Black & Decker GEH183 Manual de usuario
GEH183
www.blackanddecker.com
7
25
19
37
31
13
Bahasa indonesia
English (original instructions)
2
A
3
B3
B1
B4
B2
2
1
1
2
4
C
5
D
6
E
ENGLISH
Your Black & Decker multi-purpose tool has been
designed for a wide range of DIY applications.
Using the shear/trimmer head (GEH183), this tool
is intended for trimming grass, hedges, shrubs and
brambles.
This tool is intended for consumer use only.
@Read all safety warnings
and all instructions. Failure to follow
the warnings and instructions listed
and/or serious injury.
@Read all safety warnings
and all instructions provide with your
power tool (EVO143, EVO181, EVO183,
EAC800, EAD800) before using this
follow the warnings
and instructions
or serious injury.
The term “power tool” in the warnings
refers to your mains operated (corded) power tool
or battery operated (cordless) power tool.
@Additional safety warnings
for hedge trimmers
A moment of inat-
tention while operating the hedge trimmer may
result in serious personal injury.
min-1
2,300 2,800
cm 10 10
mm 23 23
cm 15 15
mm 8 8
mm <1 <1
kg 1.57 1.68
accessory. Failure to
GEH183
Technical Data
SHEAR/ TRIMMER HEAD
EVO143
(14.4V)
EVO181/183
(Max)
2,800
10
23
15
8
<1
1.68
2,800
10
23
15
8
<1
1.68
EAC800-KR EAD800-TW
Specifications:
Proper handling
of the hedge trimmer will reduce possible
personal injury from the cutter blades.
Cutter blades contact-
ing a “live” wire may make exposed metal
parts of the power tool “live” and could give the
operator an electric shock.
ENGLISH
During
operation the cable may be hidden in shrubs
and can be accidentally cut by the blade.
The intended use is described in this instruc-
tion manual. The use of any accessory or
attachment or performance of any operation
with this tool other than those recommended
in this instruction manual may present a risk of
personal injury and/or damage to property.
Always check the hedge/work area for foreign
objects before starting.
If you have not used a hedge trimmer before,
preferably seek practical instruction by an
experienced user in addition to studying this
manual.
Never touch the blades while the tool is run-
ning.
Never attempt to force the blades to come to a
standstill.
Do not put the tool down until the blades have
come to a complete standstill.
Regularly check the blades for damage and
wear. Do not use the tool when the blades are
damaged.
Take care to avoid hard objects (e.g. metal
wire, railings) when trimming. Should you
accidentally hit any such object, immediately
switch the tool off and check for any damage.
Should the tool start to vibrate abnormally,
immediately switch it off and check for any
damage.
If the tool stalls, immediately switch it off.
After use, place the blade sheath supplied over
the blades. Store the tool, making sure that the
blade is not exposed.
when using the tool. Never attempt to use an
incomplete tool or a tool with unauthorised
Never allow children to use the tool.
Be aware of falling debris when cutting the
higher slides of a hedge.
@Additional safety warnings
for shears
Never allow people unfamiliar with these in-
structions or children to use the machine. Local
regulations can restrict the age of the operator.
Keep in mind that the operator or user is
responsible for accidents or hazards occurring
to other people or their property.
Never operate the machine while people, espe-
cially children, or pets are nearby.
Use the machine only in daylight or good
ENGLISH
Take care against injury to feet and hands from
the cutting means. Only switch on the motor
only when the hands and feet are away from
the cutting means.
Always ensure that the ventilation openings are
kept clear of debris.
Use only the manufacturer’s recommended
replacement parts and accessories.
Inspect and maintain the machine regularly.
Have the machine repaired only by an author-
ised repairer.
@Contact with, or inhalation
of dusts arising from cutting applica-
tions may endanger the health of the
operator and possible bystanders.
designed for protection against dust
and fumes and ensure that persons
within or entering the work area are
also protected.
The following pictograms are shown on the tool:
:To reduce the risk of
injury, the user must read the
instruction manual.
RDo not expose the tool to rain or high
humidity.
Beware of sharp blades. Blades
continue to move after the motor is
switched off.
bystanders away.
96
Directive 2000/14/EC guaranteed
sound power.
ENGLISH
Tool shown is EVO183. Other tools are available
for use with this tool head.
This tool includes some or all of the following
features.
10. Garden Shear/Hedge trimmer head
11. Grass shear blade
12. Hedge trimm blade
13. Blade release button
14. Blade cover
15. Lock off button
16. Grass shear blade cover
17. Hedge trimm blade cover
Before attempting any of the following
operations, remove the battery from the tool and
make sure that the saw blade has stopped. Used
saw blades may be hot.
The shear blade (11) has been designed for trim-
ming grass and weeds. The trim blade (12) has
been designed for trimming hedges and shrubs.
Hold the tool away from the body
Push and hold the blade release button (13) in
Slide the blade cover (14) backward and lift off
Lower the blade onto the pins (B3).
The retaining magnet (18) will keep the
blade secured to garden shear/hedge trimmer
head.
Replace the blade cover (14) and slide it
Alignment of the blade with the drive pin
and alignment of the back of the blade and the
blade cover.
Ensure the forward reverse slider (2) is not
in the locked position.
To switch the tool on, pull the lock off button
(15) then press the variable speed switch (1).
The tool should always be run at full speed.
Release the lock off button.
To switch the tool off, release the variable
speed switch.
