Black Box 3-Channel DVI Extender Manual de usuario

Dec 2006

AC1070A

3-Channel DVI Extender

Triple - DVI - Extender

using a ﬁberoptic cable

Installation and

Operation Manual

Black Box Corporation 1000 Park Drive Lawrence, PA 15055-1018

Phone: 724-746-5500 Web: www.blackbox.com

2 3-Channel DVI Extender - Installation and Operation Manual

3-Channel DVI Extender

Triple - DVI - Extender

using a ﬁberoptic cable

Version 1.0

October 1, 2005

TRADEMARKS USED IN THIS MANUAL

BLACK BOX and the Double Diamond logo are registered trademarks,

and 3-Channel DVI Extender is a trademark, of BB Technologies, Inc.

Any other trademarks mentioned in this manual are acknowledged

to be the property of the trademark owners.

Black Box Corporation 1000 Park Drive Lawrence, PA 15055-1018

Phone: 724-746-5500 Web: www.blackbox.com

3-Channel DVI Extender - Installation and Operation Manual 3

INTRODUCTION

Thank you for choosing the BLACK BOX 3-Channel DVI Extender.

Its use of ﬁberoptic cables permits transmission of video signals without

any compression.

This ensures completely loss-free data transmissions with full video

refresh rates.

The result:

Excellent image quality, even at high resolutions!

You will not only enjoy the beneﬁts of longer transmission distances,

but also make your transmission routes completely insensitive to

electromagnetic interference.

In addition, you ensure overvoltage protection of your transmission routes.

The BLACK BOX 3-Channel DVI Extender transmits three DVI-I interfaces

(digital/analog) in real time to remote monitors, displays, video projectors

and other output devices with digital interfaces.

While both digital and analog video signals can be supplied to the input side,

the output ports on the receiving side are all digital.

An MTP®/MPO 12-ﬁber multimode ﬁberoptic cable is used as the

transmission medium, facilitating achievement of 3 x 3.6 Gbps data rates.

Depending on the type of ﬁbers used in the ﬁberoptic cable (50 or 62.5 μm),

distances of up to 400 meters can be covered.

Your 3-Channel DVI Extender supplies three output devices via one joint

ﬁberoptic cable.

The 3-Channel DVI Extender supports video resolutions

up to 1920 x 1200 px @ 60 Hz with digital video input and

up to 1600 x 1200 px @ 60 Hz with analog video input.

Optionally, local output devices can also be connected to the transmitter (source).

4 3-Channel DVI Extender - Installation and Operation Manual

INTRODUCTION

Device conﬁguration is based on the serial RS232 interface.

Firmware upgrades are also handled via this connector.

The 3-Channel DVI Extender can be used not only in heavy-duty

industrial environments, but also in the media sector, the television and

entertainment industries, training and education centers and many other

application areas in the visualization business.

The 3-Channel DVI Extender transmission system consists of the

3-Channel DVI Extender TX transmitter unit and the 3-Channel DVI Extender RX

receiver unit.

Both devices are delivered as desktop versions.

3-Channel DVI Extender - Installation and Operation Manual 5

TABLE OF CONTENTS

INTRODUCTION 3

TABLE OF CONTENTS 5

SAFETY GUIDELINES 6

DELIVERABLES 7

DEVICE CONNECTIONS 8

EXPLANATION OF CONNECTIONS 9

HARDWARE INSTALLATION 10

INSTALLATION PLAN 11

DEVICE CONFIGURATION PROGRAM INSTALLATION 12

PROGRAM INSTALLATION 12

SETTINGS 13

CONFIGURATION 14

PROGRAM START 14

NAVIGATION 15

CONFIGURATION OVERVIEW 16

VIDEO VIDEO INPUT 17

BRIGHTNESS AND CONTRAST 19

HORIZONTAL AND VERTICAL POSITION 20

SCREEN WIDTH AND PHASE 21

SYSTEM LANGUAGE 22

CONFIGURATION FACTORY RESET 23

EDID INTERNAL AND DEFAULT 24

EXTERNAL 25

HELP ABOUT AND CONTACT 26

FIRMWARE UPDATE 27

TECHNICAL SPECIFICATIONS 29

ACCESSORIES 30

SERVICE INFORMATION 31

TECHNICAL SUPPORT 32

NOM-STATEMENT 33

DECLARATION OF CONFORMITY 35

FCC DECLARATION 35

6 3-Channel DVI Extender - Installation and Operation Manual

SAFETY GUIDELINES

CAUTION: LASER

Your 3-Channel DVI Extender is a Class 1 laser product.

There is a risk of damaging your eyesight if you disregard this safety information!

Even if they are not in use, the ﬁberoptic connections of the modules must be sealed

either with a MTP®/MPO cable connector or a dust cap.

