LOCATION AND TIME OF
THE DEVICE, SCHEDULE
The controller has the ability to work according to a given schedule. To
make this possible, set the device’s me. Go to sengs in the “Device me”
secon, click “Change mezone”. Then select your region and locaon from
the list, conrm your selecon clicking the “Save” buon. The device will
synchronize its me with the server me (if the controller is in a WiFi network
with access to Internet) or it will download me from the phone / tablet. It
is recommended that the controller is always connected to a WiFi network
with Internet access so that it can automacally synchronize its clock.
To be able to control devices using the local sunrise and sunset, you must
also select the locaon of the controller. You can specify the locaon of
the device using a smartphone or tablet. In the secon “Device locaon”,
click “Set locaons”. Browser will ask whether to share locaons - allow. In
the “Coordinates” eld,should appear the approximate coordinates of your
locaon. If the “Set locaons” buon blinks red with the word “Error”, or
the “Coordinates” eld did not change the value from “Not set” to numeric
data, a failurehas occurred during the locaon download. You should make
sure that the phone / tablet has a GPS module and that the sharinglocaon
service is enabled on the phone.
Adding schedule entries can be performed by clicking the “Add item” buon
in the “Schedule” secon of sengs. You can select the days in which the
task will be performed, the type of entry (at a specic me, or relave to
sunrise / sunset - only having a correctly set locaon) and set the parameters
of the task. The set tasks will be visible as a list, individual entries can be
edited or deleted.
4ACCESS POINT AND WIFI
NETWORK SETTINGS
ADDITIONAL INFORMATION
TECHNICAL SPECIFICATIONS
Once you turn on the controller for the rst me, you can proceed to its
further conguraon. Being connected to the WiFi network emied by the
device, in the control panel of the wBox applicaon select the device, then
go to “Sengs” (icon at the top-right corner of the screen).
You can change the name of the device that is displayed in the wBox
applicaon. In addion, you can change the name and password of its
generated WiFi network. Remember that changing the network name or
password will disconnect the device immediately aer you click the “Save”
buon, so re-connect to the device using the newly assigned network name
and password.
You can add the controller to your home WiFi network to control it through
this home network or from anywhere in the World. To do this, in the “Connect”
sengs secon, select a network name from the list and press “Connect”. If
is required, enter the WiFi network password. During the connecon of the
controller to your home network, the phone / tablet may disconnected from
the network. In this case, you will need to reconnect your phone / tablet to
the controller network.
Please remember that in order to control the device outside the local WiFi
network, from anyplace in the World by using the wBox applicaon, the
opon “Remote access enabled” in the controller sengs must be set to
“Yes”.
Once you’ve nished conguring the WiFi network, you can disconnect your
phone/tablet from the controller network and connect your mobile device
directly to your home WiFi network. The control from the wBox applicaon
will work the same way as when the phone / tablet is connected to the
controller network. If the user leaves the local network, for example, leaving
home or using the mobile data, the wBox applicaon will signal this state as
“Remote mode”. In this case, the devices can be controlled, but for security
reasons sengs are not available.
supply voltage 12-24V
energy consumpon <1W
maximum current 12A (3A/channel)
maximum voltage 24V
maximum load 288W
supported switches monostable (push-buon),
not-illuminated
number of inputs 1
inputs type low voltage, logical, push-
-buon, short circuited to GND
number of outputs 4
type of outputs open-drain, PWM,
low side control
color mode RGB / RGBW / RGB or W
/ 4x MONO / CT / 2xCT
mounng method
in the ush-mounted box, on the lamp
housing, directly connected to the LED
strip, e.g. furniture
housing
made of polyurethane composion not
containing halogens, self -exnguishing
for thermal class B (130 °C)
dimensions 39 x 35 x 20 mm
protecon level IP20
controller operang temperature from -20°C to +50°C
protecon inverted polarizaon, ESD
supply voltage 12-24V
API open
communicaon standard μWiFi, compable with WiFi, 802.11g
transmission type bidireconal, encrypted
radio frequency 2.4 GHz
mode
direct connecon (as Access Point),
Wi-Fi connecon via a standard router,
connecon with access from any loca-
on in the world (re- quires only access
to the Internet)
encrypon WPA2-PSK and authencated encryp-
on with associated data (AEAD)
compable devices and systems
Apple iPhone, Apple iPad, iPad Mini,
Android, computers and mobile devices
supporng HTML5
SOFTWARE UPDATE
To update the soware in the controller, connect it to your home WiFi
network (see “Access Point and WiFi Network Sengs” secon) which is
connected to the Internet. Go to “Sengs” (icon at the top-right corner of
the screen) and click the “Get new rmware” buon in the nal secon on
sengs. Wait about 1 minute, do not close the interface and don’t perform
other acons. The device will download the latest soware. The soware
version number, hardware version and device idener can be read at the
boom of the sengs screen.
