FEBRUARY 2001

MD401A

MD402A

56K CardBus Modem PC Card

56K Modem PC Card

CUSTOMER SUPPORT INFORMATION

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: [email protected]

56K MODEM PC CARD

56K CARDBUS MODEM

PC CARD

FCC/IC RFI STATEMENTS

FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA

RADIO-FREQUENCY INTERFERENCE STATEMENTS

Class B Digital Device. This equipment has been tested and found to comply

with the limits for a Class B computing device pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. However, there is no

guarantee that interference will not occur in a particular installation. This

equipment generates, uses, and can radiate radio frequency energy, and, if

not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. If this equipment does

cause harmful interference to radio or telephone reception, which can be

determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult an experienced radio/TV technician for help.

Caution:

Changes or modifications not expressly approved by the

party responsible for compliance could void the user’s

authority to operate the equipment.

To meet FCC requirements, shielded cables and power cords are required to

connect this device to a personal computer or other Class B certified device.

This digital apparatus does not exceed the Class B limits for radio noise emission from

digital apparatus set out in the Radio Interference Regulation of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les

limites applicables aux appareils numériques de classe B prescrites dans le Règlement

sur le brouillage radioélectrique publié par Industrie Canada.

56K CARDBUS MODEM PC CARD AND 56K MODEM PC CARD

EUROPEAN UNION DECLARATION OF CONFORMITY

The manufacturer declares that this equipment conforms to the following

standards:

• EN 55022 (1987): “Limits and methods of measurements of radio

interference characteristics of information technology equipment.”

• EN 50082-1 (1992): “Electromagnetic compatibility - Generic

immunity standard for residential, commercial, and light industrial

equipment.”

These products herewith comply with the requirements of the EMC

Directive 89/336/EEC. The products were tested in a typical configuration.

REPEAT-CALLING STATEMENT

The host computer must not initiate repeated call attempts within intervals

shorter than 30 seconds. It is the user’s responsibility to make sure that their

software is set to handle repeat calling correctly.

NOM STATEMENT

NORMAS OFICIALES MEXICANAS (NOM)

ELECTRICAL SAFETY STATEMENT

INSTRUCCIONES DE SEGURIDAD

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes

de que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para

referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de

operación deben ser respetadas.

4. Todas las instrucciones de operación y uso deben ser seguidas.

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,

cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc.

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales

que sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea

recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más

allá a lo descrito en las instrucciones de operación. Todo otro servicio

deberá ser referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no

interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,

alfombra o superficie similar puede bloquea la ventilación, no se debe

colocar en libreros o gabinetes que impidan el flujo de aire por los orificios

de ventilación.

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor

como radiadores, registros de calor, estufas u otros aparatos (incluyendo

amplificadores) que producen calor.

56K CARDBUS MODEM PC CARD AND 56K MODEM PC CARD

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del

tipo descrito en el instructivo de operación, o como se indique en el

aparato.

12. Precaución debe ser tomada de tal manera que la tierra fisica y la

polarización del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no

sean pisados ni pellizcados por objetos colocados sobre o contra ellos,

poniendo particular atención a los contactos y receptáculos donde salen

del aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las

recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos de las

lineas de energia.

16. El cable de corriente deberá ser desconectado del cuando el equipo no sea

usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean

derramados sobre la cubierta u orificios de ventilación.

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u

B: Objectos han caído o líquido ha sido derramado dentro del aparato; o

C: El aparato ha sido expuesto a la lluvia; o

D: El aparato parece no operar normalmente o muestra un cambio en su

desempeño; o

E: El aparato ha sido tirado o su cubierta ha sido dañada.

FCC PART 68 MODEM STATEMENT

FEDERAL COMMUNICATIONS COMMISSION MODEM STATEMENT

1. The Federal Communications Commission (FCC) has established rules

which permit this device to be directly connected to the telephone

network with standardized jacks. This equipment should not be used on

party lines or coin lines.

2. If this device is malfunctioning, it may also be causing harm to the tele-

phone network; this device should be disconnected until the source of the

problem can be determined and until the repair has been made. If this

is not done, the telephone company may temporarily disconnect service.

3. If you have problems with your telephone equipment after installing

this device, disconnect this device from the line to see if it is causing the

problem If it is, contact your supplier or an authorized agent.

4. The telephone company may make changes in its technical operations

and procedures. If any such changes affect the compatibility or use of

this device, the telephone company is required to give adequate notice

of the changes.