Please ensure that the power supply is switched off before you disconnect or

connect ﬁberoptic cables.

Both the 3-Channel DVI Extender TX transmitter and the 3-Channel DVI Extender RX

receiver are connected to the power supply system.

Please observe the usual safety regulations for handling devices connected to

a power supply system.

Both devices have built-in fans. Please ensure that there is a reliable air supply

on both sides and the air outlet on the rear panel are not blocked.

Your desktop devices should never be placed on the ﬂoor between cables.

Moisture and dust will affect the reliable functioning of your 3-Channel DVI Extender.

These devices are maintenance-free. Never open the device panels.

There are no settings that need to be adjusted inside the casing.

Please contact BLACK BOX’s Technical Support

for troubleshooting purposes (page 31).

3-Channel DVI Extender - Installation and Operation Manual 7

DELIVERABLES

Please use the list below to verify that all parts have been delivered.

The following components are included:

1 3-Channel DVI Extender TX transmitter unit

1 3-Channel DVI Extender RX receiver unit

2 power cables

2 DVI / DVI video cables, 2.0 meters, for the transmitter unit

1 VGA / DVI video cable, 2.0 meters, for the transmitter unit

1 serial RJ45 / RS232 cable

1 installation CD for Windows

1 installation and operation manual

The MTP®/MPO ﬁberoptic cables supplied to you by BLACK BOX are prefabricated

and cut to the desired custom lengths for a maximum range of up to 400 meters.

Please see page 30 for further details and more optional accessories.

•

8 3-Channel DVI Extender - Installation and Operation Manual

DEVICE CONNECTIONS

3-Channel DVI Extender TX

transmitter unit

Front panel

3-Channel DVI Extender TX

transmitter unit

Rear panel

3-Channel DVI Extender RX

receiver unit

Front panel

3-Channel DVI Extender RX

receiver unit

Rear panel

3-Channel DVI Extender - Installation and Operation Manual 9

EXPLANATION OF CONNECTIONS

1 LED Lights up when the video signal is active

2 LED Power Lights up when the power supply is active

3 3-Channel DVI Extender TX

Label identifying the TX transmitter unit

4 Switch Switches the power supply on and off

5 Air outlet Ventilation duct where the heated outgoing air is vented.

Please do not cover!

6 DVI OUT 1-3 Optional local connections for linking video output devices

to the TX transmitter unit

7 Air intake Ventilation duct for air intake in on both sides.

Please do not cover!

8 Power connector For connecting the supplied power cable

9 Optical MTP®/MPO port for connecting the ﬁberoptic cable with

MTP®/MPO female / female plugs

10 RS232 RJ45 port for connecting the serial cable for device

conﬁguration and ﬁrmware updates

11 DVI IN 1-3 Input port for the video signal

Connection to the video source

Importing EDID (page 25)

Connecting cable included in deliverables

12 3-Channel DVI Extender RX

Label identifying the RX receiver unit

13 DVI OUT 1-3 Output port for the digital video signal

Connection to video output device via connecting cable

10 3-Channel DVI Extender - Installation and Operation Manual

HARDWARE INSTALLATION

Safety information:

Please ensure that the power is switched off when installing any device!

Laser Class 1 devices can damage your eyesight!

Installation steps:

1. Select a suitable location for the 3-Channel DVI Extender TX transmitter

unit and the 3-Channel DVI Extender RX receiver unit.

Please see page 30 for information about optional accessories.

Please comply with the safety guidelines on page 6.

2. Connect your 3-Channel DVI Extender TX transmitter unit to the video

signal sources via the respective DVI IN input, using the enclosed DVI cables.

3. Connect your 3-Channel DVI Extender RX receiver unit to the video

output devices via the respective DVI OUT output, using the DVI cables.

4. Connect your 3-Channel DVI Extender TX transmitter unit to your

3-Channel DVI Extender RX receiver unit via the MTP®/MPO plug labeled “Optical”,

using an MTP®/MPO 12-ﬁber multimode ﬁberoptic cable.

Please make sure that both connectors lock in place.

The necessary cables are available from BLACK BOX (see page 30).

5. Please check again that all cables, plugs and screw connections

have been connected properly.

6. Connect the transmitter and receiver to the power supply and

switch on both devices.

7. Power up your computers or video output sources.

8. Use the CONFDEV device conﬁguration program

(see Page 12 et seq.) for conﬁguration.

Please note:

BLACK BOX also guarantees interference-free operation for video cable lengths

of 3 to 5 meters.

If you experience any interference, please check the quality of the video cables

used, the video resolution settings and the quality of the devices connected.

If the distance between the video output device and your 3-Channel DVI Extender RX

receiver unit exceeds 5 meters, BLACK BOX offers an extension kit supporting

the use of longer video cables (page 30).
