of the antenna, as it

may result in impaired call quality and cause the unit to operate at a higher power level than

necessary. It may also expose that person to excessive RF energy levels established by the

FCC RF Exposure Guidelines.

5. Driving

Obey all laws and regulations on cellphone use in the areas where you drive. Observe the

following guidelines when using your phone while driving:

•Use hands-free phone operation, if available.

•Pull off the road and park before making or answering a call if driving conditions so require.

•Give full attention to driving; driving safely is your first responsibility.

6. Electronic Devices

Certain modern electronic equipment may not be shielded against RF signals from your

Iridium-designed satellite unit.

7. Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of

6 in. be maintained between a wireless phone’s antenna and a pacemaker to avoid potential

interference with the pacemaker. These recommendations are consistent with the

independent research by, and recommendations of, Wireless Technology Research.

PERSONS WITH PACEMAKERS

• Should ALWAYS keep the Iridium-designed satellite unit more than 6 in. from their

pacemaker when the unit is turned ON.

• Should turn the unit OFF immediately if you suspect that interference is taking place.

8. Other Medical Devices

If you use any other personal medical device, consult the device’s manufacturer to

determine if it is adequately shielded from external RF energy. Your physician may be able to

assist you in obtaining this information.

Turn your unit OFF in healthcare facilities when any posted regulations instruct you to do so,

as these areas may be using equipment that is sensitive to external RF energy.

9. Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor

vehicles. Check with your vehicle’s manufacturer or representative. You should also consult the

manufacturer of any equipment that has been added to your vehicle.

10. Posted Facilities

Turn your unit OFF in any facilities where posted notices so require.

Any operation. Any asset. Anywhere. PTT Bagdock User Guide v2.0

11. Blasting Areas

To avoid interfering with blasting operations, turn your unit OFF when in a “blasting area” or

in areas posted “Turn off two-way radio.” Obey all signs and instructions.

12. Potentially Explosive Atmospheres

Turn your unit OFF and disconnect the power supply in any area with a potentially explosive

atmosphere. Obey all signs and instructions.

These areas are not always clearly marked and include:

•Fuel or chemical transfer and storage facilities and fueling areas (e.g., gas stations)

•Below deck on boats

•Areas where fuel odors are present (e.g., a gas/propane leak in a car or home), the air

contains chemicals or particles (e.g., grain, dust, or metal powders), or any other area

you may normally be advised to turn off your vehicle engine.

Sparks from your battery or power source in such areas could cause an explosion or fire,

resulting in bodily injury or death.

13. For Vehicles Equipped with Airbags

DO NOT place objects, including installed or portable wireless equipment, in the area over

the airbag or where it could be deployed. Serious injury could occur if in-vehicle wireless

equipment is improperly installed, and the airbag inflates.

14. Important Notes for PABX System Users

If using the docking station with a PABX system, the following precautions must be followed

to prevent damage to your unit.

The docking station emulates a standard landline wall jack and generates the required

operating and ringing voltages. Connect to a PABX as either a central office (CO) or trunk

line. Never connect the docking station to a PABX as an extension to avoid potential damage.

PTT Bagdock User Guide v2.0

BAG FEATURES

ACCESSORIES

Antenna and cable storage

with an internal pass-through

to the dock.

Top half of the bag allows for

rapid access to the display

screen and menu keys.

Internal pass-through in end

pocket provides access to the

charger or accessories.

Optional accessory cable

integrates into the vehicle’s

audio system.

Part Number: ASE-XAD01

Optional swivel mount accessory

kit mounts the dock in a vehicle

or bridge.

This kit allows for easy transition

from bag to vehicle mount.

Part Number: ASE-MNTX2

Any operation. Any asset. Anywhere. PTT Bagdock User Guide v2.0

EQUIPMENT SET UP

Step 1 –Dock Iridium 9575 Phone in Cradle

1) Open the protective

cover on the bottom

of the Iridium 9575

handset.

2) Open the docking

station’s handset lock.

3) Slide the 9575

handset into the dock

until fully seated.

4) Secure the handset

by rotating the lock.

5) Press down on the

protective cover to

access the handset’s

contacts.

6) Slide the phone

mating connector into

the guide slot and

‘click lock’ with the

handset.

Step 2 –Charge Dock and Iridium 9575 Phone

A fully charged dock battery provides approximately 15 hours of service.

Connect the Iridium-

supplied 6V charger to the

dock, then plug the

charging jack directly into

the dock. The charging

indicator is visible on the

Iridium 9575 phone screen;

both the phone and dock

take approximately 4 hours

to charge.