5. If the telephone company requests information on what equipment is

connected to their lines, inform them of:

a. The telephone number that this unit is connected to.

b. The ringer equivalence number.

c. The USOC jack required: RJ-11C.

d. The FCC registration number.

Items (b) and (d) can be found on the unit’s FCC label. The ringer

equivalence number (REN) is used to determine how many devices can

be connected to your telephone line. In most areas, the sum of the

RENs of all devices on any one line should not exceed five (5.0). If too

many devices are attached, they may not ring properly.

6. In the event of an equipment malfunction, all repairs should be

performed by your supplier or an authorized agent. It is the

responsibility of users requiring service to report the need for service to

the supplier or to an authorized agent.

56K CARDBUS MODEM PC CARD AND 56K MODEM PC CARD

INDUSTRY CANADA MODEM STATEMENT

The Industry Canada (IC) label identifies certified equipment. This

certification means that the equipment meets certain telecommunications-

network protective, operation, and safety requirements. Industry Canada

does not guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is permissible

to be connected to the facilities of the local telecommunications company.

The equipment must also be installed using an acceptable method of

connection. In some cases, the company’s inside wiring associated with a

single-line individual service may be extended by means of a certified

connector assembly (extension cord). The customer should be aware that

compliance with the above conditions may not prevent degradation of

service in some situations.

Repairs to certified equipment should be made by an authorized

Canadian maintenance facility—in this case, Black Box. Any repairs or

alterations made by the user to this equipment, or equipment malfunctions,

may give the telecommunications company cause to request the user to

disconnect the equipment.

Users should ensure for their own protection that the electrical ground

connections of the power utility, telephone lines, and internal metallic water

pipe system, if present, are connected together. This precaution may be

particularly important in rural areas.

CAUTION:

Users should not attempt to make such connections

themselves, but should contact the appropriate electric

inspection authority, or electrician, as appropriate.

The LOAD NUMBER (LN) assigned to each terminal device denotes the

percentage of the total load to be connected to a telephone loop which is

used by the device, to prevent overloading. The termination on a loop may

consist of any combination of devices, subject only to the requirement that

the total of the load numbers of all the devices does not exceed 100.

TABLE OF CONTENTS

Contents

Chapter Page

1. Specifications .............................................................. 8

2. Introduction ............................................................. 12

3. Installation and Operation ...................................... 14

4. Troubleshooting ....................................................... 15

4.1 Calling Black Box .............................................. 15

4.2 Shipping and Packaging ................................... 16

Appendix: Direct Modem Control ................................. 17

A.1 AT Commands .................................................. 17

A.2 S-Registers .......................................................... 21

A.3 Result Codes ...................................................... 23

A.4 Factory-Default Settings of

Some Important Options............................. 26

56K CARDBUS MODEM PC CARD AND 56K MODEM PC CARD

1. Specifications

Compliance —

EMI/RFI: CE (EN 55022 and EN 50082-1), FCC Part 15

Subpart J Class B, IC Class/classe B;

Phone-system compatibility: FCC Part 68;

Also certified by various European PTTs

FCC Part 68 Registration Number — Both models share

the registration number 4W91SR-32427-M5-E

Ringer-Equivalence Number — Both models are 0.88 B

Standards and Data Rates —

PC Card:

MD401A: 32-bit CardBus PC Card, Type II, 3.3V;

MD402A: 16-bit PC Card, Type II;

Modem commands: Full AT command set;

Error correction: ITU V.42 LAPM and MNP 2 through 4;

Data compression: ITU V.42 bis and MNP 5;

Video-ready modem (VRM): ITU V.80;

CHAPTER 1: Specifications

Standards and Data Rates (continued) —

Modem communication:

Downstream only: ITU V.90 and K56flex™ at up to

56,000 bps (FCC rules limit speeds to ~53,0000 bps

in the U.S.);

“V.34+” at up to 33,600 bps;

ITU V.34 at up to 28,800 bps;

“V.32 terbo” at up to 19,200 bps;

ITU V.32 bis at up to 14,400 bps;

ITU V.32 at up to 9600 bps;

ITU V.22 bis at up to 2400 bps;

ITU V.22 A/B and V.23 at 1200/600 bps;

ITU V.21 at up to 300 bps;

Bell 212A at 1200 bps;

Bell 103J at up to 300 bps;

Fax commands: ITU Group 3, command sets for

ITU Classes 1 and 2 (TIA-578 and -592);

Fax communication:

ITU V.17 at up to 14,400 bps;

ITU V.29 at up to 9600 bps;

ITU V.27 ter at up to 4800 bps;

ITU V.21 channel 2 at up to 300 bps
