Blaupunkt SA 2700 Manual de usuario
Smart GSM Alarm Series
SA 2500/ SA 2700 Kit
Home is priceless. Protecting home should be anyone’s top priority. Blaupunkt
Smart Alarm Series SA 2500/ SA 2700 Kit offers you an easy and efficient way to do
“DIY security, DIY protection.” You can set up a quality security system all by
yourself and control/monitor your home from your smartphone anytime,
anywhere.
The completely wire-free SA2500/ SA 2700 Kit integrates security and home
automation into one system to provide safety and convenience. You can remotely
turn on/off lights and home appliances or arm/disarm your house in seconds. A few
simple touches on your smartphone will get all these done!
SA 2500/ SA 2700 Kit monitors alarms ranging from unauthorized opening/closing
of windows and doors to fire risks. All alarms will be reported to your mobile phone
to prompt you to respond immediately. Your “home radar” will be kept alert at all
times.
This new way of security in our era of smart living is being ushered in by the proven
SA 2500/ SA 2700 Kit sealed with the “blue dot,” the symbol of innovation and
quality performance for over 70 years.
SA 2500 Kit
- 1 x SA 2500 Alarm Control Panel
(without LCD display)
- 1 x Door Contact DC-S1
- 1 x PIR Motion Sensor IR-S1L
- 1 x Remote Controller RC-S1
SA 2700 Kit
- 1 x SA 2700 Alarm Control Panel
(with LCD display)
- 1 x Door Contact DC-S1
- 1 x PIR Motion Sensor IR-S1L
- 1 x Remote Controller RC-S1
A new way of security in the era of
smart living
Completely wire-free
SA 2500/ SA 2700 Kit’s control panel and
sensors/devices communicate wirelessly. The easy
installation saves wiring troubles and preserves home
décor.
30 zones of protection
Smart Alarm Series provides 30 zones of protection for
your premises. Thirty sensors/devices can be installed
in these zones to monitor your house and property.
SMS reporting
The Control Panel sends an SMS message to a preset
phone number to notify the user when an event
happens at home.
Voice reporting
The Control Panel dials a preset phone number and
plays a pre-recorded voice message to report to the
user when an event happens at home.
Home Automation
Your home appliances can be automatically controlled
by security modes, temperature levels or timer settings.
You can also operate home appliances from your
smartphone.
Pre-linked devices
All devices/sensors in the package have been
pre-learned into the Control Panel and can
immediately communicate and operate in the system
after installation.
Connect2Home mobile app
The Connect2Home app enables you to control SA
2500/ SA 2700 from your smartphone, allowing you to
check the current security status, configure system
settings, and remotely arm/disarm your house.
APP
PIR Motion Sensor IR-S1L
• Power: EL123AP 3V lithium battery x 1
• Frequencies available: 433MHz/868.35MHz FM/868.6375MHz Narrow FM
• Operating temperature: -10°C to 45°C
• Dimensions: 53.2mm X 67mm X 89.2mm
Remote Control RC-S1
• Power: Pre-inserted CR2032 3V lithium battery
• Frequencies available: 433MHz/868.6375MHz Narrow Band
FM/868.35MHz
• Operating temperature: -10° to 45°C
• Dimensions: 50mm x 33mm x 14.5mm
Door Contact DC-S1
• Power: CR2 3V lithium battery x 1
• Frequencies available: 433MHz/868.6375MHz Narrow Band
FM/868.35MHz
• Operating temperature: -10° to 45°C
• Dimensions: 85mm x 24.6mm x 19.5mm
Alarm Control Panel SA 2700
• Power: 12V 1A adaptor
• Backup battery: 1.2V Ni-MH rechargeable battery x 4
• Alarm output: 96dB/1M
• Frequencies available: 433MHz/868.6375MHz Narrow Band
FM/868.35MHz FM
• Operating temperature: -10°C to +45°C
• Dimensions: 209mm x 136mm x 22.5mm
Alarm Control Panel SA 2500
• Power: 9V 500mA adaptor
• Backup battery: 4.8V 600mAh Ni-MH rechargeable battery x 4
• Alarm output: 96dB/1M
• Frequencies available: 433MHz/868.6375MHz Narrow Band
FM/868.35MHz FM
• Operating temperature: -10°C to +45°C
• Dimensions: 155 mm x 105 mm x 26 mm
